- Page 1 Owner's Manual LED LCD MONITOR (LED MONITOR*) *LG LED Monitors are LCD Monitors with LED Backlighting. Please read the safety information carefully before using the product. LED LCD Monitor (LED Monitor) Model List 29UM69G 34UM69G www.lg.com...
-
Page 2: Table Of Contents
Moving and Lifting the Monitor SPECIFICATIONS Installing the Monitor 29UM69G - Assembling the stand base 34UM69G Installing the Monitor Factory Support Mode (Preset Mode, PC) - Assembling the stand base HDMI / DP Normal / USB-C - Using the cable holder... -
Page 3: License
LICENSE LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. VESA, VESA logo, DisplayPort compliance logo and DisplayPort compliance logo for dual-mode source devices are all registered trademarks of the Video Electronics Stan- dards Association. -
Page 4: Assembling And Preparing
The product warranty will not cover damage or injury caused by the use of counterfeit components. It is recommend that use the supplied components. If you use generic cables not certified by LG, the screen may not display or there may be image noises. NOTE Note that the components may look different from those shown here. -
Page 5: Supported Drivers And Software
ASSEMBLING AND PREPARING Supported Drivers and Software You can download and install the latest version from the LGE website (www.lg.com). Drivers and Software Installation Priority 29UM69G/34UM69G Monitor Driver Recommended OnScreen Control Recommended... -
Page 6: Component And Button Description
ASSEMBLING AND PREPARING Component and Button Description 29UM69G 34UM69G Joystick Button Power LED On: power is on Off: power is off How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with your finger. -
Page 7: Input Connector
ASSEMBLING AND PREPARING Input Connector 29UM69G 29UM69G 34UM69G 34UM69G... -
Page 8: Moving And Lifting The Monitor
Hold the top and bottom of the monitor frame firmly. Do not hold the screen itself. 34UM69G 34UM69G When holding the monitor, the screen should face away from you to prevent it being scratched. -
Page 9: Installing The Monitor
ASSEMBLING AND PREPARING Installing the Monitor Assembling the stand base Attach the Stand Base to Stand Body. Tighten the screw to the right. 29UM69G Place the screen face down. Stand Body Stand Base CAUTION To protect the screen from scratches, cover the Attach the screw cover. -
Page 10: Installing The Monitor
ASSEMBLING AND PREPARING Installing the Monitor Assembling the stand base 34UM69G Please put a soft cloth on a low table or box to protect the screen of the monitor. Please put the monitor on the soft cloth with the screen facing down. -
Page 11: Using The Cable Holder
Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this way will not be covered by the product warranty. cable holder NOTE 34UM69G You can disassemble the stand in the reverse order of the assembly. cable holder... -
Page 12: Installing Onto A Table
Place at least 100 mm away from the wall to ensure sufficient ventilation. 29UM69G 29UM69G 100 mm 100 mm 100 mm 100 mm 34UM69G 34UM69G 100 mm 100 mm 100 mm 100 mm Press the joystick button on the bottom of the monitor to turn on the monitor. -
Page 13: Adjusting The Angle
If you need another power cord, please contact your local dealer or the nearest retail store. Rear Side Front Side 34UM69G 20° -5° Rear Side Front Side... -
Page 14: Adjusting The Stand Height
ASSEMBLING AND PREPARING WARNING Adjusting the Stand Height To avoid injury to the fingers when adjusting the 34UM69G screen, do not hold the lower part of the moni- Handle the monitor with both hands for safety. tor's frame as illustrated below. -
Page 15: Using The Kensington Lock
To avoid injury when rotating the display, do not place your fingers between the display and the stand base. Monitor head 34UM69G Using the Kensington lock The Kensington security system connector is located at the back of the Monitor set. -
Page 16: Detaching The Stand Body
If you use improper screw, the product might be dam- aged and drop from mounted position. In this case, LG Electronics is not responsible for it. 29UM69G Installing the wall mount plate Wall Mount (A x B) - Page 17 Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Please use the genu- ine LG wall mounting bracket. For more informa- tion, contact your local retail store or a qualified installer.
