LEK-431/432 APP
User manual
Model
Programs
Remote controller
Light source type
CRI (Ra>):
IP rating
Light colour mode
Working voltage
Power
Material of housing
Light engine dimensions
Net weight
Fibre optic port diameter
Maximum number of fibre optic
bundles at 0.75 mm diameter
Lifetime
Warranty
Package dimensions (excluding
fibre optic bundle)
Weight with packaging
www.stellarlighting.co.uk
email: info@stellarlighting.co.uk
LEK-431 APP
LEK-431 APP
Speed, brightness, 20 colour changing programs, music sync mode, twinkling
wheel speed, on/off
Yes, RF and Bluetooth app
LED CREE
70
IP33
RGBW
DC 12 V
13 W
Aluminium
126 mm (L) x 125 mm (W) x 88 mm (H)
0.85 kg
17.3 mm
400
50,000 hours
2 years
192 mm (L) x 160 mm (W) x 95 mm (H)
0.9 kg
LEK-432 APP
LEK-432 APP
25 W
2 x 17.3 mm
2 x 400
1
Advertisement
Related Manuals for Stellar Lighting LEK-431 APP
Summary of Contents for Stellar Lighting LEK-431 APP
- Page 1 LEK-431/432 APP User manual LEK-431 APP LEK-432 APP Model LEK-431 APP LEK-432 APP Speed, brightness, 20 colour changing programs, music sync mode, twinkling Programs wheel speed, on/off Remote controller Yes, RF and Bluetooth app Light source type LED CREE CRI (Ra>):...
-
Page 2: Safety Notices
LEK-431/432 APP User manual Safety notices Electrical work safety advice and tips ● Make sure the input voltage is correct. ● Avoid placing the light engine in the rain or in moist areas. Please ensure that the light engine has sufficient ventilation and is not placed in a completely sealed area. - Page 3 LEK-431/432 APP User manual Connection method between optical fibres and the light engine Your fibre optic bundle will come with the connector fittings ready to connect to the light engine. If you need to 1. Align all the optical fibre ends and fasten with tapes which can resist temperature over 130℃ 2.
-
Page 4: Remote Controller Operation
LEK-431/432 APP User manual Remote controller operation Troubleshooting for remote controller connection issues: • • Check if the battery is operational in the remote controller: Press a button on the remote and the t there is either no battery in the remote or the battery needs replacing. - Page 5 LEK-431/432 APP User manual -pairing the remote • Pairing your remote controller with the light engine: 1. Make sure the light engine is switched off range. 3. The light engine will flash in white if the pairing was successful. Bluetooth App control guide 1.
- Page 6 LEK-431/432 APP User manual 3. Operation and modes www.stellarlighting.co.uk email: info@stellarlighting.co.uk...
- Page 7 LEK-431/432 APP User manual Static mode Dynamic mode Music mode Twinkling mode Meteor mode* 4. Bluetooth connection settings b. Rename connected devices in the App www.stellarlighting.co.uk email: info@stellarlighting.co.uk...
- Page 8 LEK-431/432 APP User manual c. Group devices in the App www.stellarlighting.co.uk email: info@stellarlighting.co.uk...
- Page 9 LEK-431/432 APP User manual 5. Troubleshooting for Bluetooth connection issues • Check that the light engine is powered on. • Check that the Bluetooth is turned on the mobile device. • Check if another mobile phone is already connected to the light engine. If another mobile phone is already connected to the light engine, disconnect it first.
