Summary of Contents for ViewSonic ViewPanel VG181 VLCDS21594-1
- Page 1 ® VG181 ViewPanel User Guide Guide de l’utilisateur Bedienungsanleitung Manual de Instrucciones Guida per l'utente Guia do usuário Användarhandbok Polski...
-
Page 2: For Your Records
To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic Wizard CD-ROM also provides an opportunity for you to print the registration form, which you may then mail or fax to ViewSonic. -
Page 3: Table Of Contents
*To meet your future needs, and to receive any additional product information as it becomes available, please register your monitor's warranty on the Internet at: http://www.viewsonic.com....... 4 ®... -
Page 4: Getting Started
Getting Started Congratulations on your purchase of a ViewSonic VG181 color monitor! You have selected one of the most advanced display devices in the industry. Features include OptiSync™ technology making the VG181 capable of accepting virtually any of today's analog and tomorrow's Digital Video Interface (DVI) input sources. -
Page 5: Before Using The Viewpanel
ViewPanel, video cable, or power cord. • CAUTION: If smoke, abnormal noise, or strange odor is present, immediately switch the ViewPanel off and call your dealer or ViewSonic. It is dangerous to continue using the ViewPanel in this condition. ViewSonic VG181... -
Page 6: Important Safety Instructions
If the product has been dropped or the cabinet has been damaged. e) If the product exhibits a distinct change in performance, indicating a need for service. ViewSonic VG181 Getting Started... -
Page 7: Quick Installation
Quick Installation Available options: wall mount (contact ViewSonic or your dealer), turn the display from Landscape to Portrait mode (see Using the ViewPanel section), raise or lower the display up or down (see the next page). However, if you just want the quickest and easiest way to get connected, follow the Quick Installation instructions below. -
Page 8: Installation-Wall Mount (Optional)
Installation-Wall Mount (optional) To get a wall mounting kit, contact ViewSonic compatible with the VESA wall mounting standards. To convert the desk-mounted VG181 to a wall-mount installation, do the following: 1 Disconnect DC power. Make sure the power is turned off... -
Page 9: Using The Viewpanel
Setting the Timing Mode The timing mode consists of the resolution and refresh rate (vertical frequency). After setting the timing mode, use the ViewSonic OnView controls in this section to make adjustments. The recommended timing mode for this ViewPanel is: 1280 x 1024 @ 60Hz. -
Page 10: Landscape/Portrait Modes
(video) cards. For information on compatible graphics cards and approved hardware configurations, go to the ViewSonic website, http:// www.viewsonic.com, and select the following path: Customer support > Support options > Document area > PPCHART.XLS. The PPCHART.XLS spreadsheet will provide information on compatibility with your graphics card. -
Page 11: Adjusting The Screen Image
Main Menu See the steps below for accessing the menus. See the next few pages for descriptions of menu selections. All menus and adjustment screens disappear automatically. ViewSonic VG181 Using the ViewPanel oywers o/offl... - Page 12 Adjusting the Screen Image..continued The following steps show an example of how to access the OnView Main ® Menu from ViewSonic , the Submenus, and make adjustments to your screen image. For more information on each control see the next few pages.
-
Page 13: Main Menu
CONTRAST adjusts the difference between the image background (black level) and the foreground (white level). [M] decreases contrast, [L] increases contrast. BRIGHTNESS adjusts background black level of the screen image. [M] decreases brightness, [L] increases brightness..continued ViewSonic VG181 Using the ViewPanel... - Page 14 Phase minimizes the video distortion. Press[M] or [L] to adjust to your preference. Zoom expands and contracts the entire screen image. [M] Expands the screen image. [L] Contracts the screen image..continued ViewSonic VG181 Using the ViewPanel...
- Page 15 5400K — Adds green to the screen image for a darker color. 5000K — Adds blue and green to the screen image for a darker color. User Color — Individual adjustments for red, green, and blue. Press [L] to increase blue. Using the ViewPanel ® Color Menu ViewSonic VG181...
-
Page 16: Advanced Menu
(vertical frequency). NOTE: See the Preset Timing Modes chart on page 8. Example: ® VESA 1280 x 1024 @ 60Hz (recommended) means that the resolution is 1280 x 1024 and the refresh rate is 60 Hertz. ViewSonic VG181 Using the ViewPanel... -
Page 17: Setup Menu
Preset Timing Mode listed in this user guide. Exception: This control does not affect changes made with the User Color control. Note: Using this control resets color to 9300K. ViewSonic VG181 Using the ViewPanel... -
Page 18: Other Information
Display Area Full scan Operating Temperature Preset Timing Modes (pre-adjusted to VESA Timing Modes table. * Macintosh computers may require a ViewSonic vsparts@viewsonic.com, or contact ViewSonic. ViewSonic VG181 " 18.1" (full viewable diagonal area), TFT (Thin Film Transistor), Active Matrix XGA LCD, 0.2805mm pixel pitch... -
Page 19: Troubleshooting
Try the ViewPanel with another power source, graphics card, or computer system. • Connect the video cable securely. Control buttons do not work • Press only one button at a time. Other Information ® color menu for proper settings ® is tightly secured ViewSonic VG181... -
Page 20: Customer Support
New Zealand T: 64-3-366-1135 F: 64-3-366-7006 Singapore/Southeast T: 65-273-4018 Asia F: 65-273-1566 Other Asia/Pacific T: 886-2-2248-4072 countries and Indian F: 886-2-2249-1751 Peninsula South Africa T: 27-11-314-0002 F: 27-11-314-0002 ViewSonic VG181 Email vstech@viewsonic.com vstechs@viewsonic.com -------------------------- service.au@viewsonic.com mbarlass@vistech.co.nz service.sg@viewsonic.com service.ap@viewsonic.com atscom@mweb.co.za Other Information... -
Page 21: Cleaning The Viewpanel
Chemical cleaners have been reported to damage the screen and/or case of the ViewPanel. Further, ViewSonic does not recommend applying pressure when wiping the ViewPanel screen clean. ViewSonic will not be liable for damage resulting from use of liquid cleaners or resulting from applying pressure to the screen. -
Page 22: Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components. -
Page 23: Appendix
Switzerland ...SEV Britain ...BASEC/BS Japan ...Electric Appliance Earth Neutral Live Table A Size of Conductors In Cord 18AWG 16AWG 14AWG 18AWG 17AWG Control Act Figure 1 Figure 2 Maximum Current Rating of Unit 10Amps 12Amps 12Amps 10Amps 12Amps ViewSonic VG181... -
Page 24: Fcc Information
The device complies with the requirements of the EEC directive 89/336/EEC as amended by 92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic compatibility”, and 73/23/EEC as amended by 93/68/EEC Art. 13 with regard to “Safety”. ViewSonic VG181 FCC Information FCC Warning: Power Supply Cord USA... - Page 25 Appendix NOTES ViewSonic VG181...
- Page 26 ® ViewSonic Corporation...
