VSPOE-SWA24 /
VSPOE-SWA16
User Manual
Important Safeguard and Warning
Please read the following safeguards and warnings carefully before using the
product in order to avoid damages and losses.
Attentions:
• Do not expose the device to lampblack, steam or dust. Otherwise it may cause
fire or electric shock.
• Do not install the device at position exposed to sunlight or in high temperature.
• Temperature rise in device may cause fire.
• Do not expose the device to humid environment. Otherwise it may cause fire.
• The device must be installed on solid and flat surface in order to guarantee
safety under load and earthquake. Otherwise, it may cause device to fall off or
turnover.
• Do not place the device on carpet or quilt.
• Do not block air vent of the device or ventilation around the device. Otherwise,
temperature in device will rise and may cause fire.
• Do not place any object on the device.
• Do not disassemble the device without professional instruction.
Warning:
• Please use battery properly to avoid fire, explosion and other dangers.
• Please replace used battery with battery of the same type.
• Do not use power line other than the one specified. Please use it properly.
Otherwise, it may cause fire or electric shock.
Special Announcement:
• This manual is for reference only.
• All the designs and software here are subject to change without prior written
notice.
• Always follow the instructions listed on the manual. We are not liable for any
problems caused by unauthorized modifications or attempted repair.
• All trademarks and registered trademarks are the properties of their respective
owners.
• If there is any uncertainty or controversy, please refer to the final explanation
of us.
• Please visit our website for more information.
Advertisement
Table of Contents
Related Manuals for Vip-Vision VSPOE-SWA24
Summary of Contents for Vip-Vision VSPOE-SWA24
- Page 1 Important Safeguard and Warning Please read the following safeguards and warnings carefully before using the product in order to avoid damages and losses. VSPOE-SWA24 / Attentions: • Do not expose the device to lampblack, steam or dust. Otherwise it may cause fire or electric shock.
-
Page 2: Table Of Contents
©r------------------' 16/24-Port PoE Switch 6 De v ice Management ..............22 6.1 Rin g Networ k ··················································································································· 22 Table of Contents 6.1.1 STP Definition········································································································· 22 6.1.2 Basic Conce p ts of STP ························································································ 23 6.1.3 STP Brid g e Settin g s····························································································· 24 6.1.4 STP Port Se ttin g s ...... -
Page 3: Overview
• Provide web-based layer 2 network management. • Support 250m long distance transmission. Figure 2-1 • Support 2*1 ODOM Combo ports. Refer to table 2-1 for the front panel description of VSPOE-SWA24. • Support 16/24*10/100M self-adaptive RJ45 ports. Parameter Note •... -
Page 4: Log In Switch
©f---------------� 16/24-Port PoE Switch Refer to table 2-2 for the description of rear panel. Parameter Note Power switch Control device power on and off Support AC 100 - 240 V Power Input Log in Switch Ground terminal Ground wire Table 2-2 =�... -
Page 5: Port Info Display Section
©r------------------' 16/24-Port PoE Switch As it is shown in Figure 3-2, the whole WEB management interface is divided into several parts which includes device info display section, navigation bar, and config section etc. 3.2.1 Port Info Display Section System Config It is shown in Figure 3-3 that port info display is divided into WAN port state display and �... -
Page 6: Current Time
©r------------------' 16/24-Port PoE Switch 4.1.2 Current Time Refer to Figure 4-5 for the IP config interface, where you can check the device IP address, subnet mask, default gateway and MAC address. The default IP of switch is 192.168.1.110, Refer to Figure 4-3 for the display interface of switch system time, where you can set the which can be modified in this interface. -
Page 7: Software Upgrade
©r------------------' 16/24-Port PoE Switch Figure 4-10 Figure 4-7 4.7 System Reboot b. Click "Save" . It needs to save the config before rebooting the device. Otherwise, all the configurations 4.4 Software Upgrade will be lost after reboot. You need to log in the device WEB interface again after device reboot. -
Page 8: Port Management
©f---------------� 16/24-Port PoE Switch • Speed-current: It displays the current speed status of the port. Refer to table 5-3 for the port speed duplex display. Port Current speed Speed duplex mode Port Management Ethernet port Auto(default) Auto-negotiation mode 10M FULL 10M Full duplex 10M HALF 10M Half duplex... -
Page 9: Port Statistics
■ ©r------------------' 16/24-Port PoE Switch System Config Port Mirroring Port Management > Monitored Packets lngress&Egress Monitored Packets Disable Port Conflgurallon Dest Pon Port Mil'l'oring > PortStatistics Srt::Port > Port Speed Limit > Broad�asl Storm Control > Long Distance Device Management Save Refresh Save... -
Page 10: Port Speed Limit
©r------------------' 16/24-Port PoE Switch 5.4 Port Speed Limit Here is to set port speed limit parameters, restrict bandwidth of inbound/outbound data packets. See Figure 5-5. Port Speed Limit Figure 5-6 ( 2) Click Save button. 5.5 Broadcast Storm Control The broadcast storm refers to a phenomenon: the broadcast frames on the network are forwarded again and again, which affects the proper communications. -
Page 11: Long Distance Transmit
©r------------------' 16/24-Port PoE Switch Refer to Table 5-7 for broadcast control parameters. Long Distonce Name Note Ei11ti;mg Lon; D,1tan�1 Httnds 1M maximooi dl111nc1 ltDm 1oom to 2� Howtvu 1n.,w11 dropt�• tonnKtion t,pffd from tOOMbp:s.:ci 101,lbps Threshold The broadcast packets limit of one port during the specified period. Port name. -
Page 12: Device Management
@>---------------� 16/24-Port PoE Switch • Hello time: The period cycle of Bridge Root sending BPDU. • Forward delay: It means the time of maintaining snoop and study status before sending data package after topology is changed. Device Management 6.1.2 Basic Concepts of STP Bridge Identifier: it is the comprehensive numerical value of bridge priority and its MAC address, and the bridge priority is a parameter which can be set. -
Page 13: Stp Bridge Settings
©r------------------' 16/24-Port PoE Switch • STP Mode: Enable or disable ring network function. Switch A • Bridge Priority: Set bridge priority, it ranges from O to 61440. Ponl • Hello Time: Set the period of Root Bridge sending BPDU, it ranges from 1 s to 1 Os. •... - Page 14 ©r------------------' 16/24-Port PoE Switch 6.2.3 802.1 Q VLAN Port Type For frames without Tag For frames with Tag For the frames to be sent out The frames of the switch have tag frame and untag frame. Refer to the following figure for tag When the VLAN ID is in When VLAN ID is the same as the Trunk...
