  • Page 1 Camera Anti-Corrosion Thermal Network Bullet Camera Quick Start Guide...
  • Page 2 Quick Start Guide COPYRIGHT © 2017 Hangzhou Hikvision Digital Technology Co., Ltd. ALL RIGHTS RESERVED. Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed,...
  • Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
  • Page 4 Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for Class A device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union.
  • Page 6 Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent serious injury or death. potential injury or material damage. Warnings ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. ●...
  • Page 7 ● Make sure the power supply voltage is correct before using the camera. ● Do not drop the camera or subject it to physical shock. ● Do not touch sensor modules with fingers. If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently.
  • Page 8 recommended for all the users. Please contact with your dealer for more details. ● Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent type only. Dispose of used batteries according to the instructions provided by the battery manufacturer.

  • Page 9: Table Of Contents

    Table of Contents 1 Appearance Description .............. 9 1.1 Camera Appearance............. 9 1.2 Cable Description ............9 2 Installation .................. 11 2.1 Wide Range Coverage for Different Specifications .. 12 2.2 Installing Camera ............13 2.2.1 Wall Mounting ..........13 2.2.2 Installing Junction Box ........

  • Page 10: Appearance Description

    1 Appearance Description 1.1 Camera Appearance The overview of Anti-corrosion thermal network bullet camera and its components are shown below: Type I Camera Overview 1.2 Cable Description The bullet camera cables, including power cable, coaxial video cable, alarm cable, and audio cable are shown below.
  • Page 11 Cable Description Name Description Network Interface Connect to the LAN. PoE+ supported. Power Interface 12V DC power supply. Make sure that positive/negative terminals connected correctly. Alarm Interface Alarm In: IN and G, Alarm Out: 1A and 1B. BNC Interface Local video signal output Audio Interface Audio In: Pickup Audio Out: Loudspeaker...

  • Page 12: Installation

    2 Installation Before you start: Make sure the device in the package is in good ● condition and all the assembly parts are included. The standard power supply is 12V DC or 24V AC, ● please make sure your power supply matches your camera.

  • Page 13: Wide Range Coverage For Different Specifications

    2.1 Wide Range Coverage for Different Specifications Select the proper installation site, and proper lens focal length according to the Wide Range Coverage list below: Wide Range Coverage Lens (focal length) 10mm 15mm 25mm 35mm 50mm 75mm Detection range (Vehicles) 631m 902m 1353m 2255m 3157m 4510m 6765m...

  • Page 14: Installing Camera

    2.2 Installing Camera The anti-corrosion camera installation adopts 12V DC power supply. Pick appropriate site for junction box installation to ensure the stable power and water-proof performance. 2.2.1 Wall Mounting Steps: 1. Loosen the screws of the PT joint and separate the PT joint top from the PT joint bottom.
  • Page 15 Fix the Bracket Body 4). Adjust the bracket direction (pan range: -45° to +45° ). Adjust Bracket Direction 3. Fix the PT joint top with the camera with the 1/4UNC× 12 screw (with flat washer and spring washer).
  • Page 16 Camera PT Joint Top Fix the PT Joint Top with Camera 4. Fix the PT joint top with the PT joint bottom with M6× 12 screw (with flat washer and spring washer). 5. Adjust the camera direction (tilt range: -45° to +45° ). PT Joint Top Tilt Range (-45°...

