Product Information
file:///P|/P_TranslateFile/C9/2008/8/C9004300-Qisda-Philips%20240S...13-Final/CD-Contents/lcd/manual/ENGLISH/240SW9/product/product.htm 第 8 頁 / 共 10 2008/8/13 下午 05:42:53
Physical Specifications
• Tilt -5°+2/-0 ~+ 20°+3/-0
• Power supply 100 ~ 240 VAC, 50/60 Hz
• Power consumption 65W* (typ.)
0° C to 40 ° C (operating)
• Temperature
-20° C to 60° C (storage)
• Relative humidity 20% to 80%
• System MTBF 50K hours (CCFL 40K hours)
* This data is subject to change without notice.
The native resolution of the monitor is 1920 x 1200. By default, your monitor has 100% brightness (max.), 50% contrast, and
6500K color temperature, with a full white pattern.
Pin Assignment
1.The digital only connector contains 24 signal contacts organized in three rows of eight contacts. Signal pin assignments are
listed in the following table:
Pin
Signal Assignment
No.
1
T.M.D.S. Data2-
2 T.M.D.S. Data2+
3 T.M.D.S. Data2/4 Shield
4 No connect
5 No connect
6 DDC Clock
7 DDC Data
8 No connect
RETURN TO TOP OF THE PAGE
RETURN TO TOP OF THE PAGE
Pin
Signal Assignment
No.
9 T.M.D.S. Data1-
10 T.M.D.S. Data1+
11 T.M.D.S. Data1/3 Shield
12 No connect
13 No connect
14 +5V Power
15 Ground (for +5V)
Hot Plug Detect
16
Pin
Signal Assignment
No.
T.M.D.S. Data0-
17
T.M.D.S. Data0+
18
T.M.D.S. Data0/5 Shield
19
No connect
20
No connect
21
T.M.D.S. Clock Shield
22
T.M.D.S. Clock+
23
T.M.D.S. Clock-
24
