SportsPlay Equipment 381-404H Installation Instructions Manual

Wheelchair swing
Hide thumbs

Advertisement

Quick Links

Download this manual
381-404H WHEELCHAIR SWING
Installation Guide
INSTALLATION INSTRUCTIONS
381-404H
ACCESSIBLE WHEELCHAIR SWING
Please read the entire manual before beginning installation.
3 CTN
5 PIPE
2 WF
10 TOTAL PCS
265# WEIGHT
CLASS 70
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 381-404H and is the answer not in the manual?

Questions and answers

Related Manuals for SportsPlay Equipment 381-404H

Summary of Contents for SportsPlay Equipment 381-404H

  • Page 1 381-404H WHEELCHAIR SWING Installation Guide INSTALLATION INSTRUCTIONS 381-404H ACCESSIBLE WHEELCHAIR SWING Please read the entire manual before beginning installation. 3 CTN 5 PIPE 2 WF 10 TOTAL PCS 265# WEIGHT CLASS 70...
  • Page 2 381-404H WHEELCHAIR SWING Installation Guide...
  • Page 3 381-404H WHEELCHAIR SWING Installation Guide dm 04-30-20...
  • Page 4 381-404H WHEELCHAIR SWING Installation Guide Important Also note any obvious damage to the packing materials, pallets or components on the BOL. Please read completely before beginning installation. Equipment should be inventoried and installed within a few days of This equipment has been designed for safety as well as challenge and fun. This receipt.
  • Page 5 381-404H WHEELCHAIR SWING Installation Guide Before you begin Review your swing footing and top view drawings to ensure your site is large enough. Read through the entire instruction booklet before beginning the actual installation. Before you begin preparing the site or digging any holes you must first contact you local utility companies so they can visit the site and mark all of the buried utilities.
  • Page 6 Web Site – www.astm.org SportsPlay Equipment Inc. does not manufacture safety surfacing. All manufacturers of safety surfacing require different depths of surfacing for fall You must consider the type of safety surfacing you will use before beginning heights.
  • Page 7 381-404H WHEELCHAIR SWING Installation Guide Tools and Materials Files and sand paper List is for tools and materials needed that are not included with the Safety surfacing playground Spray paint to mark holes Follow manufacturer’s guidelines for proper use of tools and materials.
  • Page 8 All SportsPlay Equipment play events have been engineered to meet all applicable safety guidelines, but if installed improperly, these problems may occur:...
  • Page 9 381-404H WHEELCHAIR SWING Installation Guide FOOTING SIDE VIEW Step 1: Layout Lay structure in the desired location using the top view layout drawing. Measure from each post to ensure there is adequate space for any component and the components fall zone. This drawing is a standard drawing and does not represent the actual playground you are installing.
  • Page 10 381-404H WHEELCHAIR SWING Installation Guide SportsPlay recommends having a CPSI (certified playground safety Step 3: Post & Component Installation inspector) present during installation. If that’s not possible you should have the completed playground (after surfacing is in place) inspected by We recommend installing the posts once the post are square and level a CPSI.
  • Page 11 381-404H WHEELCHAIR SWING Installation Guide Other Installation Tips If you are mocking up components with the intention of removing the hardware at some point, you may want to apply lubricating oil to the hardware. Stainless steel hardware has a tendency to seize so if you are planning on removing the hardware you may want to apply lubricant to prevent this.
  • Page 12 381-404H WHEELCHAIR SWING Installation Guide  Make sure there are no unsafe modifications (especially ropes tied to SUPERVISION GUIDE equipment). Remove all unsafe modifications and close the equipment for play until they are removed. This equipment has been designed for use under STRICT CONTROL BY AN ...
  • Page 13 381-404H WHEELCHAIR SWING Installation Guide Once the is unsnapped of removed, then the front entry platform must be unsnapped from the chain assembly and pulled down. Once the front platform/chain assembly is pulled down, the wheelchair should be placed or rolled onto the platform (Handles facing short platform).
  • Page 14 381-404H WHEELCHAIR SWING Installation Guide ½ X ½ SET 3/16 ALLEN WRENCH (YELLOW BAG) SCREW D-SHACKLE 2 3/8” SWING HANGER ¼ ALLEN WRENCH (BLUE BAG) 5/16 LOCK 5/16 X 1 BUTTON WASHER HEAD NUT 5/16 X 2 ½ BUTTON 5/16 ALLEN WRENCH (RED BAG)
  • Page 15 381-404H WHEELCHAIR SWING Installation Guide COMPONENT INSTALLATION INSTRUCTIONS...

