Summary of Contents for RC4 Wireless DMX6dim-500
- Page 1 Wireless Dimming | Wireless DMX | Wireless Motion Since 1991 W i r e l e s s RC4Magic Series 3 DMX6dim-500 High Power Six-Channel Wireless Dimmer Quick Start Guide Rev. 1.0...
- Page 2 RC4Magic DMX6dim-500 1. DMX Data Indicator 2. Function and COP* Indicator 3. Function Button 4. SetABC and SetDEF Buttons 5. DimA - DimF Dimmer Indicators 6. RF Connect Indicator 7. Anderson PowerPole Connections for Power and Outputs 8. DMX In/Out Data Port 9.
- Page 3 Most RC4Magic DMX6dim-500 users will find all the information they need To use your DMX6dim-500 wireless dimmer you will need: right here. Your DMX6dim-500 also has a wide variety of advanced features. • A DMX lighting console. You can find out more about them in the RC4 Knowledge Base at http://rc4.
-
Page 4: Performing A Factory Reset
Confirming and Setting an RC4 System ID All RC4Magic devices being used together must be set to the same RC4 System ID. If someone else has used your DMX6dim-500, or On power-up, the currently selected System ID is indicated with a blink pattern on you just want to get back to a known configuration, the DMX Data and COP indicators. - Page 5 RC4Magic Series 3 system operating in the 2.4GHz band. The RF Connect indicator remains on (not blinking) while the DMX6dim-500 is searching for your VPN. It blinks quickly and PUSH continuously while your DMX6dim-500 is connected to your wireless VPN.
- Page 6 DMX channel 1 for dimmer A, and channel 2 for dimmer B. Bring up the DMX channel that will be the DMX6dim-500 starting address. Set Before changing any settings, play with DMX levels for these channels to see it to 30% (Decimal 77) for a curve that is optimized for smooth LED dimming.
- Page 7 C, and connect the second to DimD, E, and F. Power Input: 6 - 35VDC Do not exceed voltage * DimC, D, E, and F on the DMX6dim-500 can control a variety of devices including solenoids, rating for connected loads. Common Positive...
-
Page 8: Advanced Features
Choosing Other Dimmer Curves or Profiles Advanced Features The DMX6dim-500 default is the ISL dimmer curve, which is best for LEDs. This The DMX6dim-500 is a multifaceted device for users of all experience levels. is also the curve that is selected with RC4 OneTouch™ when the DMX level is The features below can be explored further at http://rc4.info/ or by asking us... - Page 9 Caring for Your DMX6dim-500 • The DMX6dim-500 should not be used with AC power or with any voltage higher than 35VDC. Doing so will severely damage the device and is extremely dangerous for the operator. • Do not exceed the maximum total power handling of the DMX6dim-500, which is 45A.