  • Page 17: Installing Junction Box

    Finish the Installation 2.2.2 Installing Junction Box Steps: 1. Attach the drill template (supplied) to the place where you want to fix the junction box, and then drill the screw holes in the wall according to the drill template. 270 mm (10.6'') 120 mm (4.7'') Drill Template (Junction Box)
  • Page 18 2. Use the Allen wrench to loosen the four screws of the junction box cover. Disassemble Junction Box Cover 3. Align the screw holes to the drill template and install the junction box with four PA5× 25 screws. 4. Connect the cables. 1) Loosen the waterproof nut with camera silk-screen on it, and take away the sealing ring.
  • Page 19 2) Route the cables (including network cable, alarm cable, audio cable, power cable, etc.) into the cable hole. Save the sealing ring for future usage.  To ensure the sealing performance, we provide you with  multiple sealing plugs. Select the appropriate sealing plug according to your cable type.
  • Page 20 6) Connect the power cables and other cables with negative terminal and positive terminal correctly. 5. After the connection, install the sealing ring, washer, bolt, and tighten the water-proof screw. 6. Fix the junction box cover with the supplied screws. Fix the Junction Box...

  • Page 21: Installation Of Network Cable Water-Proof Jacket

    Installation of Network Cable Water-proof Jacket Purpose: If the camera is installed outdoor, you can adapt the water-proof accessory for the network cable after the camera is secured on the installation surface. Water-proof Accessory Components Table 2-1 Components Components Camera’s Network Interface Socket O-Type Gasket Network Plug Waterproof Endcap...
  • Page 22 Align the snap and notch. i. Insert into ⑤ ④ ii. Secure with ⑥ ④ Camera Switch/Router Water-proof Accessory Installation Steps: 1. Feed the plugless network cable through the lock nut ⑦ ⑥ waterproof rubber gasket ⑤ (rubber gasket inset ridge must face waterproof endcap), and the water-proof endcap ④...
  • Page 23 4. Insert the network plug into the camera’s network ③ interface socket ① 5. Insert the water-proof rubber gasket into the waterproof ⑤ endcap , and secure lock nut with the water-proof ④ ⑥ endcap ④ 6. Align the snap on the water-proof endcap ④...

  • Page 24: Setting The Network Camera Over The Lan

    3 Setting the Network Camera over the LAN Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. If the product does not work properly, please contact with your dealer or the nearest service center.

  • Page 25: Activating The Camera

    3.2 Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.

  • Page 26: Activation Via Sadp Software

    3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 27 SADP Interface Note: The SADP software supports activating the camera in batch. Please refer to the user manual of SADP software for details. 3. Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters,...

  • Page 28: Modifying The Ip Address

    3.3 Modifying the IP Address Purpose: To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. Then, install the SADP software or client software to search and change the IP of network camera. We will take modifying the IP Address via SADP software as an example to introduce the IP address modification.
  • Page 29 4. Input the password to activate your IP address modification. The batch IP address modification is supported by the SADP; please refer to the User Manual of SADP for details.

  • Page 30: Accessing Via Web Browser

    4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version. CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024× 768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 31 Click Login. Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. You may have to close the web browser to finish the installation of the plug-in. Download Plug-in...
  • Page 32 Install Plug-in (1) Install Plug-in (2) 6. Reopen the web browser after the installation of the plug-in and repeat steps 2~4 to login. For detailed instructions of further configuration, please refer to the user manual of network camera.

  • Page 33: Appendix

    Appendix Frequently Asked Questions (FAQ) Device Running Error Question: The device fails to start up or reboots repeatedly.  Answer: Examine the power supply of the positioning  system and see whether it meets the requirements. Select the power supply as close as possible. ...
  • Page 34 Examine if any obstruction is nearby, e.g. spider  web. Question: Live view fails with good network connection. Answer: Examine if the IE plug-in is well installed. Change  the Website Blocker settings if necessary. For cross-domain routing, enable the UPnP of ...

  • Page 35: Common Material Emissivity Reference

    Common Material Emissivity Reference Material Temperature (° C/° F) Emissivity Water 0 to 100/32 to 212 0.95~0.98 Soil (Dry) 20/68 0.92 Soil (Moist) 20/68 0.95 Wood 17/62.6 0.962 Sand 20/68 Sandstone 19/66.2 0.909~0.935 PVC (Polyvinyl Chloride) 70/158 0.93 Pitch 20/68 0.967 Paint 70/158...
  • Page 36 UD06594B...
