Components
Item Qty Component
1
1
Body
2
2
Wall bracket
3
2
Olive
4
2
Compression face
5
2
Concealing plate
6
2
Sealing washer
4
Technical Data
The Nulo thermostatic shower valve is suitable for installations on all types of plumbing
systems, including gravity supplies, fully pumped, modulating combination boiler, unvented
water heater and unbalanced supplies i.e. Cold Mains
for non-modulating combination boilers.
Max Inlet Pressure (Static)
Max Inlet Pressure (Dynamic)
Min Operating Pressure (Dynamic) 0.2 bar
Max Unbalanced Pressure Ratio
Inlet Connections (Body only)
Outlet Connection
© Intatec Ltd 2017
2 3
8
11 12
10 bar
5 bar
5:1
G¾"
Bottom
G½"
Item Qty Component
7
2
Circlip
8
2
Filter
9
2
Check valve
10
2
Connector
11
2
Union nut
12
2
'O' ring seal
5
6
Tank Fed Hot. They are not suitable
Max Inlet Temperature
Pre Set Factory Temp Setting
Temperature Stability
Min Temp Differential to
ensure fail-safe between hot
and cold supplies
2
7
9
10
1
85˚C
38˚C
± 2˚C
10˚C
