Skyvue NXG-DS Owner's Manual

Weatherproof televisions
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NXG-DS| 4K-4350-L / 4K-4370-L
MODEL:
Owner's Manual
Weatherproof Televisions
IMPORTANT:
Please read this owners manual before
starting or operating the equipment.
3840P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NXG-DS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Skyvue NXG-DS

Summary of Contents for Skyvue NXG-DS

  • Page 1 NXG-DS| 4K-4350-L / 4K-4370-L MODEL: Owner’s Manual Weatherproof Televisions IMPORTANT: Please read this owners manual before starting or operating the equipment. 3840P...
  • Page 3 Congratulations on purchasing your new outdoor weather-proof television. We welcome you to our SkyVue family. To gain the full potential of your new SkyVue Outdoor Television, please read carefully the instructions within this document. There is a wealth of relevant information to get started and fully utilize all of the unique capabilities of your new SkyVue Outdoor Television.

  • Page 5: Important Information

    SKY4230 & SKY4630 NXG-DS|4k-4350-L / 4k-4370-L Model : OWNER’S MANUAL LED TELEVISION ENGLISH OPERATION MANUAL IMPORTANT: To aid reporting in case of loss or theft, please record the TV's model and serial numbers in the space provided. The numbers are located at the rear of the TV.
  • Page 6 DECLARATION OF CONFORMITY: SK Y4220 & SK Y4630 Model No.: NXG-DS|4k-4350-L / 4k-4370-L This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 7: S Afety I Nformation

    19) Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product according to the method recommended by the manufacturer. Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L afety nformatIon...
  • Page 8 Also, do not allow the cabinet to remain in contact with rubber or vinyl products for a long period of time. Plasticizers inside the plastic may cause the cabinet to deform and cause the paint to peel off. ® All Rights Reserved. SkyVue 2012 SKYVUE 2012 SKYVUE LC-60LE632U̲70LE732U̲E̲01.indd   4...
  • Page 9 More than 2,200 companies enjoy the benefi ts of CEA membership, including legislative advocacy, market research, technical training and education, industry promotion and the fostering of business and strategic relationships Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L afety nformatIon 2012 SKYVUE 2012 SKYVUE...
  • Page 10 Do not submerge SkyVue Outdoor TV’s in water: The SkyVue Outdoor TV’s will resist water exposure from normal rain, sprinklers, garden hoses, etc.; however, it is not designed to withstand pressure washers, high-pressure water jets, hurricane-type weather or be submerged in water.

  • Page 11: Table Of Contents

    ......................41 SIng the nput ......................... 43 rOuBleShOOtIng .................... 45 are Of utdOOr ........................46 pecIfIcatIOnS tV c & p ..................47 OlIcy nfOrmatIOn rS232 c ....................48 OntrOl OdeS Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L able of onTenTs...
  • Page 12 If items are damaged or missing, contact your dealer immediately. Back of 4350 model will appear slightly different than 4370 model Model NXG-DS|4k-4350-L / 4k-4370-L Front View Model NXG-DS|4k-4350-L / 4k-4370-L Back NXG-DS| 4K-4350-L / 4K-4370-L MODEL: Owner’s Manual...

  • Page 13: Tv I Nstallation

    1. The Internal Component Source is inside the Component Cover located on the back of the unit. 2. Loosen the 6 thumbscrews located on the back cover of your SkyVue TV , and pull off the cover to reveal the Component Source.

  • Page 14: Rear Panel Connections

    HDMI 1 Please note: This port does not support MHL devices. HDMI 2 Please note: This port does not support MHL devices. HDMI 3 Please note: This port does not support MHL devices. ® All Rights Reserved. SkyVue...
  • Page 15 14. CVBS - Composite video is usually in standard formats such as NTSC, PAL, and SECAM and is often designat- ed by the CVBS initialism, for color, video, blanking and sync, or simply as video. Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L TV I & C nsTallaTIon...
  • Page 16 Switching Inputs: Your SkyVue TV offers several options when connecting your Cable Name Cable End Images devices to the TV. The chart below will help you understand which input you select for each of the connections. HDMI or HDMI-DVI Connections...

