Lee Technology LTK-1400A User Instruction Manual

Pager transmitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PAGER TRANSMITTER
USER INSTRUCTION MANUAL
FCC ID :QBTLTK-1400A
Trade Name : PAGER TRANSMITTER
Model No. :LTK-1400A
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS :
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
LEE TECHNOLOGIES KOREA CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LTK-1400A and is the answer not in the manual?

Questions and answers

Related Manuals for Lee Technology LTK-1400A

Summary of Contents for Lee Technology LTK-1400A

  • Page 1 USER INSTRUCTION MANUAL FCC ID :QBTLTK-1400A Trade Name : PAGER TRANSMITTER Model No. :LTK-1400A THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS : (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

  • Page 2: Fcc Notice

    FCC NOTICE WARNING : The antenna must be installed in a manner that ensures a minimum separation distance of 30 centimeters between the antenna and human beings.
  • Page 3 TABLE OF CONTENTS Ⅰ. PREFACE Ⅱ. TURN TRANSMITTER ON/OFF Ⅲ. SEND A PAGE 1. NUMERIC MESSAGE 2. ALPHA MESSAGE 3. PRE-SET MESSAGE(ON) 4. ALPHA MESSAGE(ON) 5. TRANSMIT INDIVIDUAL PAGER NUMBER 6. ERROR MODE Ⅳ. SETUP MENU 1. MENU OPTIONS 1) USER MODE 2) MASTER MODE 2.
  • Page 4 PAGER TRANSMITTER Ⅰ. PREFACE Pager transmitter, LTK-1400A is the desktop paging system capable of addressing more than 1000 pagers with Alpha message or Numeric message. It consists of a fully featured encoder with a large 4 line by 64 chara -cter LCD display.
  • Page 5 (3) Input message in ENTER MESSAGE (Maximum available up to 128 characters) and then press ENTER. (4) Transmit message and return to initial screen. (Sending Message Please Wait) ※ To return to an initial screen(1/3) on the process, input CANCEL. 3.
  • Page 6 1) Set Default Msg:OFF in Menu Options * In initial screen(1/3), input "1" and push SEND then No Message is transmitted. 2) Set Default Msg:ON in Menu Options * In initial screen(1/3), input "1" and push SEND then Message which is set in Set Default Msg is transmitted. 6.
  • Page 7 ※ If hour(1-12) or minute(00-59) is set by other number, it moves to default time. 2) SLEEP TIME SETUP (1) Go to 2.Sleep Time Setting using *(←) and #(→) Key and then press ENTER. (2) Select 1.ON or 2.OFF using *(←) and #(→) Key and then press ENTER. (3) Sleep Time is displayed and default Sleep Time is 12:00 AM.
  • Page 8 (2) Select one among "Set Pager Alert:" list using *(←) and #(→) Key, and then press ENTER. (3) "Are All Pagers Returned??" is displayed and then press ENTER. (4) "Unplug All Coasters" is displayed and then press ENTER. (5) "Message Sent Plug In Pager" is displayed and transmit message twice and then move to Menu Options. * Pager Alert Message LIST 1.Vibe Only (9292) 2.Vibe &...
  • Page 9 (1) Go to 8.Set Alpha Msg using *(←) and #(→) Key and then press ENTER. (2) Select 1.Alpha Msg:ON/OFF using *(←) and #(→) Key and then press ENTER. (3) Select 1.ON using *(←) and #(→) Key and then press ENTER. (4) Select 2.Alpha Msg(0-9) using *(←) and #(→) Key and then press ENTER.

  • Page 10: Troubleshooting

    Troubleshooting Transmitter will not display anything a. Make sure there is power to the outlet a. Check all connections. If you try all this and the transmitter still wont power up your power supply may be bad. If display is still blank, call us Before you call, try some of the following suggestion *Remember that the capability of your system will be affected by: Foil backed wallboard, Metal mesh, wire reinforced glass, metal sheeting, large mirrors, suspended ceilings, lift shafts etc.
  • Page 11 The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device.

  • Page 12: Warranty

    WARRANTY LeeTek warrants this product against any defects that are due to faulty material or workmanship for a one-year period after the original date of consumer purchase. This warranty does not include damage to the product resulting from accident, misuse or improper electrical connection. Power supplies are warranted for 60 days.

  • Page 13: Hints And Tips

    Benefits of a VISUAL paging system Staff members are alerted thru the pager and know to quickly close the tab of a guest to help speed table turns. LEE TECHNOLOGY KOREA CO., LTD.
