6V PSU Hub 2/Hub 2 Plus User Manual
6V PSU Hub 2/Hub 2 Plus is a power supply unit, connecting Hub 2 and Hub 2
Plus control panels to 6 and 12 volt DC sources. This is an electronic board,
replacing the standard 110/230 V power supply unit in the body of the device.
How to calculate Hub 2 or Hub 2 Plus operation time from the portable
battery when connecting via 6V PSU
Buy 6V PSU
Installing
6V PSU Hub 2/Hub 2 Plus should be installed by a qualified electrician only.
Before installing the power supply, make sure that the device is disconnected
from the mains.
When installing the 6V PSU Hub 2/Hub 2 Plus, follow the general electrical
safety rules, as well as the requirements of electrical safety regulatory acts.
Never disassemble the device while it is under voltage!
What is the difference between 6V PSU and 12V PSU
Installation process:
Updated April 23, 2021
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AJAX 6V PSU Hub 2
Summary of Contents for AJAX 6V PSU Hub 2
- Page 1 Updated April 23, 2021 6V PSU Hub 2/Hub 2 Plus is a power supply unit, connecting Hub 2 and Hub 2 Plus control panels to 6 and 12 volt DC sources. This is an electronic board, replacing the standard 110/230 V power supply unit in the body of the device.
- Page 2 1. Remove the screws and take off the device from the SmartBracket mounting panel, shifting it down with force. 2. Switch off the device holding the power button for 2 seconds. 3. Disconnect power and Ethernet cables. Wait 5 minutes for the capacitors to discharge. 4.
- Page 3 5. Remove the screws attaching the boards to the device body. 6. Carefully remove both boards, keeping them in the same plane and not disconnecting them. There is a connector between boards: do not break it.
- Page 4 7. Disconnect the power supply unit (smaller board) from the mainboard. 8. Connect 6V PSU Hub 2/Hub 2 Plus to the mainboard using the eight-pin connector between them. Do not warp or bend the antennas while replacing the board: this can cause the device to malfunction.
- Page 5 12. Switch on the device by holding the power button for 2 seconds. 13. Close and fix the SmartBracket mounting panel. Switch on the device, wait until loading, and check the external power status in the Ajax app. If there is no power, and you are using a terminal adapter, check...
- Page 6 the polarity of the connected wires. If there is no power even after reconnecting, please contact the Support Service. We recommend using zinc-air alkaline batteries for long-term autonomous operation. Before connecting such a battery, make sure that all the stickers have been removed, and valves capping the air access are open.
- Page 7 2. Terminal adapter 3. Quick start guide Warranty Warranty for the AJAX SYSTEMS MANUFACTURING Limited Liability Company products is valid for 2 years after the purchase. If the device does not function correctly, please contact the Support Service first. In half of the cases, technical issues can be solved remotely!
- Page 8 Subscribe to the newsletter about safe life. No spam Email Subscribe...