  • Page 17: D Etachable S Peakerbar

    7. Plug in power cord only after all other connections are made. 8. Optional - Speaker bar my also be plugged into axullery power plug found inside the componet compart- ment. SPEAKER BAR Do Not Remove Figure 1 Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L TV I & C nsTallaTIon onneCTIons...
  • Page 18 Installation / Mounting Notes Figure 1 Figure 2 Remove for Speakerbar Do Not Remove Figure 3 Figure 4 Figure 5 ® All Rights Reserved. SkyVue...
  • Page 19 TV might lose picture or sound. This TV will turn off automatically if there’s no signal present for more than 15 minutes. Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L TV I & C nsTallaTIon...
  • Page 20 Refer to the DVD/Blu-ray player’s manual to make sure the DVD/Blu-ray player is configured to output correctly to the TV. This TV will turn off automatically if there’s no signal present for more than 15 minutes. ® All Rights Reserved. SkyVue...
  • Page 21 7. Turn on the TV and your set-top box. 8. Use the remote control’s input button or the input button on the TV to switch to componet. Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L TV I & C nsTallaTIon onneCTIons...
  • Page 22 The TV will turn off automatically if there’s no signal present for more than 15 minutes. If HDMI 1 is already occupied, use HDMI 3 as your connection port, and switch source to HDMI 3. Located on Back of TV ® All Rights Reserved. SkyVue...
  • Page 23 The VGA port of the TV features a power saving mode which will automatically turn off the TV if there is no signal provided for more than 15 minutes. Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L TV I & C nsTallaTIon...

  • Page 24: Front Panel Lights And Sensors

    120V, 60HZ power source at all times. Manual Controls Panel The Side or Bottom Control Panel can be found by reaching your hand on the underside of the SkyVue logo . Location of Manual Controls Panel This button switches between the different sources of the TV. When the On-Screen Display (OSD) is active, this INPUT button acts as the enter button and confirms the menu selection.

  • Page 25: Remote Control Guide

    CH +/ - Push to go up or down in channel numbers Numbers - Push these to enter channel numbers and passwords Sleep - Push to activate the sleep timer ./- Push to enter channels The SkyVue Remote Control is weatherproof For use with Streaming Stick Devices: = Home...

  • Page 26: On-Screen Display (Osd) Functions

    Vol+ and Vol- to select a choice. Vol(-) - This button decreases the volume and functions as right direction in the OSD. If the OSD is active, use Vol+/Vol- to select a choice. ® All Rights Reserved. SkyVue...

  • Page 27: On-Screen Display Menu

    Zoom Mode Brightness 3D Noise Reduction Sharpness Backlight Tint Color Audio Menu This menu manages Audio functions including: Equalizer mode Equalizer frequencies MTS Stereo mode Audio Language Digital Output type Surround Sound Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L creen iSplayS...

  • Page 28: Time Menu

    HDMI Mode Closed Caption Ambient Light Sensor Restore Default Ambient Sensor Value Setup Wizard Auto Backlight Floor Software Update Backlight Sensor Floor Lock Menu This menu manages Lock functions including: System Lock Change Password Input Block ® All Rights Reserved. SkyVue...

  • Page 29: Adjusting On-Screen Displays - Channel Menu

    To delete a channel from your favorites list, press the buttons to highlight the channel. Press the button delete the channel from your favorites. The red heart next to the channel will disappear. Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L djusting creen isplAys...
  • Page 30 Channel No. item of the menu. The longer the horizontal bar appears, the better the signal strength. If the signal strength is extremely poor, no meter will appear and the menu will simply say Bad. ® All Rights Reserved. SkyVue...

  • Page 31: Adjusting On-Screen Displays - Picture Menu

    Tint adjustment is not supported on this model. Color Press the buttons to highlight the Color adjustment, then use to adjust color satura- tion. This control is active only when Personal picture mode is selected. Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L djusting creen isplAys...

  • Page 32: Adjusting On-Screen Displays - Audio Menu

    VOL+/VOL- on the TV to make the desired adjustments. 3. When adjustments are complete, press MENU or EXIT on remote or MENU on the TV to exit the main menu. ® All Rights Reserved. SkyVue...
  • Page 33 10 kHz (upper treble) audio band. This adjustment is available only when Personal sound mode is selected. This function is supported only with analog broadcast signals,which are no longer used in the U.S. Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L djusting creen isplAys...

  • Page 34: Adjusting On-Screen Displays - Time Menu

    VOL+/VOL- on the TV to make the desired adjustments. 3. When adjustments are complete, press MENU or EXIT on remote or MENU on the TV to exit the main menu. ® All Rights Reserved. SkyVue...
  • Page 35 (day, hour, minute, etc.), then use to make the adjustment. Repeat until the desired wake up time is set. Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L djusting creen isplAys...

