Installer: Leave this manual with the proud new owner
*
*
Also be sure to check the grill box completely for ALL parts
including the rotisserie spit rod (if applicable)
Renaissance Cooking Systems
Owner's Manual
For Outdoor Use Only
America's Best Value in Outdoor Kitchen Equipment
Installation, Operation, Maintenance
Instructions & Parts List
Models:
RJC26A, RJC32A, RJC32AL, RJC40A,
RJC40AL, RON30A, RON38A & RON42A
These grills are tested and certified to the ANSI-Z21.58/CSA 1.6.standards.
This owner's manual was updated August 30, 2019
For the latest news, recipes and cooking tips for your new
Renaissance Cooking Systems grill, check out www.RCSGasGrills.com
1 |
P a g e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RJC32A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RCS RJC32A

Summary of Contents for RCS RJC32A

  • Page 1 America's Best Value in Outdoor Kitchen Equipment Installation, Operation, Maintenance Instructions & Parts List Models: RJC26A, RJC32A, RJC32AL, RJC40A, RJC40AL, RON30A, RON38A & RON42A These grills are tested and certified to the ANSI-Z21.58/CSA 1.6.standards. This owner’s manual was updated August 30, 2019 For the latest news, recipes and cooking tips for your new Renaissance Cooking Systems grill, check out www.RCSGasGrills.com...

  • Page 2: Table Of Contents

    For any assistance, contact us. Make sure to provide the Model Number and Serial Number of the grill which is located on the right or left hand side of the control panel depending on model: RJC26A, RJC32A, RJC32AL, RJC40A & RJC40AL – left side Premier Series: Cutlass Pro Series: RON30a, RON38a &...

  • Page 3: For Your Safety

    Safety and Installation Instructions GRILL INSTALLATION This gas grill must be installed in accordance with all local codes. If installation is planned in an area with no local codes, the gas grill must be installed in accordance with the National Fuel Gas Code ANSI Z223.1 and storage and handling of liquefied petroleum gases, ANSI/NFPA 58 or CSA B149.1 natural gas and propane installation code.
  • Page 4 FOR YOUR SAFETY 1. Do Not store or use gasoline, caustic or other flammable vapors and liquids in the vicinity of this or any other appliance. 2. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance..
  • Page 5 Wind Guard: WARNING! Your RCS grill should NOT be installed with the back of the grill facing frequent, prevailing winds like a large body of water or open space unless there is a substantial back splash or some way of blocking the wind.
  • Page 6 Adequate Ventilation: Ensure there is adequate ventilation for both the barbecue, cylinder and all appliances located in this cabinet. Adequate ventilation is required for proper combustion and to prevent gas build up. Kitchen vents (RVNT1) are required every 4 feet to help ventilate and prevent dangerous gas build up, remove excess heat, add air to help with air/fuel mix for the grills and allows moisture/ condensation to evaporate.
  • Page 7 P a g e...

  • Page 8: Safety Rules

    Clean grease tray often so that grease does not accumulate and stay in it which may cause a fire. • Do not operate the grill in a windy area. For windy areas we recommend the RCS Wind Guard. (see page 13) •...

  • Page 9: First Time Operation

    ALSO-the temperature at the cooking surface is significantly higher than what the heat indicator shows in the lid. Your RCS grill has been designed and manufactured to provide optimum cooking temperatures across a wide range of foods, without “cooking itself to death!”...
  • Page 10 DO NOT connect high pressure to this grill. This grill uses low pressure 1/2" psi to operate. You MUST use the regulator(s) that are available from RCS. An intermediate (step- down) regulator may be necessary. Check with your gas supplier if you are not sure.

  • Page 11: Gas Barbecue Specifications

    11” – 14” W.C. Purchase a standard 20 LB. LP tank with QCC – 1 fitting, and an approved hose and low pressure regulator like the RCS: RONHK. (Available From Your RCS Dealer) Assemble pipe/hose assembly as shown (not included).

  • Page 12: Lp Tank Requirement

    To connect, insert the regulator inlet into the tank valve and turn the black coupler clockwise until the coupler tightens up. DO NOT OVER TIGHTEN THE COUPLER. After completion of assembly, make sure all appliance control valves are OFF then turn the propane tank supply valve on and then turn the control valves on the grill to the ‘HI/IGN’...
  • Page 13 Sides of the grill can be 0” from non-combustible wall, below the cooking surface. Wind Guard: WARNING! Your RCS grill should NOT be installed with the back of the grill facing frequent, prevailing winds like a large body of water or open space unless there is a substantial back splash or some way of blocking the wind.
  • Page 14 12 square inches of opening for each (running) 4 feet of counter top. See Item # RVNT1 for approved vents. In the event of an installation in a combustible (wooden) cabinet, you must use an insulated jacket available from RCS. 14 |...
  • Page 15 “B” Depth Model “C” Height “A” Width 21 1/4" RJC26A 23 1/2” 8 ¼” RJC32A / RJC32AL 21” 30 5/8” 8 ¼” RJC40A / RJC40AL 37 3/4” 21” 8 ¼” RON30A 33” 20” 11” 41 1/4” RON38A 20” 11” RON42A 20”...
  • Page 16 Exhaust Hood Requirements When using an exhaust hood, the area above the cooking surface of the grill must be covered with a hood larger than the cooking area of the grill, AND with a minimum of 1200CFM (cubic feet per minute) for proper outdoor application.
  • Page 17 If adding a side burner to your connection: Electrical Electrical outlet for Rotisserie motor must be installed to the left side of the grill. The outdoor cooking gas appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1.