  • Page 16: Installation Details

    382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew (Adult): 2  Installation time: 4 hr  User age: 5-12  Use zone: 0’ x 0’  Weight: 123 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.

  • Page 17: Parts List

    382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 383-414 HD Main Platform/Chain ASM. 383-415 HD Back Platform/Chain ASM. 383-416 HD Front Platform/Chain ASM. 186-403 ¼” x 1” Flat Head Screw 226-402 ¼” Lock Nut 342-506 D - Shackle 416-500BPK 5/16”...
  • Page 18 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION Note: The swing hanger’s pivot point to the ground should be 91” which will result an approximate 4” distance from the bottom of the platform to the ground. May 21, 2020...

  • Page 19: Installation Instruction

    382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION SPECIFICATIONS INSTALLATION TIPS & TROUBLE SHOOTING  Hardware – Stainless steel & tamper resistant  Do not tighten bolts all the way until the unit is completely assembled and all components are square and level. ...

  • Page 20: Before You Begin

    382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a tape measure, post hole digger, level and a dry erase marker. INSTALLATION STEPS __1) Review all instructions before beginning: __2) Unpack, organize, and identify all components: Be sure to place all painted components on a protective surface (cardboard, cloth, etc…) to prevent damage.

  • Page 21: Operational Instructions

    382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION INSTALLATION STEPS CONTIUDE __6) Attaching Front and Back Restrain Chain: To do this all you have to do is use the swivel snaps and hooks it to the D- Shackle. The small restrain chain goes in back and the long for the front.
  • Page 22 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION OPERATIONAL INSTRUCTION CONTIUDE __6) The front platform/chain assembly should be pushed back into its original position and snapped back on the chain assembly of the platform with the swivel snaps. __7) Finally, the long restraining chain should be placed or snapped back onto the chain assembly by using the swivel snaps.
  • Page 23 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION This equipment has been designed for use under STRICT CONTROL BY AN ADULT. This Equipment does not meet the standards set by ASTM and is designed to allow people who are bound to a wheelchair to swing. This unit can cause serious injury if used in an un-supervised area where other children are playing.
  • Page 24 381-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew (Adult): 2  Installation time: 4 hr  User age: 5-12  Use zone: 21’ x 39’  Weight: 148 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.
  • Page 25 381-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 383-511 Swing End 1 7/8” x 11’ Pipe 583-601A 2 3/8” x 4’ Pipe 383-220 2 3/8” Swing Hanger 585-520 342-506 D Shackle ½” x ½” Socket Set Screw 196-802 5/16”...
  • Page 26 381-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION FOOTING INFORMATION  Total footing depth is 24” less the height of the surfacing plus the height of the blocking material. If you are using 12” of surfacing the footing hole would need to be 12” plus the height of the blocking material (refer to both the side and front cutaway views to the right).
  • Page 27 381-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION ELEVATION AND FOOTING LAYOUT VIEW April 8, 2020...
  • Page 28 381-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION SPECIFICATIONS INSTALLATION TIPS & TROUBLE SHOOTING  Apply locktite to all bolts during assembly prior to  Tube – FloCoat® Galvanized 1 7/8” O.D. and 2 3/8” O.D. completely tightening them.  Hardware – Stainless steel & tamper resistant ...
  • Page 29 381-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a tape measure, post hole digger, level and a dry erase marker. INSTALLATION STEPS __1) Review all instructions before beginning:...
  • Page 30 381-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION INSTALLATION STEPS CONTIUDE __6) Attaching Swing Hangers: You will need two swing hangers (4), two D Shackles (5). Assemble the D-shackles and the wheelchair chain to the swing hangers. Attach the swing hangers to the top rail. See (Detail C).
  • Page 31 381-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __10) Once the concrete has set, back fill dirt over the footing holes; inspect the area and components for tools, hazardous debris and sharp edges. Verify all components are installed and all hardware is tight and then install the safety surfacing.