  • Page 36: Adjusting On-Screen Displays - Setup Menu

    CC Mode submenu shown at left. Pressing will now select among the three closed caption modes: Off, On and CC on Mute. The last option shows captions only when mute is activated. ® All Rights Reserved. SkyVue...
  • Page 37 Setup Wizard. When you have finished with the third Setup Wizard screen, the Setup Wizard will automatically activate Auto Scan to identify and memorize the channels that can be received. Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L djusting creen isplAys...

  • Page 38: Adjusting On-Screen Displays - Lock Menu

    Software Update (USB) This function is used to update the software on your TV. Consult SkyVue Outdoor TV for more information. Blue Screen Press the buttons to highlight the Blue Screen adjustment, then use to activate or deactivate the blue screen that appears when no signal is available at the selected input.
  • Page 39 (0000 unless you previously changed it), then enter the new password twice. If you enter a new password but forget it later, contact SkyVue Outdoor TV for assistance. Operator’s Manual - Model...
  • Page 40 If an input is blocked, using it will require entering the system password. Canada RRT Setting Reset RRT These functions are not adjustable and are for service use only. ® All Rights Reserved. SkyVue...

  • Page 41: Sing The Usb I Nput

    USB stick, or to the folders on the stick that the media is stored in. If folders appear, press to highlight the folder you want, then press to open the folder. Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L UsB i sing the npUt...
  • Page 42 Listening to Music from the USB Stick to highlight the song you want to listen to, then press to play the song. The song will begin playing and a text screen that shows data about the file will appear. ® All Rights Reserved. SkyVue...
  • Page 43 TVs to power up and show the picture. shows up slowly Make sure you have a 3.5 mm mini-jack cable connected from your PC’s sound output to No sound from PC the TV’s VGA Stereo Input. Operator’s Manual - Model NXG-DS|4k-4350-L / 4k-4370-L roubleshooTing roblems...
  • Page 44 This is common to all LED screens used in display and television color products, and is not specific to SkyVue Outdoor TV’s. For more information, see SkyVue Outdoor TV’s’s Pixel Quality Policy in this manual. Switching a channel Different channels and inputs sometimes have this effect because the channel signal’s...

  • Page 45: Care Of Skyvue Outdoor Tv

    (do not spray the solution directly on the panel) and gently clean the panel. A “special outdoor formula” LED Cleaning Kit is now available and can be ordered from SkyVue Outdoor When the TV is not in use, keep it covered with a Deluxe SkyVue Outdoor TV Cover: When the unit is not being used, the SkyVue team strongly recommends using the all weather protective cover.

  • Page 46: Specifications

    Available in nine designer colors. • 2 Year Parts and Labor Warranty applies to all SkyVue NXG Series Outdoor Televisions. 1) Satin Black, 2) White, 3) Dark Brown, 4) Slate Gray, 5) Sandstone, 6) Mint Green, 7) Hunter Green, 8) Terra Copper, 9) Patriot Blue *All dimensions shown are for planning purposes only.
  • Page 47 Available in nine designer colors. • 2 Year Parts and Labor Warranty applies to all SkyVue NXG Series Outdoor Televisions. 1) Satin Black, 2) White, 3) Dark Brown, 4) Slate Gray, 5) Sandstone, 6) Mint Green, 7) Hunter Green, 8) Terra Copper, 9) Patriot Blue *All dimensions shown are for planning purposes only.

  • Page 48: Tv Care & Policy Information

    TV Care & Policy Information Extreme Climate Warning If temperatures below -24º F are expected, we recommend that you bring your SkyVue Outdoor TV inside to prevent damage to the LED screen. SkyVue Outdoor TV Pixel Quality Policy (Applicable to LED TVs sold within USA and Canada only.) SkyVue Outdoor TV LED screens are manufactured with rigorous standards to maintain optimal viewing.

  • Page 49: Rs232 Control Codes

    RS232 Control Codes Baud Rate: 38400/ Bits: 8/ Parity: None/Stop Bit: 1 Command Code Sequence: A0 F0 55 FF <IR Code> <Check Sum> The time of the command sequence must be < 500 ms. The interval time of two continuous command sequences must be > 500 ms. Mute: A0 F0 55 FF 14 EB AV Input...
