Ozito PX2DB-215 Instruction Manual
Ozito PX2DB-215 Instruction Manual

Ozito PX2DB-215 Instruction Manual

Cordless blower / inflator

Advertisement

Quick Links

CORDLESS
BLOWER /
INFLATOR
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage:
18V
No Load Speed:
15,500/min
Max. Air Speed:
78km/hr
Charge Time:
30mins (1.5Ah)
Weight:
1.0kg
ozito.com.au
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other than that specified
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
OZITO
Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
WARRANTY
The benefits provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty and are excluded from the warranty extension. Warranty excludes
consumable parts, for example: blower tube.
WHAT'S IN THE BOX
Cordless Drill Driver
Cordless Blower / Inflator
Inflation Adapters & Extension
Nozzle
2 x 1.5Ah Batteries
Fast Charger
PX2DB-215
0517

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PX2DB-215 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ozito PX2DB-215

  • Page 1 30mins (1.5Ah) Weight: 1.0kg ozito.com.au Fast Charger PX2DB-215 WARRANTY IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU The benefits provided under this warranty are in addition to other rights and remedies which are available to you at law.
  • Page 2: Know Your Product

    KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS BLOWER / INFLATOR 1. BATTERY & CHARGING (PXWBS-200) 1 Blower Nozzle 5 Battery Seating 2 Blower Housing 6 Inflation Adaptors x 3 CAUTION: THE CHARGER FOR THIS PRODUCT SHOULD BE PROTECTED BY A RESIDUAL CURRENT 3 On/Off Switch 7 Extension Nozzle DEVICE (RATED AT 30mA OR LESS).
  • Page 3: Battery Charge Indicator

    2. FITTING THE BATTERY Charging your lithium ion battery - Eco Charger Inserting & Removing the Battery 1 Connect the charger into a mains power outlet. 1 Align the ribs of the battery with the recess at the rear of the blower and 2 The charger LED will flash green push in until it clicks into place.
  • Page 4: Operation

    OPERATION 3. ASSEMBLY 4. CONTROLS WARNING! DO NOT USE THE BLOWER WITH ANY WARNING! ENSURE THE TOOL IS SWITCHED OFF AND DISCONNECTED FROM THE POWER SUPPLY BEFORE ACCESSORIES OR ATTACHMENTS OTHER THAN THOSE PERFORMING ANY OF THE FOLLOWING TASKS. SUPPLIED. SUCH USAGE MIGHT BE HAZARDOUS. Connecting the Blower Nozzle or Extension Nozzle Switching On and Off 1 The blower end is equipped...
  • Page 5 ENSURE THE BLOWER OUTLET IS NOT BLOCKED DURING USE. 5 Fit small end of adaptor to the inlet on the device to be inflated. Once fitted, use On/ Off switch to inflate device. 6 To Remove adaptor, turn in anti-clockwise direction. PX2DB-215...
  • Page 6: Maintenance

    To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning. Removing the battery pack will not reduce this risk. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the Never attempt to connect 2 chargers together.
  • Page 7: Electrical Safety

    Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.
  • Page 8 BLOWER / INFLATOR SAFETY WARNINGS • Always wear adequate protective clothing when operating the blower to avoid injuries to face, eyes, • Do not get distracted and always concentrate on what you are doing. Use common sense. Never hands, feet, head or hearing. Use safety glasses or a face shield, high boots or sturdy shoes, long operate the tool when you are tired, sick or under the influence of alcohol or other drugs.
  • Page 9: Warranty

    30mins (1.5Ah) Weight: 1.1kg ozito.com.au Fast Charger PX2DB-215 WARRANTY IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU The benefits provided under this warranty are in addition to other rights and remedies which are available to you at law.
  • Page 10 KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS DRILL DRIVER 1. BATTERY & CHARGING (PXDDS-201) 1 Keyless Chuck 5 Belt Clip CAUTION: THE CHARGER FOR THIS PRODUCT SHOULD 2 Torque Adjustment Collar 6 Forward/ Reverse Lever BE PROTECTED BY A RESIDUAL CURRENT DEVICE 3 Variable Speed Trigger 7 Gearbox speed selector (RATED AT 30MA OR LESS).
  • Page 11: Battery Installation

    2. BATTERY INSTALLATION Installing the Battery Pack Charging your lithium ion battery - Eco Charger 1 Connect the charger into a mains power outlet. 1 Slide the battery into the drill base until it clicks into place. 2 The charger LED will flash green showing power is being supplied to the charger.
  • Page 12: Forward/ Reverse Lever

    OPERATION 3. KEYLESS CHUCK 4. CONTROLS Forward/ Reverse Lever WARNING! Ensure the tool is turned off & disconnected from the power supply before performing any of the following operations. 1 For forward rotation, push the fwd/rev lever towards the left side of the drill. For reverse rotation push fwd/rev lever to the right.
  • Page 13: Helpful Tips

    This measure will prevent the drill bit from slipping off centre as you start the the drill do all the work. hole. When drilling metals, use light oil on the drill bit to keep it from overheating. The oil will prolong the life of the bit and increase drilling action. PX2DB-215...
  • Page 14 Variable speed trigger is locked Note: Ozito Industries will not be responsible for any damage or injuries caused by repair of the drill by an unauthorised person or by mishandling. Ensure that the forward / reverse lever is in the correct position; pressed left for forwards direction, pressed right for backwards direction.
  • Page 15 This charger is not intended for any uses other than charging rechargeable batteries. Any other use may result in risk of visit www.ozito.com.au or contact Ozito Customer fire, electric shock or electrocution. Do not place any object on top of the charger or place the charger on a soft surface that may result in excessive internal Service: heat.
  • Page 16: Drill Driver Safety Warnings

    The power supply for this products charger should be protected by a residual current device (rated at 30mA or less). A residual current Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
