- Page 1 FINAL FOR PRINT RF-RBWHP01_10-0652_MAN_V1.fm Page 1 Thursday, July 29, 2010 8:26 AM Rocketboost™ Wireless Stereo Headphones RF-RBWHP01 User Guide...
- Page 2 RF-RBWHP01_10-0652_MAN_V1.fm Page 2 Thursday, July 29, 2010 8:26 AM...
-
Page 3: Table Of Contents
Specifications..............23 Legal notices ..............24 One-year limited warranty.........27 Introduction Congratulations on your purchase of high-quality Rocketfish Rocketboost™ Wireless Stereo Headphones. This system represents the state of the art in 2.4 wireless headphone design, and gives you complete freedom while enjoying your music or movie without the limitations of cables. -
Page 4: Safety Information
RF-RBWHP01_10-0652_MAN_V1.fm Page 4 Thursday, July 29, 2010 8:26 AM The system can be used with your television or other audio components, like your CD/DVD player, home theater system, or even audio output from a computer or mp3 player. By using other Rocketboost™... - Page 5 RF-RBWHP01_10-0652_MAN_V1.fm Page 5 Thursday, July 29, 2010 8:26 AM • Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third is provided for your safety.
- Page 6 RF-RBWHP01_10-0652_MAN_V1.fm Page 6 Thursday, July 29, 2010 8:26 AM • Rocketboost™ is uncompressed digital audio compatible with all audio formats such as Dolby TrueHD, and DTS-HD Master Audio used with Blu-ray. When you see the Rocketboost™ logo on any product, it has been designed to work with other Rocketboost™...
-
Page 7: Features
RF-RBWHP01_10-0652_MAN_V1.fm Page 7 Thursday, July 29, 2010 8:26 AM We hope you enjoy your new Rocketboost system. Remember that it’s designed to grow with your home entertainment needs, and that it’s easy to add a new device to the network as you expand your system. - Page 8 RF-RBWHP01_10-0652_MAN_V1.fm Page 8 Thursday, July 29, 2010 8:26 AM Headphones back Item Description Self-adjustable headband Swiveling hinge for angle adjustment (on the left and right ear pieces) Power ON/OFF switch (on left earpiece) Source indicator (on the SOURCE button). Flashes several times when a different audio stream is selected on your Rocketboost network.
- Page 9 RF-RBWHP01_10-0652_MAN_V1.fm Page 9 Thursday, July 29, 2010 8:26 AM Headphones front and side Left earpiece RIght earpiece Item Description Manual CONNECT button (on the left earpiece) Charging contacts (on the left earpiece) Power indicator (on the left earpiece). Lights green when the hub switch on the docking station is set to enable and lights blue when the hub switch on the docking station is set to disable.
- Page 10 RF-RBWHP01_10-0652_MAN_V1.fm Page 10 Thursday, July 29, 2010 8:26 AM Docking station front Item Description STANDBY indicator. Lights red when the docking station is plugged in. POWER indicator. Lights green when the hub switch on the docking station is set to enable and lights blue when the hub switch on the docking station is set to disable.
- Page 11 RF-RBWHP01_10-0652_MAN_V1.fm Page 11 Thursday, July 29, 2010 8:26 AM Docking station back Item Description Manual connect button DC IN jack AUX INPUT jacks AUX OUTPUT jacks RF-RBWHP01...
- Page 12 RF-RBWHP01_10-0652_MAN_V1.fm Page 12 Thursday, July 29, 2010 8:26 AM Docking station top Item Description Charging pins Headphone cradles Hub Enable/Disable switch Power on/standby switch...
-
Page 13: Setting Up Your System
RF-RBWHP01_10-0652_MAN_V1.fm Page 13 Thursday, July 29, 2010 8:26 AM Setting up your system Caution: To prevent damage to your system, make sure all components are turned off before making the connections. Connecting the system to an audio source The following diagram shows a typical user installation. In this case the docking station is connected to the audio output of a TV. - Page 14 RF-RBWHP01_10-0652_MAN_V1.fm Page 14 Thursday, July 29, 2010 8:26 AM To connect the docking station to your audio source: • Using the supplied RCA audio cable, connect the audio output jacks of your audio source to the AUX INPUT jacks of the docking station. Make sure that you connect the same color jacks together (the white to the white and the red to the red).
- Page 15 RF-RBWHP01_10-0652_MAN_V1.fm Page 15 Thursday, July 29, 2010 8:26 AM To connect the docking station to your amplifier (optional): • The audio input signal from the AUX INPUT jacks is connected to the AUX OUTPUT jacks. This is helpful if your audio source component only has one audio output and you want to connect it to both the docking station and another component, like an audio amplifier.
