Jensen AL3000DGv3 Installation Manual

Power LED
WPS LED
WPS status LED.
Network ports LED
WPS LED is flashing when
Show status for devices
setting up a WPS connection.
that are connected to
the router by cable.
5GHz LED
2.4GHz LED
LED that show status
LED that show status
for the 5GHz network.
for the 2.4GHz network.
The LED's will flash when
The LED will flash when
active.
active.
Installation Guide
USB port
USB port for connecting
a printer or USB hard disk drive.
USB LED
Indicates if the USB port is correctly
connected.
Internet LED
LED that show status
for the Internet port.
The LED will flash when active.
Declaration of Conformity with Regard to EU Directive 1999/5/EC (R&TTE Directive):
Hereby, Jensen Scandinavia AS, declares that this wireless router is in compliance with
the essential requirements and other relevant provisions of Directive 1999/5/EC.
The declaration of confirmity may be consulted at www.jensenscandinavia.com/rtte/
Internet 1 2 3
Internet port
Please connect your
broadband modem
to the internet port.
Network ports
Ports for connecting network
devices by cable, such as computer,
TV, Media Server, Network printer,
VOIP adapter etc.
This equipment may be operated in all EU and EFTA countries: AT, BE, BG, CY, CZ, DK, EE, FI,
FR, DE, GR, HU, IS, IE, IT, LV,LI, LT, LU, MT, NL, NO, PL, PT, RO, SK, SI, ES, SE, CH, TR, GB
PRODUCT USAGE RESTRICTIONS: This product is intended for indoor use only.
Model: AL3000DGv3
4
Power connector
Reset / WPS*
Reset: Hold for about 7 seconds to
reset the router to factory default.
WPS: Hold for about to 1-2 seconds
to initiate WPS connection.
* WPS is disabled as default
and needed to be activated in
router GUI (http://192.168.38.1) before
use.
