P/N 127026-01 Rev. D 01/2019
P127026-01
This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also
contains information that will enable you to obtain replacement parts or accessory items when needed. Keep
it with your other important papers.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Refer to this manual for correct installation and operational procedures. For assistance or
additional information consult a qualified installer, service agency or the gas supplier.
This fireplace is approved for use on an outdoor application provided that a certified gas log set approved under
the ANSI Z21.97 standard with a maximum input rate of 40,000 BTU's is used. An IHP hood must be installed
when using a vent-free log heater (see Parts, page 15).
DO NOT INSTALL THE APPLIANCE IN THIS FIREBOX, UNLESS THIS FIREBOX MEETS THE MINIMUM DIMEN-
SIONS REQUIRED FOR THE INSTALLATION.
WARNING: FOR USE ONLY WITH A LISTED, GAS-FIRED UNVENTED DECORATIVE ROOM HEATER NOT TO
EXCEED 40,000 BTU/H.
DO NOT BUILD A WOOD FIRE.
WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result
causing property damage, personal injury or death.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
PFS
®
US
Report No. F09-130
SAVE THIS BOOK
Installation and Operation Instructions
Outdoor Universal Vent-Free Firebox
With Masonry Brick Walls
Models
VRE6036RS
VRE6042RS
VRE6036IS
VRE6036RH
VRE6042RH
VRE6036IH
VRE6050RS
VRE6042IS
VRE6050IS
VRE6050RH
VRE6042IH
VRE6050IH
Advertisement
Table of Contents
Related Manuals for Superior Fireplaces VRE6036RS
Summary of Contents for Superior Fireplaces VRE6036RS
- Page 1 Installation and Operation Instructions Outdoor Universal Vent-Free Firebox With Masonry Brick Walls Models VRE6036RS VRE6042RS VRE6050RS P/N 127026-01 Rev. D 01/2019 VRE6036IS VRE6042IS ® VRE6050IS VRE6036RH VRE6042RH VRE6050RH VRE6036IH VRE6042IH VRE6050IH Report No. F09-130 P127026-01 SAVE THIS BOOK This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also contains information that will enable you to obtain replacement parts or accessory items when needed.
-
Page 2: Table Of Contents
Thank you for your purchase. We appreciate your TABLE OF CONTENTS business! Safety ..................... 2 Please carefully read and follow all instructions in this manual. Pay Local Codes ................... 3 special attention to all warnings and safety information. Product Features ................3 Following these safety, care, and operation instructions will help Requirements for the Commonwealth of Massachusetts.... -
Page 3: Local Codes
SAFETY Continued PRODUCT FEATURES OPERATION You must operate this fireplace with the provided This firebox is designed for use with approved ANSI Z21.11.2 deco- fireplace screen and hood in place. Make sure these rative type unvented room heaters. (Physical size limitations apply. parts are in place and screens are closed before run- Refer to minimum firebox requirements supplied with log heater.) ning installed gas log heater. -
Page 4: Product Specifications
36" MODELS " 29" 19" " " (Ref.) " " " " 36" HEARTH " " 50" 30" " " " 7" " 36" " " " Figure 1 - 36" Models - VRE6036RS, VRE6036IS, VRE6036RH and VRE6036IH SuperiorFireplaces.us.com 127026-01_D... - Page 5 PRODUCT SPECIFICATIONS continued 42" MODELS " " " 23" (Ref.) " " " " " 42" HEARTH " " 50" 30" " " 7" " " 42" " " 13" Figure 2 - 42" Models - VRE6042RS, VRE6042IS, VRE6042RH and VRE6042IH 127026-01_D SuperiorFireplaces.us.com...
- Page 6 PRODUCT SPECIFICATIONS continued 50" MODELS " " " " 23" (Ref.) " " " 50" HEARTH " " 50" 30" " " " 7" " 50" " " 13" Figure 3 - 50" Models - VRE6050RS, VRE6050IS, VRE6050RH and VRE6050IH SuperiorFireplaces.us.com 127026-01_D...