  • Page 18: Electrical/Wire Diagram

    Cutlass Pro Electrical Wire Diagram P a g e...
  • Page 19 Premier Series Electrical Wire Diagram Connector Connector Black White Black White Black LED Switch White Black White Connector RJC32AL 5 LEDS 2 HALOGEN LIGHTS RJC40AL 6 LEDS 2 HALOGEN LIGHTS 19 | P ag e...

  • Page 20: Burner Adjustments

    Leak Testing NEVER USE AN OPEN FLAME TO CHECK FOR LEAKS. All gas piping and connections must be tested for leaks after installation or service. All leaks must be corrected immediately. Remember-before exchanging an empty bottle for a new one, make sure all control valves are in the “off”...

  • Page 21: Lighting Instructions

    If flame is lifting, remove the front panel to access the burner front (air shutter) then turn the air shutter clockwise reducing this intake. The screw should be loosened before turning the air shutter. If the flame has more yellow than blue, the air shutter should be turned counter clockwise allowing more air in.

  • Page 22: Operation

    Optional Infred Burner 1. To install the optional infrared burner, begin by removing the far left cooking grid, flame tamer and zone divider, if applicable. 2. Remove conventional burner by first removing the cotter pin or screws that hold the burner in place (unless they were removed prior to installation), located on the bottom rear of the burner and located inside the rear of the grill body.

  • Page 23: Cleaning And Maintenance

    Cleaning and Maintenance Your grill works better and lasts longer if properly cleaned and maintained. Cleaning: Clean the grill after each use. Turn grill off before starting to clean. Protect your hand with a good mitt when cleaning the hot grill. Use a wire brush, dip in water and scrub the cooking grids to soften and loosen food spills.
  • Page 24 • For seasonal storage use the product referred to above, ensure the grill is dry, then cover and secure the cover to minimize the amount of damp air getting to the surfaces Fuel (Gas) Conversion Instructions for RCS grills. This should only be performed by a licensed gas professional Gas regulator: Currently all grills are supplied with a gas regulator installed.
  • Page 25 Fuel Conversion of Main Burners: 1- Determine the existing gas type (LP or Natural gas). The method of changing gas types is similar for natural gas or propane gas. 2- You must remove all grates and burner covers to expose the main burners in the grill. 3- On the bottom rear of each burner may be a cotter pin or screws attaching burners to the grill housing.
  • Page 26 “Rear burner won’t light” Solution: Visit the RCS website, under documents watch the video about how to light your rear burner. GREAT video there.
  • Page 27 RJC26A/RJC32A/RJC40A Enlarged View P a g e...
  • Page 28 RJC26A/RJC32A/RJC40A Parts List QTY. ITEM PART NO. DESCRIPTION RJC26A RJC32A RJC40A RJC001P 26"-TOP HOOD RJC002P 32"-TOP HOOD RJC051P 40"-TOP HOOD RJC003P ACCESS DOOR RJC004P 26"-REAR HOOD RJC005P 32"-REAR HOOD RJC052P 40"-REAR HOOD RJC006P 26"-WARMING RACK RJC007P 32"-WARMING RACK RJC053P 40"-WARMING RACK...
  • Page 29 RJC32AL / RJC40AL Enlarged View 29 | P a g e...
  • Page 30 RJC32AL/RJC40AL Parts List QTY. ITEM PART NO. DESCRIPTION RJC32AL RJC40AL RJC002P 32"-TOP HOOD RJC051P 40"-TOP HOOD RJC003P ACCESS DOOR RJC062P 32"-REAR HOOD RJC063P 40"-REAR HOOD RJC007P 32"-WARMING RACK RJC053P 40"-WARMING RACK RJC008P TOP GRATE RJC009P BRIQUETTE TRAY RJC010P CROSSOVER TUBE RJC011P BURNER RJC064P...
  • Page 31 RON30a/RON38a/RON42a Enlarged View c· IP age...
  • Page 32 FLEX TUBE-IR BURNER 1050mm RON014 36”-ORIFICE(NG 1.6)-IR BURNER RON102 CONTROL KNOB RON015 ORIFICE ELBOW NUT RON103 BEZEL RON016 ORIFICE ELBOW RON050 LOGO PLATE-RCS RON080 30”-WARMING RACK RON104 LIGHT SWITCH RON115 38”-WARMING RACK RON105 LED LIGHT SWITCH RON081 42”-WARMING RACK RON106 30 “-LIGHT WIRE...
  • Page 33 Improper maintenance, salt spray, chemicals, pesticides will effect the look and integrity of the components. RCS will not be responsible for any damage caused as a result of not following owner’s manual instructions. This non-transferable warranty is limited to the replacement of original (one-time) defective parts, does not include shipping and labor to remove or install replacement parts, if necessary.
