- Page 1 Owner's Manual IPS LED MONITOR (LED MONITOR*) *LG LED Monitors are LCD Monitors with LED Backlighting. Please read the safety information carefully before using the product. IPS LED Monitor (LED Monitor) Model List 29WK600 34WK650 34BK650 www.lg.com...
-
Page 2: Table Of Contents
Contents CONTENTS LICENSE USER SETTINGS Activating the Main Menu - Main Menu Features ASSEMBLING AND PREPARING User Settings Product Components - Menu Settings Supported Drivers and Software Component and Button Description TROUBLESHOOTING - How to Use the Joystick Button Input Connector Moving and Lifting the Monitor SPECIFICATIONS Installing the Monitor... -
Page 3: License
LICENSE LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries. -
Page 4: Assembling And Preparing
The product warranty will not cover damage or injury caused by the use of counterfeit components. It is recommend that use the supplied components. If you use generic cables not certified by LG, the screen may not display or there may be image noises. NOTE Note that the components may look different from those shown here. -
Page 5: Supported Drivers And Software
OnScreen Control Recommended Dual Controller Optional Required and Recommended: You can download and install the latest version from the enclosed CD or from the LGE website (www.lg.com). Optional: You can download and install the latest version from the LGE website (www.lg.com). -
Page 6: Component And Button Description
ASSEMBLING AND PREPARING Component and Button Description 29WK600 34WK650 34BK650 Joystick Button Power LED On: power is on Off: power is off How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with your finger. -
Page 7: Input Connector
ASSEMBLING AND PREPARING Input Connector 29WK600 34WK650 34BK650... -
Page 8: Moving And Lifting The Monitor
ASSEMBLING AND PREPARING Moving and Lifting the Monitor CAUTION When moving or lifting the monitor, follow these in- As far as possible, avoid touching the monitor structions to prevent the monitor from being scratched screen. This may result in damage to the screen or or damaged and to ensure safe transportation regard- some of the pixels used to create images. -
Page 9: Installing The Monitor
ASSEMBLING AND PREPARING Installing the Monitor Assembling the stand base 29WK600 Stand Body Stand Base CAUTION To protect the screen from scratches, cover the surface with a soft cloth. Screw Cover CAUTION Stand Body Applying excessive force when tightening the screws may cause damage to the monitor. -
Page 10: Installing The Monitor
ASSEMBLING AND PREPARING Installing the Monitor Assembling the stand base 34WK650 34BK650 Stand Body Stand Base CAUTION To protect the screen from scratches, cover the surface with a soft cloth. Cable Holder NOTE Stand Body Press the stand until the button reaches the top. -
Page 11: Using The Cable Holder
ASSEMBLING AND PREPARING Using the cable holder CAUTION Arrange the cables using the cable holder as shown in Illustrations in this document represent typical the illustration. procedures, so they may look different from the actual product. 34WK650 34BK650 Do not carry the monitor upside down by just holding the stand base. -
Page 12: Installing Onto A Table
ASSEMBLING AND PREPARING Installing onto a table Lift the monitor and place it on the table in an up- Connect the Power cord to the monitor, then plug right position. the power cord into the wall outlet. Place at least 100 mm away from the wall to ensure sufficient ventilation. -
Page 13: Adjusting The Angle
ASSEMBLING AND PREPARING Cautions When Connecting Power Cord Adjusting the angle Place the monitor in an upright position, mounted on the stand base. Adjust the angle of the screen. The angle of the screen can be adjusted forwards or backwards for a comfortable viewing experience. -
Page 14: Adjusting The Stand Height
ASSEMBLING AND PREPARING WARNING Adjusting the Stand Height To avoid injury to the fingers when adjusting the 34WK650 34BK650 screen, do not hold the lower part of the moni- Handle the monitor with both hands for safety. tor's frame as illustrated below. 29WK600 The height can be adjusted up to 110.0 mm. -
Page 15: Using The Kensington Lock
ASSEMBLING AND PREPARING Using the Kensington lock 34WK650 34BK650 The Kensington security system connector is located at the back of the Monitor set. For more information on installation and usage, refer to the Kensington lock user manual or visit the website at http://www.kensington.com. -
Page 16: Installing The Wall Mount Plate
If you use screw longer than standard, the monitor might be damaged internally. If you use improper screw, the product might be dam- aged and drop from mounted position. In this case, LG Electronics is not responsible for it. 29WK600 Wall Mount (A x B) 100 x 100... - Page 17 Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Please use the genu- ine LG wall mounting bracket. For more informa- tion, contact your local retail store or a qualified installer.