-
Page 18: Using The Monitor
NOTE There may be no video or audio output depending on the DP version of the PC. If you use generic cables not certified by LG, the screen may not display or there may be image noises. NOTE If you use HDMI PC, it can cause compatibility problem. -
Page 19: Usb-C Connection
USING THE MONITOR Connecting to AV Devices USB-C connection Transmits digital video and audio signals from your PC HDMI connection to the monitor. Connect the monitor to your PC using the USB-C cable Transmits the digital video and audio signals from your as shown in the illustration below. -
Page 20: Connecting To External Devices
USING THE MONITOR Connecting to External Devices Connecting Headphones Connect peripherals to the monitor via the headphones port. Connect as illustrated. (sold separately) (sold separately) NOTE Peripheral devices are sold separately. If you use angled earphones, it may cause a prob- lem with connecting another external device to the monitor. -
Page 21: User Settings
User Settings USER SETTINGS Activating the Main Menu Press the joystick button on the bottom of the monitor. Move the joystick up/down ( ▲ / ▼ ) and left/right ( ◄ / ► ) to set the options. Press the joystick button once more to exit the main menu. Joystick Button Button Menu Status... -
Page 22: User Settings
User Settings User Settings Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Menu. Configure the options by moving the joystick up/down/left/right. To return to the upper menu or set other menu items, move the joystick to ◄ or pressing ( / Ok) it. - Page 23 User Settings Picture Mode Cinema Optimizes the screen for video. Color Weakness This mode is for users who cannot distinguish between red and green. It enables users with color weakness to easily distinguish between the two colors. FPS Game 1 This mode is optimized for FPS games.
- Page 24 User Settings Game Adjust Black Stabilizer You can control the black contrast to have better visibility in dark scenes. Increasing the Black Stabilizer value brightens the low gray level area on the screen. (You can easily distinguish objects on dark game screens.) Reducing the Black Stabilizer value darkens the low gray level area and increases the dy- namic contrast on the screen.
- Page 25 User Settings Menu > Sound Description Volume To adjust the Volume of headphone or speaker. ® ® MaxxAudio MaxxAudio by Waves, recipient of a Technical GRAMMY Award is a suite of studio- quality sound tools for a superior listening experience. Disables the MaxxAudio function.
-
Page 26: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Nothing is displayed on the screen. Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. Test the Power Plug using a lamp or other device. Is the power LED on? Check the power cable connection and press the power button. - Page 27 Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message? Have you installed the display driver? Be sure to install the display driver from our web site: http://www.lg.com. Make sure to check if the video card supports Plug&Play function.
-
Page 28: Specifications
SPECIFICATIONS SPECIFICATIONS 29UM69G LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Pixel Pitch 0.2628 mm x 0.2628 mm Resolution Maximum Resolution 2560×1080 @ 75 Hz Recommended Resolution 2560×1080 @ 60 Hz Video Signal Horizontal Frequency 30 kHz to 90 kHz Vertical Frequency 56 Hz to 75 Hz Input Connector... -
Page 29: 34Um69G
SPECIFICATIONS SPECIFICATIONS 34UM69G LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Pixel Pitch 0.312 mm x 0.310 mm Resolution Maximum Resolution 2560×1080 @ 75 Hz Recommended Resolution 2560×1080 @ 60 Hz Video Signal Horizontal Frequency 30 kHz to 90 kHz... -
Page 30: Hdmi / Dp Normal / Usb-C
SPECIFICATIONS Factory Support Mode (Preset Mode, PC) HDMI / DP Normal / USB-C Resolution Horizontal Vertical Polarity(H/V) Remarks (HDMI / DP / USB-C) Frequency(kHz) Frequency(Hz) 640 x 480 31.469 59.94 640 x 480 37.5 800 x 600 37.879 60.317 800 x 600 46.875 1024 x 768 48.363... - Page 31 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. MODEL SERIAL...
