Appearance
Feature
No need to install any software, support control computer by hot key/ button/ remote
◎
controll.
USB port KVM switch.
◎
LED light shows work status.
◎
Support add or remove units over plug and play without shut off the switch.
◎
Apply to DVR, ect.
◎
ZWAY HDMI- KVM
KHU-0401
KHU-0801
Advertisement
Table of Contents
Related Manuals for EKL KHU-0401
Summary of Contents for EKL KHU-0401
- Page 1 ZWAY HDMI- KVM Appearance KHU-0401 KHU-0801 Feature No need to install any software, support control computer by hot key/ button/ remote ◎ controll. USB port KVM switch. ◎ LED light shows work status. ◎ Support add or remove units over plug and play without shut off the switch.
- Page 2 Connection Diagram (Take KHU-0401 for example) HDMI Signal Sources Display Device HDMI HDMI Input Output HDMI Input HDMI Input USB Input USB Input HDMI HDMI Input Input Power in keyboard & mouse remote controller HDMI Signal Sources Use Manual ◎Make sure all cables are properly connected before turning.
- Page 3 使用方法 Operation 1. Connect signal source , display device, keyboard and mouse correctly. 2. Switch method: directly switch by switch button or Hot Key. Hot Key : 1.Double Click Scroll Lock into Control state, at the same time, the switch make two sounds “di...di...”...
- Page 4 Performance Parameter 性能参数 HDMI Video port,USB keyboard mouse port Output Interface 4/8 way HDMI video port,4/8 way USB port Input Interface Button swich, hot key, remot control switch Switch way Keyboard mouse USB port Automatic scanning 6 seconds (settable) interval Resolution 1920*1440 or 1080P 2.55GHZ...