-
Page 7: Air For Combustion And Ventilation
AIR FOR COMBUSTION AND VENTILATION Confined and Unconfined Space WARNING: This firebox shall not be installed in a The National Fuel Gas Code, ANSI Z223.1/NFPA 54 defines a confined room or space unless the required volume of indoor space as a space whose volume is less than 50 cubic feet per 1,000 combustion air is provided by the method described Btu per hour (4.8 m per kw) of the aggregate input rating of all ap-... - Page 8 AIR FOR COMBUSTION AND VENTILATION continued The space in the example is a confined space because the actual Btu/ Ventilation Air From Outdoors Hr used is more than the maximum Btu/Hr the space can support. Provide extra fresh air by using ventilation grills or ducts. You must You must provide additional fresh air.
-
Page 9: Installation
INSTALLATION INSTALLATION CLEARANCES WARNING: A qualified service person must install firebox. Follow all local codes. WARNING: Maintain the minimum clearances. If you can, provide greater clearances from floor, ceil- WARNING: Never install firebox ing, and adjoining wall. • in a bedroom or bathroom* •... - Page 10 INSTALLATION continued Mantel Clearances for Built-In Installation BUILT-IN FIREBOX INSTALLATION If placing custom mantel above built-in firebox, you must meet Built-in installation of this firebox involves installing firebox into a the minimum allowable clearance between mantel shelf and top of framed-in enclosure.
- Page 11 INSTALLATION continued IMPORTANT: When finishing your firebox, combustible materials such 1. Assemble cabinet mantel as instructed. as wall board, gypsum board, sheet rock, drywall, plywood, etc. may 2. Install gas piping to firebox location. See Gas Line Installation on be butted up next to the sides and top of the firebox. Combustible page 13.
- Page 12 INSTALLATION Continued FIREBRICK WALL INSTALLATION Retaining Bracket IMPORTANT: Installation of brick should be done after the fireplace is placed in a permanent location. 1. The fireplace is shipped with the hearth preinstalled. It is held in place for shipping with 3 shipping brackets (Figure 13). Remove these brackets before installing any of the other firebrick walls.
- Page 13 INSTALLATION Continued INSTALLING FIREPLACE HOOD AND SCREENS Note: Secure incoming gas line to wood framing to provide rigidity for threaded end. 1. Attach hood to firebox using screws provided (see Figure 16). 4. Repack insulation around gas line and into sleeve opening. Seal any 1.
-
Page 14: Parts
PARTS MODEL NO. CATALOG NO. VRE6036RS F0461 VRE6036IS F0462 VRE6036RH F0463 VRE6036IH F0464 VRE6042RS F0465 VRE6042IS F0466 VRE6042RH F0467 VRE6042IH F0468 VRE6050RS F0469 VRE6050IS F0470 VRE6050RH F0471 VRE6050IH F0472 15/16 15/16 SuperiorFireplaces.us.com 127026-01_D... - Page 15 18 of this manual. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. Use of non-approved parts can result in poor performance and safety hazards. VRE6036RS VRE6042RS VRE6050RS VRE6036IS...
- Page 16 IMPORTANT: Installation of brick panels should be done after the fireplace is placed in a permanent location. LIFTING HAZARD SINGLE -PERSON LIFT COULD MODEL NO. CATALOG NO. CAUSE INJURY. VRE6036RS F0461 USE ASSISTANCE WHEN MOVING VRE6036IS F0462 VRE6036RH F0463 OR LIFTING.
- Page 17 PARTS This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 18 of this manual. VRE6036RS VRE6036RH VRE6042RS VRE6042RH VRE6050RS VRE6050RH NO. CATALOG NO. DESCRIPTION (F0461) (F0463) (F0465) (F0467)
-
Page 18: Technical Service
TECHNICAL SERVICE REPLACEMENT PARTS Continued You may have further questions about installation, operation, or When ordering repair parts, always give the following information: troubleshooting. Please contact your IHP dealer for any questions 1. The model number of the fireplace. or concerns a. When contacting your dealer please have your model 2. -
Page 19: Warranty
Innovative Hearth Products Superior Brand Gas Fireplaces, Stoves and Inserts ® 20 Year Limited Warranty THE WARRANTY Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Superior Brand gas fireplace, Stove or Insert ("Product") to be free from defects in materials ®... - Page 20 SuperiorFireplaces.us.com Record the following important information about your fireplace: Fireplace model number Fireplace serial number Date fireplace was Installed Type of gas fireplace uses Dealer name P127026-01 Innovative Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
