- Page 1 OPERATING INSTRUCTIONS • NOTICE D’UTILISATION BEDIENUNGSANLEITUNG • ISTRUZIONI D’USO INSTRUCCIONES DE USO DSAF94MR5IAA DSAF124MR5IAA DSAF184MR5IAA DSAF224MR5IAA Split air conditioner system • Climatiseurs split Split- Klimagerät • Condizionatori d’aria Split System Acondicionador de aire de consola partida sistema split 37.4163.254.0 01/2005...
-
Page 2: Features
Features This air conditioner is equipped with cooling, heating, and drying functions. Details on these functions are provided below; refer to these descriptions when using the air conditioner. • Microprocessor Controlled Operation • Air Sweep Control The interior compartment of the remote control This function moves a flap up and down in the unit contains several features to facilitate air outlet, directing air in a sweeping motion... -
Page 3: Table Of Contents
Contents Page Features ......................2 Product Information ..................3 Alert Symbols ....................3 Installation Location ..................4 Electrical Requirements .................. 4 Safety Instructions ..................4 Names of Parts and operation selector ............5 Using the Remote Control Unit ..............10 Operation with the Remote Control Unit ............ -
Page 4: Installation Location
Installation Location • We recommend that this air conditioner be installed properly by qualified installation technicians in accordance with the Installation Instructions provided with the unit. • Before installation, check that the voltage of the electric supply in your home or office is the same as the voltage shown on the nameplate. •... -
Page 5: Names Of Parts And Operation Selector
Names of parts and operation selector TIMER OPERATION 10. Operation selector. ON Position: In this position the air conditioner is operating and controlled by the remote control unit. Set the selector normally in this position. OFF Position: Switch the selector to the off position if you are not going to use the air conditioner for a few days or longer. - Page 6 Remote Control Unit (Display) Displayed when setting temperature in automatic operation Displayed when transmitting data Displayed when indoor unit sensor is in use Displayed when setting temperature Displayed when setting timer Symbols (1) Operation mode (5) ECONOMY ......AUTO ........(6) High power operation ...
- Page 7 Remote Control Unit Sensor Transmitter (Cover closed) Display ON/OFF operation button HIGH POWER button 1 HR. TIMER button Temperature setting buttons (TEMP .) ECONOMY button OFF TIME setting button ON TIME setting button MODE selector button Return button FAN SPEED selector button Advance button FLAP button Inactivated button...
- Page 8 Remote Control Unit (continued) No display : The timer does not operate. ON TIME/OFF TIME setting buttons : The air conditioner stops at the set time. : The air conditioner starts at the set time. : The air conditioner stops and starts, or starts and stops, at the set times every day.
- Page 9 Remote Control Unit (continued) ADDRESS switch • Change the address switch to prevent mixing of signals from remote control units when two air conditioners are installed next to each other. Normally, the address switch is set to A. When switching the adress, take the steps listed below.
-
Page 10: Using The Remote Control Unit
Using the Remote Control Unit How to Install Batteries 1. Slide the cover in the direction indicated by the arrow and remove it. 2. Install two AAA alkaline batteries. Make sure the batteries point in the direction marked in the battery compartment. -
Page 11: Operation With The Remote Control Unit
Operation with the Remote Control Unit 1. Automatic Operation STEP 2 STEP 3 STEP 1 STEP 1 Press the MODE selector button and select (AUTO). STEP 2 Press the ON/OFF button and switch the air conditioner ON. STEP 3 Press the temperature setting buttons (TEMP .). The air conditioner starts operating after automatically selecting the type of operation —whether heating, drying (dehumidifying) or cooling—that suits the conditions in the room, and automatically adjusting the temperature, fan speed and airflow direction. -
Page 12: Manual Operation
Operation with the Remote Control Unit (continued) As shown in the figure below, the automatic selection of the operating modes is determined by the indoor temperature and outside air temperature. Temperature setting Indoor temperature (standard) Approx. Approx. Approx. 27°C 15°C 22°C Cooling Approx. - Page 13 Operation with the Remote Control Unit (continued) STEP 1 Press the MODE selector button and select the desired mode. → For heating operation For dehumidifying operation → → For cooling operation STEP 2 To start the air conditioner, press the ON/OFF operation button.
-
Page 14: Adjusting The Fan Speed
Operation with the Remote Control Unit (continued) 3. Adjusting the Fan Speed A. Automatic Simply set the FAN SPEED selector button to the position. B. Manual If you want to adjust fan speed manually during operation, just set the FAN SPEED selector button as desired. [ , or 4. - Page 15 Operation with the Remote Control Unit (continued) A. In Cooling and DRY When the ECONOMY mode is selected, the air conditioner Mode: ( and ) automatically raises the temperature setting 1 °C when 60 minutes have passed after the selection was made. This enables you to save energy without sacrificing comfort.
-
Page 16: Special Remarks
Special Remarks Power failure • In the event of power failure, the unit will stop. Though the power is during operation resumed, the unit will not restart automatically. Press the ON/OFF operation button and restart the unit again. Clicking Sound •... -
Page 17: Setting The Timer
Setting the Timer 1. How to set the present (Example) To set to 10:30 pm. time Operation Indication 1. Press the CLOCK button three The time indication alone blinks. times. 2. Press the Advance, Return ( , ) The time can be set in 1-minute button until PM 10:30 is increments. - Page 18 Setting the Timer (continued) NOTE • The timer can be programmed while the unit is operating or while it is stopped. • A timer program is canceled after the timer has operated. So the timer should be set every time programming operation is to be performed.
- Page 19 Setting the Timer (continued) 4. How to set DAILY ON/ (Example) To start operation at 7:10 am. and stop the air conditioner at OFF REPEAT timer 11:00 am. 7:10 am. 11:00 am. Present time Operation Indication The present time 10:30 pm. and 1.
-
Page 20: Setting The 1-Hour Off Timer
Setting the 1-Hour OFF Timer 1. 1-Hour OFF Timer This function causes the unit to operate for one hour and then stop, regardless of whether the unit is on or off when this button is pressed. indicator in the display indicates that this function is operating. Setting the 1-Hour OFF Timer: Regardless of whether the unit is operating or stopped, press the 1 HR. -
Page 21: Tips For Energy Saving
Setting the HIGH POWER Operation (continued) NOTE Concerning HIGH POWER During a heating operation • The room is heated for 15 minutes by warm air which has a slightly operations higher temperature than usual. • When the HIGH POWER button is pressed during a defrosting operation, the unit enters the HIGH POWER operating mode upon completion of the defrosting operation. -
Page 22: Operation Without The Remote Control Unit
Operation without the Remote Control Unit If you have lost the remote control unit or it has trouble, follow the steps below. 1. When the air conditioner is not running If you want to turn on the air conditioner, switch the operation selector to OPERATION the OFF position, and then to the ON position. -
Page 23: Troubleshooting
Troubleshooting If your air conditioner does not work properly, first check the following points before requesting service. If it still does not work properly, contact your dealer or service center. Trouble Possible Cause Remedy Air conditioner does not run 1. Power failure. 1.