-
Page 16: Using Your System
RF-RBWHP01_10-0652_MAN_V1.fm Page 16 Thursday, July 29, 2010 8:26 AM Expanding the headphones with other Rocketboost devices Your headphones can receive audio from other Rocketboost sender devices. Additionally your other Rocketboost receivers can receive audio connected to your docking station. To expand your listening area throughout your house, install additional receivers and senders where ever you want sound. - Page 17 RF-RBWHP01_10-0652_MAN_V1.fm Page 17 Thursday, July 29, 2010 8:26 AM Insert one AA rechargeable battery into each battery compartment. Make sure to align the + and - symbols on the batteries with the symbols in the battery compartments. Put the left and right cushions back into place. Charging the headphones Important: Before using the wireless headphones for the first time, make sure the batteries are fully charged for at least 16 hours.
- Page 18 RF-RBWHP01_10-0652_MAN_V1.fm Page 18 Thursday, July 29, 2010 8:26 AM • The docking station charging indicator turns red to indicate the headphones are charging. • When the headphones are fully charged (which takes about eight to nine hours), the docking station charging indicator turns green. Note: It can take about eight to nine hours to charge the batteries.
- Page 19 RF-RBWHP01_10-0652_MAN_V1.fm Page 19 Thursday, July 29, 2010 8:26 AM • Blue when the HUB switch on the docking station is set to DISABLE. Power indicator Power indicator Notes: If the headphone’s charge is low, the indicator turns red. When this happens, you should charge the headphones.
- Page 20 RF-RBWHP01_10-0652_MAN_V1.fm Page 20 Thursday, July 29, 2010 8:26 AM To join the headphones to the docking station: Docking station (HUB: ENABLE) + other Rocketfish devices. Headphones Rocketfish sender/receiver RF-RBAUX (HUB: DISABLE) Set the HUB switch on the docking station to ENABLE if this is your first Rocketboost™...
- Page 21 RF-RBWHP01_10-0652_MAN_V1.fm Page 21 Thursday, July 29, 2010 8:26 AM To join an existing Rocketboost network: Rocketfish sender/receiver RF-RBAUX or other Rocketboost device. (HUB: ENABLE) RF-RBAUX Docking station Headphones (HUB: DISABLE) (HUB: DISABLE) Set the HUB switch on the docking station to DISABLE.
-
Page 22: Maintaining Your System
RF-RBWHP01_10-0652_MAN_V1.fm Page 22 Thursday, July 29, 2010 8:26 AM Listening to the digital wireless stereo headphones To listen through the headphones: Set the headphone volume level to the minimum. Turn on the headphones and docking station. Make sure that your docking station and headphones are wirelessly “joined. -
Page 23: Troubleshooting
RF-RBWHP01_10-0652_MAN_V1.fm Page 23 Thursday, July 29, 2010 8:26 AM • If the power cord is damaged, it must be repaired by a qualified technician. Troubleshooting Check this list for a possible solution before calling for service. Problem Solution No sound •... -
Page 24: Legal Notices
RF-RBWHP01_10-0652_MAN_V1.fm Page 24 Thursday, July 29, 2010 8:26 AM Legal notices FCC and IC Information: This device complies with Part 15 of the FCC Rules and RSS-210 of the IC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 26 RF-RBWHP01_10-0652_MAN_V1.fm Page 26 Thursday, July 29, 2010 8:26 AM...
-
Page 27: One-Year Limited Warranty
Product is determined to be defective by an authorized Rocketfish repair center or store personnel, Rocketfish will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you. - Page 28 Damage due to incorrect operation or maintenance • Connection to an incorrect voltage supply • Attempted repair by anyone other than a facility authorized by Rocketfish to service the Product • Products sold as is or with all faults •...
- Page 29 RF-RBWHP01_10-0652_MAN_V1.fm Page 29 Thursday, July 29, 2010 8:26 AM RF-RBWHP01...
- Page 30 RF-RBWHP01_10-0652_MAN_V1.fm Page 30 Thursday, July 29, 2010 8:26 AM...
- Page 31 RF-RBWHP01_10-0652_MAN_V1.fm Page 31 Thursday, July 29, 2010 8:26 AM RF-RBWHP01...
- Page 32 Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2010 BBY Solutions, Inc. All rights reserved. ROCKETFISH is a trademark of BBY Solutions, Inc. All other products and brand names are trademarks of their respective owners. 10-0652...