-
Page 15: Link Aggregation
©r------------------' 16/24-Port PoE Switch Please refer to Figure 6- 7. • Aggregation Group It is an assembly of a group of Ethernet ports. The supported number of aggregation groups is three by default, which can't be modified. The default status of all the aggregation groups is disable, member port is null by default. -
Page 16: Qos Settings
10014)1QM. (l()O}{tlOtJt50M)>lOOll ©r------------------' 16/24-Port PoE Switch The config parameter of LACP protocol mainly includes port LACP function enable, key In traditional no QoS IP network, the device treats all packets as the same and the process value, activity (active/passive mode) and timeout config. policy is first in first out (FIFO). -
Page 17: Congestion Settlement
©r------------------' 16/24-Port PoE Switch • The congestion consumes huge amount of network resources (especially storage resources), Refer to Table 6-3 for priority mode information. improper resources allocation may result in system down. Name Note So, we can see the congestion prevents the flows getting the resources in time and it is the First In First Out (FIFO) The first received packet will be forwarded first. -
Page 18: Tcp/Udp Port
©r--------------- 16/24-Port PoE Switch 6.4.6 TCP/UDP Port Byte Byte Byte Byte TCP and UDP adopt 16bit port to recognize the applications. The server usually uses the port to recognize. For example, the TCP port of the FTP server is the 21, TCP port of each TPID(Tag protocol identifier) -
Page 19: Security
Dis-able D1Hble ©r------------------' 16/24-Port PoE Switch 6.5 Security 2. Settings ( 1 ) Set the device mode is all-high-before-low mode MAC (Media Access Control) records the relationship between the MAC address and the port, and port belonging VLAN information and etc. 6.5.1 MAC Address List When device forwards the packet, it searches the MAC address sheet according to the packet destination MAC address. -
Page 20: Port Mac Filtering
©.-------------------' 16/24-Port PoE Switch When NMS manages the device, it pays great attention on some parameters such as port ( 3) Select the port whose connection status is green, and then click Bind button. See status, CPU usage rate and etc. All these parameters together are called the Management Information Base (MIB). -
Page 21: Snmp
192. 168. 1. 2 ©r------------------' 16/24-Port PoE Swit ch • SNMPv2 adopts the community name to certify. SNMPv2c has expand the functions of Refer to Table 6-6 for detailed information. the SNMPv1. It provides more operation types and supports more data types, provides Name Note abundant error codes and can accurately distinguish the errors. -
Page 22: 802.1X
192. 168. 1. 3 ©r------------------' 16/24-Port PoE Switch ( 10 ) Authentication mode is "Md5" . System Config ( 11 ) Encryption password is "admin123" Pon Management Device Management ( 12) Encryption mode is "CBC-DES" ( 13) Encryption password is "admin123" >... -
Page 23: 802.1Xauthentication Controlled/Uncontrolled Port
©r------------------' 16/24-Port PoE Switch • Client is the user terminal device which requires for LAN access, which is authenticated by • Unicast trigger: when the device receives unknown packet from source MAC address, it the device end in the LAN. The client has to install client software which supports 802.1x will actively send Identity-typed request packet to the MAC address unicast in order to authentication. -
Page 24: Igmp Snooping
©r------------------' 16/24-Port PoE Switch 7.1 PoE Settings Fi g ure 6-35 Power over Ethernet (PoE) means the device uses the Ethernet port to provide power to the device via the twisted pair cable remotely. The PoE function realizes the centralized power 6.8 IGMP Snooping supplying and easy to backup. -
Page 25: Poe Events
@------------------J 16/24-Port PoE Switch 7.2 PoE Event Statistics Note: The power supplying mode is depending on the PD specifications. The selected mode shall supports PSE and PD at the same time. If the PSE and the PD power supplying mode are not the same (such as the PSE does not support the spare wire power supplying, or the PD supports spare wire supplying only), please use converter to provide power to the PD. - Page 26 @--------------------J 16/24-Port PoE Switch Refer to Table 7-3 for detailed Green PoE setup information. Name Note PoE off time The single port input current has exceeded its output port current threshold. Po E on time The sending port is short-circuit when the chip is proving power to the port. The ports to be selected.
