Advanced Menu

Selecting the Advanced Menu from the main menu takes you to the
submenu shown below.
Scaling adjusts the video input signal to the screen size using the
following options.
Press [M] or [L] to select from the following options:
1:1 adjusts the video signal so that the height and width of the
picture are the same.
Sharpness adjusts the clarity and focus of the screen image.
Press [M] or [L] to adjust the image sharpness.
®
ViewMeter displays the timing mode (video signal input) coming
from the graphics card in your computer. See page 8 for instructions
on changing the resolution. Also, see your graphic card's user guide
for instructions on changing the refresh rate (vertical frequency).
NOTE: See the Preset Timing Modes chart on page 8. Example:
®
VESA 1280 x 1024 @ 60Hz (recommended) means that the
resolution is 1280 x 1024 and the refresh rate is 60 Hertz.
ViewSonic VG181 Using the ViewPanel 15
