- Page 1 User manual for XMR401HD User Manual Mobile Digital Video Recorder ...
- Page 2 User manual for XMR401HD Notice The information in this manual was current when published. The manufacturer reserves the right to revise and improve its products. All specifications are therefore subject to change without any notice. The purpose of this manual is to kindly aid the user for the operation for our MDVR. The user should have a basic understanding of computer operation and basic knowledge of how to connect peripherals and make some settings.
- Page 3 User manual for XMR401HD Guarantee & Warnings 1) Electrical Apparatus Safety All installation and operation should comply with local electrical safety norms. 2) Transportation In the process of transportation, storage and installation, please avoid heavy stress, violent vibration, impact and water splashing.
-
Page 4: Product Characteristics
1. PRODUCT CHARACTERISTICS 1.1. OVERVIEW XMR401HD is a functional Mobile Digital Video Recorder specially designed for vehicle video surveillance. It has a high-speed processor and embedded operating system, combining with the most advanced H.264 video compression / decompression technology, GPS positioning technology. It supports video recording in 720P, WD1, WHD1, WCIF, D1, HD1 and CIF formats. - Page 5 User manual for XMR401HD Pre-recording 0-60minutes Post-recording 0-30 minutes Mirror/Dual Recording Support Playback Channel 1 channel by local playback Playback Search Mode Date/time, channel, event IPC Ethernet 6-pin DJ M12(100M x 1, PON power supply) Locating Location tracking, speed detection and time sync...
-
Page 6: System Diagram
User manual for XMR401HD 1.3. SYSTEM DIAGRAM 1.4. EXTERNAL INTERFACE DIMENSION (Unit: mm) - Page 7 User manual for XMR401HD FRONT PANEL REAR PANEL Serial No. Print Description Power DC 8-36 V Power Input Sensor&Serial The Interfaces of Serial Port and Switch A/V IN1~4 Audio & Video Input 1-4 A/V OUT Audio & Video Output The Interface of PON Power Supply...
-
Page 8: Definition And Pictures Of External Cables
User manual for XMR401HD 1.5. DEFINITION AND PICTURES OF EXTERNAL CABLES ALARM CABLE DEFINITION Alarm and Serial Cables A/V OUT Cable 2. FREQUENTLY ASKED QUESTIONS The system can’t start? Usually this problem results from the incorrect power connection. Please follow below steps to... - Page 9 User manual for XMR401HD whether it is broken down. The device can’t record? Usually this problem results from the storage disk or camera. Please follow below steps to check it: Check whether the storage disk is installed, whether it is in good contact, and whether the disk can be read normally in computer.
