AIB
BEL T DRIVE
TUBEAXIALS
IN-LINE FANS
•
Spark resistant, cast aluminum airfoil axial impeller
•
Aerodynamically efficient performance
•
Factory set adjustable pitch blades
•
Heavy duty welded steel construction
•
TEFC industrial duty motor
•
Mountable in ductwork in any position
•
Sizes range from 12" to 60"
•
Belt drive capacities to 54,000 cfm
Advertisement
Related Manuals for CFM AIB-1006
Summary of Contents for CFM AIB-1006
- Page 1 Aerodynamically efficient performance • Factory set adjustable pitch blades • Heavy duty welded steel construction • TEFC industrial duty motor • Mountable in ductwork in any position • Sizes range from 12” to 60” • Belt drive capacities to 54,000 cfm...
- Page 2 AIB BELT DRIVE TUBEAXIAL FANS STANDARD FEATURES & BENEFITS • Spark resistant, cast aluminum airfoil axial impeller • Factory set adjustable pitch blades • Aerodynamically efficient performance • Heavy duty welded steel and angle ring construction • Air dried enamel paint finish •...
- Page 3 B. Fan motor base shall be adjustable, and be located on the exterior of the fan housing. C. Fan belt tube shall be completely sealed, and shall isolate the bearings from ambient and/or contaminated airstreams. D. Fan housing and motor base shall be coated with an air dried gray enamel finish.
- Page 4 AIB BELT DRIVE TUBEAXIALS...
