- Page 1 382-403H WHEELCHAIR SWING Installation Guide INSTALLATION INSTRUCTIONS 382-403H ACCESSIBLE WHEELCHAIR SWING Please read the entire manual before beginning installation. 1 CTN 7 PIPE 2 WF 10 TOTAL PCS 155# WEIGHT CLASS...
- Page 2 382-403H WHEELCHAIR SWING Installation Guide...
- Page 3 382-403H WHEELCHAIR SWING Installation Guide dm 04-30-20...
- Page 4 382-403H WHEELCHAIR SWING Installation Guide Important Also note any obvious damage to the packing materials, pallets or components on the BOL. Please read completely before beginning installation. Equipment should be inventoried and installed within a few days of This equipment has been designed for safety as well as challenge and fun. This receipt.
- Page 5 382-403H WHEELCHAIR SWING Installation Guide Before you begin Review your swing footing and top view drawings to ensure your site is large enough. Read through the entire instruction booklet before beginning the actual installation. Before you begin preparing the site or digging any holes you must first contact you local utility companies so they can visit the site and mark all of the buried utilities.
- Page 6 Web Site – www.astm.org SportsPlay Equipment Inc. does not manufacture safety surfacing. All manufacturers of safety surfacing require different depths of surfacing for fall You must consider the type of safety surfacing you will use before beginning heights.
- Page 7 382-403H WHEELCHAIR SWING Installation Guide Tools and Materials Files and sand paper List is for tools and materials needed that are not included with the Safety surfacing playground Spray paint to mark holes Follow manufacturer’s guidelines for proper use of tools and materials.
- Page 8 All SportsPlay Equipment play events have been engineered to meet all applicable safety guidelines, but if installed improperly, these problems may occur:...
- Page 9 382-403H WHEELCHAIR SWING Installation Guide FOOTING SIDE VIEW Step 1: Layout Lay structure in the desired location using the top view layout drawing. Measure from each post to ensure there is adequate space for any component and the components fall zone. This drawing is a standard drawing and does not represent the actual playground you are installing.
- Page 10 382-403H WHEELCHAIR SWING Installation Guide SportsPlay recommends having a CPSI (certified playground safety Step 3: Post & Component Installation inspector) present during installation. If that’s not possible you should have the completed playground (after surfacing is in place) inspected by We recommend installing the posts once the post are square and level a CPSI.
- Page 11 382-403H WHEELCHAIR SWING Installation Guide Other Installation Tips If you are mocking up components with the intention of removing the hardware at some point, you may want to apply lubricating oil to the hardware. Stainless steel hardware has a tendency to seize so if you are planning on removing the hardware you may want to apply lubricant to prevent this.
- Page 12 382-403H WHEELCHAIR SWING Installation Guide Make sure there are no unsafe modifications (especially ropes tied to SUPERVISION GUIDE equipment). Remove all unsafe modifications and close the equipment for play until they are removed. This equipment has been designed for use under STRICT CONTROL BY AN ...
- Page 13 382-403H WHEELCHAIR SWING Installation Guide Once the is unsnapped of removed, then the front entry platform must be unsnapped from the chain assembly and pulled down. Once the front platform/chain assembly is pulled down, the wheelchair should be placed or rolled onto the platform (Handles facing short platform).
- Page 14 382-403H WHEELCHAIR SWING Installation Guide ½ X ½ SET 3/16 ALLEN WRENCH (YELLOW BAG) SCREW D-SHACKLE 2 3/8” SWING HANGER ¼ ALLEN WRENCH (BLUE BAG) 5/16 LOCK 5/16 X 1 BUTTON WASHER HEAD NUT 5/16 X 2 ½ BUTTON 5/16 ALLEN WRENCH (RED BAG)
- Page 15 382-403H WHEELCHAIR SWING Installation Guide COMPONENT INSTALLATION INSTRUCTIONS...
-
Page 16: Installation Details
382-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION INSTALLATION DETAILS Recommended crew (Adult): 2 Installation time: 4 hr User age: 5-12 Use zone: 20’ x 32’ Weight: 148 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required. -
Page 17: Parts List
382-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 383-511 Swing End 1 7/8” x 8’ Pipe 383-221 2 3/8” x 4’ Pipe 383-220 1 7/8” x 8’ Pipe 503-612 1 7/8” T-Clamp (pair) 425-517 2 3/8” Swing Hanger... - Page 18 382-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION FOOTING INFORMATION Total footing depth is 24” less the height of the surfacing plus the height of the blocking material. If you are using 12” of surfacing the footing hole would need to be 12” plus the height of the blocking material (refer to both the side and front cutaway views to the right).
- Page 19 382-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION ELEVATION AND FOOTING LAYOUT VIEW March 2, 2016...
-
Page 20: Specifications
382-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION SPECIFICATIONS INSTALLATION TIPS & TROUBLE SHOOTING Apply locktite to all bolts during assembly prior to Tube – FloCoat® Galvanized 1 7/8” O.D. and 2 3/8” O.D. completely tightening them. Hardware – Stainless steel & tamper resistant ... -
Page 21: Before You Begin
382-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a tape measure, post hole digger, level and a dry erase marker. INSTALLATION STEPS __1) Review all instructions before beginning:... - Page 22 382-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION INSTALLATION STEPS CONTIUDE __6) Attaching Plastic Caps to Base Rail Pipe: To do this you will need the four of the black plastic caps (12). Slide the black plastic cap onto the base pipe (4). Do this to all four ends of the base rail.
- Page 23 382-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __9) Tighten all set screws inspect the area and components for tools, hazardous debris and sharp edges. Inspect for sharp edges and if necessary file them down and apply touch up paint.
