Specifi cations
Product Specifi cations
LCD Module
Frequency
Pixel Clock
Viewable Size
Input Signal
DVI DVI-D 24pin
DisplayPort DisplayPort Connector
VGA* 2 15pin Mini D-sub
HDMI HDMI Connector
DVD/HD* 2 15pin Mini D-sub
VIDEO1 BNC
VIDEO2* 2 15pin Mini D-sub
S-VIDEO* 2 15pin Mini D-sub
Output Signal
DVI DVI-D 24pin
AUDIO
AUDIO STEREO Mini Jack
Input
HDMI Connector
DisplayPort Connector
AUDIO STEREO Mini Jack
Output
Speaker Output
Control
Power Supply
Operational Environment
Storage Environment
Dimension
Weight
Detection method
Operating system
Multi-touch
PC connector
Protective glass
VESA compatible mounting interface
Power Management
Plug & Play
Power supply for Slot 2 type OPTION
Accessories
NOTE: Technical specifi cations are subject to change without notice.
42"/106.7 cm diagonal
Pixel Pitch: 0.485 mm
Resolution: 1920 x 1080
Color: Over 16 million colors (depending on display card used)
2
Brightness: 430 cd/m (Max.), 310 cd/m
Contrast Ratio: 1300:1
Viewing Angle: 87° (typ) @ CR>10
Horizontal: 15.625/15.734 kHz, 31.5 kHz - 91.1 kHz (Analog Input)
31.5 kHz - 91.1 kHz (Digital Input)
Vertical: 50.0 - 85.0 Hz
25.2 MHz - 162.0 MHz
930.2 x 523.3 mm
Digital RGB DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Digital RGB DisplayPort Complies with Standard V1.1a, applicable to HDCP V1.3
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz
Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
Digital YUV HDMI
Digital RGB VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
Composite 1.0 Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
S-VIDEO Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)
NTSC/PAL/SECAM/4.43NTSC/PAL60
Digital RGB DVI (HDCP)
Analog Audio Stereo L/R 0.5 Vrms
Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
Analog Audio Stereo L/R 0.5 Vrms
External Speaker Jack 15 W + 15 W (8 ohm)
Internal Speaker 10 W + 10 W
RS-232C In: 9 Pin D-sub
RS-232C Out: 9 Pin D-sub (with daisy chain)
LAN: RJ-45 10/100 BASE-T
Remote IN: Stereo Mini jack 3.5
2.4 - 1.0 A @ 100-240V AC, 50/60Hz
Temperature* 3 : 0 - 35°C / 32 - 95°F
Humidity: 20 - 80% (without condensation)
Altitude: 0 - 3000 m (Brightness may decrease with altitude)
Temperature: -20 - 60°C / -4 - 140°F
Humidity: 10 - 90% (without condensation) / 90% - 3.5% x (Temp - 40°C) regarding over 40°C
1008 (W) x 601 (H) x 83.5 (D) mm / 39.7 (W) x 23.7 (H) x 3.3 (D) inches
24.7 kg (54.5 lbs)
Optical imaging method
Windows 7, Windows Vista, Windows XP
More than 2 touches with Windows 7 (limited accuracy)
USB V2.0
Material: Full-tempered glass
Thickness: 4.0 mm
Surface treatment: Anti-Refl ective coating (both inside and outside)
Transparency: More than 96%
≤ 2%
Refl ection rate:
Surface hardness: 8 H
4
Impact resistance* : 130 cm
300 mm x 300 mm (M6, 4 Holes)
VESA DPM
VESA DDC2B, DDC/CI, DisplayPort
16V/3.8 A
Setup manual, Power Cord, Video Signal cable, Remote Control, AA Battery x 2, Clamp x 1,
Screw x 1, CD-ROM, USB cable
*3: When you use option board accessories, please contact your supplier for detailed information.
English-41
2
(Factory setting Typ.) @25°C
1 , 1920X1080 (60Hz), 1080p, 1080i
1
, 1920x1080 (60 Hz), 1080p, 1080i,
1
, 1920X1080 (60Hz)
1
, 1920x1080 (60 Hz), 1080p, 1080i,
*4: The distance of a steel ball (weight: 500 g) in one free fall without breaking.
*1: Compressed image.
*2: Common terminal.
