Home Accents Holiday TGC0P5402L03 Assembly Instructions

TM

Safety Information

IMPORTANT SAFETY
INSTRUCTIONS
When using electrical products, basic precautions should
always be followed, including the following:
READ AND FOLLOW ALL
a.
SAFETY INSTRUCTIONS.
b. Do not use seasonal products outdoors unless marked
suitable for indoor and outdoor use. When products are
used in outdoor applications, connect the product to a
Ground Fault Circuit Interrupting (GFCI) outlet. If one is
not provided, contact a qualified electrician for proper
installation.
c. This seasonal product is not intended for permanent
installation or use.
d. Do not mount or place the product near gas or electric
heaters, fireplaces, candles, or other similar sources of heat.
e. Do not secure the wiring of the product with staples or
nails, or place on sharp hooks or nails.
f. Do not let lamps rest on the supply cord or on any wire.
g. Unplug the product when leaving the house, when
retiring for the night, or if left unattended.
h. This is an electric product and not a toy! To avoid risk of
fire, burns, personal injury and electric shock it should not
be played with or placed where small children can reach it.
i. Do not use this product for other than its intended use.
j. Do not hang ornaments or other objects from cord, wire,
or light string.
k. Do not close doors or windows on the product or exten
sions cords as this may damage the wire insulation.
l. Do not cover the product with cloth, paper, or any
material that is not a part of the product when in use.
m. This product is equipped with push-in type lamps. Do not
twist lamps.
n. Read and follow all instructions that are on the product
or provide with the product.
SAVE THESE INSTRUCTIONS
o.

USER SERVICING INSTRUCTIONS

LAMP REPLACEMENT

Step 1. Grasp the power adapter or power cord plug, and than
unplug from the power outlet. Do not pull the power cord.
Step 2. Lift up lamp lock tab, then pull the
lamp and plastic lamp base straight
out of the lamp-holder.
Step 3. Replace with a new spare lamp
provided with this product.
( Reference figure only)

Assembly

Assembling the tree stand

Step 1. Pull apart the legs of the stand so that they are snapped
into an x-shape, place the tree stand on a level surface.
Step 2. When inserting the bottom section of the tree into the
assembled stand, insert and turn the eyebolts into the
stand and tighten until the tree pole is firmly secured.
To close the stand, remove the eyebolts, press the metal button and
fold the legs together.
Eye Bolt

Assembling the tree

This tree assmebles with Quick Set® technology
---Set up and light up your tree in less than 10 minutes!
Step 1.
Remove the protective caps from the tree bottom and insert
the pole into the tree stand.
Step 2.
Continue by inserting the upper tree section(s) to
the lower section(s) until inserting the tree top.
Step 3.
Shape the branches to your preference by working from the
bottom to the top. When adjusting branches, ensure that all
wires are free of branch hinges.
Step 4.
Insert the adaptor into the wall outlet. All your lights should
now be lit.
Step 5.
Shape the tree from the bottom to the top. Start with the
branches farthest from the pole – fan out in a star shape, and
continue until the entire tree is shaped.
Top view
Step 6.
When finished shaping the branches, slightly upsweep all
branch tips for a uniform look.
Tree top
100S
50S
50S
Section 4
90S
90S
50S
Section 3
90S
90S
60S
Section 2
80S
80S
100S
Section 1
100S
Christmas Tree
Model: TGC0P5402L03
Sku #1003 143 233
Eye Bolt
Click
Side view
Do Not Tamper
Internal Parts
Open the
protective
cover
Do Not Tamper
Internal Parts
Open the
protective
cover
Adaptor
To Be Plugged
Into Wall
Outlet
Foot Pedal
on/off Switch
