- Page 1 Steam Generator User's Manual Model: SR-6000 * To use the product correctly, plese read this operation instruction carefully. http://www.silverstar.co.kr...
-
Page 2: Table Of Contents
♠ Before use What is vapor generator - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Names of parts of product - - - - - - - - - - - - - - - - - - - - - - - - - - - - Product specification - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -... -
Page 3: What Is Vapor Generator
What is SR-6000 SR-6000 is composed of the vapour generated between pressure containers that store water and generate vapours, and the iron that can perform ironing work.This product functions with antomatism of water. Vapour generator owns basic functions of industrial boiler. Miniaturized design is easy in installation and convenient for use. -
Page 4: Product Specification
Product specification Product name Vapour generator Type SR-6000 Voltage 120/220V~,50/60㎐ 1,500W Vapour generator power Electric iron power 120V/800W,220V/1,000W Vapour pressure 3.5bars Product weight 25kg Product dimension 420×250×830h Circuit diagram QS : power switch PCB : Pcb board P S/W : Switch of iron T.F : Fuser... -
Page 5: Product Characteristics
Product characteristics ♣ This product satisfies relevant technical requirements for customer's safety. ♣ This product is energy saving product improving basic energy consumption of boiler. ♣ This vapour generator has four major safety devices. - automatic pressure cutting switch attached - safety valve that can discharge pressure in the vapour container in case of excessive pressure generated because of product abnormality - two automatic temperature controllers preventing (over temperature attached) do... -
Page 6: Precautions Of Safety Use
Precautions of safe use ♣ The following is indication of precautions marked to prevent occurance of accidents for correct, safe use of product.which is expected to be abided by. ♣ Precautions of safe use, such as unexpected hazard caused by inadequate use,are classified by "Warning"... -
Page 7: Use
Precautions of Safe Use ★ Power wire can not be extruded by heavy object or product. Warning! ---------------------- Short circuit of power wire may become the reason of electric shock and fire. Power ★ It must be used on the plug more than 120V/25A, 220V/15A individually. - Page 8 Precautions of Safe Use ★ It should be paid special attention to that use, or contact by children should be Warning! prevented. ---------------------- To avoid scald. ★ During product use, spraying at human body or contacting vapour is prohibited. ★ Except for iron clothes, it can not be used for other purpose.
-
Page 9: Confirmation Before Use
Precautions of Safe Use ★ After use, the cleaning must be made after power plug is pulled out. Cautio ★ Washing powder or detergent can not be used for cleaning. ---------------------- Sweepi To avoid electric shock and ng and shortened service life of product. keepin ★... -
Page 10: Assembly And Use
Assembly and Use 1. Setting of hook 2. Put Water ● Install the hook Put water into water according to the bottle, also suction drawing,hang power pipe and hanst pipe wire and vapour put into bottle too. tube on the hook. 4. -
Page 11: Cleaning Method
Cleaning method ★ Clean once a month. ★ Open the salfly valve,give 1/2 water in this bottle.Throug the valve drain the water(try 2-3 times) ★ After repeated operation, power on and heat for about 15 minutes, to eliminate moisture in pressure container completely.(Safety valve should be in open state right now) ★... -
Page 12: Breakdown Drawing
Troubleshooting Common problems Cause Solution ●The power is cut off. ●Check if the socket is well ●The indicating light in front of product is OFF. ●The socket is not well connected. connected. ●Check if there is any failure of ●Failure of socket. socket. - Page 13 HEAD OFFICE & FACTORY 104-5,Shinpyong-Ri,Shinbuk-Myoun,Pochun-Kun,Kyoungki- Do,Korea TEL:82-31-531-8131~6 FAX:82-31-531-8130 E-mail : silverstar@silverstar.co.kr...