-
Page 18: Using The Monitor
NOTE There may be no video or audio output depending on the DP version of the PC. If you use generic cables not certified by LG, the screen may not display or there may be image noises. NOTE If you use HDMI PC, it can cause compatibility problem. -
Page 19: Connecting To Av Devices
USING THE MONITOR Connecting to External Devices Connecting to AV Devices HDMI connection Connecting Headphones Transmits the digital video and audio signals from your Connect peripherals to the monitor via the headphones PC and A/V devices to the monitor. Connect your PC port. -
Page 20: User Settings
User Settings USER SETTINGS Activating the Main Menu Press the joystick button on the bottom of the monitor. Move the joystick up/down ( ▲ / ▼ ) and left/right ( ◄ / ► ) to set the options. Press the joystick button once more to exit the main menu. Joystick Button Button Menu Status... -
Page 21: User Settings
User Settings User Settings Menu Settings To view the settings menu, press the joystick button at the bottom of the monitor and then enter the Settings. Configure the options by moving the joystick up/down/left/right. To return to the upper settings or set other settings items, move the joystick to ◄ or press ( ). If you want to exit the settings menu, move the joystick to ◄... - Page 22 User Settings Picture Mode on SDR(Non-HDR) signal. Settings > Picture Description Picture Mode Custom Allows the user to adjust each element. The color mode of the main menu can be adjusted. Reader Optimizes the screen for viewing documents. You can brighten the screen in the set- tings menu.
- Page 23 User Settings Picture Adjust Brightness Adjusts the brightness of the screen. Contrast Adjusts the contrast of the screen. Sharpness Adjusts the sharpness of the screen. SUPER High Optimized picture quality is displayed when a user wants crystal clear images. It RESOLUTION+ is effective for high quality video or game.
- Page 24 User Settings Color Adjust Gamma Mode 1, Mode 2, The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter the image becomes. Mode 3 Mode 4 If you do not need to adjust the gamma settings, select Mode 4. Color Temp Custom The user can adjust it to red, green, or blue by customization.
- Page 25 User Settings Settings > General Description Language Sets the menu screen to the desired language. SMART ENERGY High Saves energy using the high-efficiency SMART ENERGY SAVING feature. SAVING Saves energy using the low-efficiency SMART ENERGY SAVING feature. Disables the SMART ENERGY SAVING feature. Power LED The power LED turns on.
-
Page 26: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Nothing is displayed on the screen. Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. Test the Power Plug using a lamp or other device. Is the power LED on? Check the power cable connection and press the power button. - Page 27 Be sure to install the display driver from the display driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lg.com. Make sure to check if the video card supports Plug&Play function.
-
Page 28: Specifications
SPECIFICATIONS SPECIFICATIONS 29WK600 LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Pixel Pitch 0.2628 mm x 0.2628 mm Resolution Maximum Resolution 2560×1080 @ 75 Hz Recommended Resolution 2560×1080 @ 60 Hz Video Signal Horizontal Frequency 30 kHz to 90 kHz Vertical Frequency 56 Hz to 75 Hz Input Connector... -
Page 29: 34Wk650/34Bk650
SPECIFICATIONS SPECIFICATIONS 34WK650/34BK650 LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Pixel Pitch 0.312 mm x 0.310 mm Resolution Maximum Resolution 2560×1080 @ 75 Hz Recommended Resolution 2560×1080 @ 60 Hz Video Signal Horizontal Frequency 30 kHz to 90 kHz Vertical Frequency 56 Hz to 75 Hz Input Connector... -
Page 30: Factory Support Mode (Preset Mode, Pc)
SPECIFICATIONS Factory Support Mode (Preset Mode, PC) HDMI / DP Timing (PC) Resolution Horizontal Vertical Polarity(H/V) Remarks (HDMI / DP) Frequency(kHz) Frequency(Hz) 640 x 480 31.469 59.94 640 x 480 37.5 800 x 600 37.879 60.317 800 x 600 46.875 1024 x 768 48.363 1024 x 768... - Page 31 In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
