OWNER'S MANUAL
LG Gaming Computer Monitor
(LED COMPUTER MONITOR*)
* Disclaimer : LG LED Monitor applies LCD screen with LED backlights.
This product is a computer monitor and not for television purpose.
Please read this manual carefully before operating your set and retain it
for future reference.
34GN850
34GN85B
www.lg.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LG 34GN85B
Summary of Contents for LG 34GN85B
- Page 1 LG Gaming Computer Monitor (LED COMPUTER MONITOR*) * Disclaimer : LG LED Monitor applies LCD screen with LED backlights. This product is a computer monitor and not for television purpose. Please read this manual carefully before operating your set and retain it for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS LICENSE ........3 USB Cable connection Connecting Headphones ASSEMBLING AND PREPARING 4 USER SETTINGS ....... 17 - Supported Drivers and Software ......4 - Activating the Main Menu ........17 - Product and Button Description......5 Main Menu Features How to Use the Joystick Button - User Settings ...............19 - Moving and Lifting the Monitor......6 Menu Settings... -
Page 3: License
LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. -
Page 4: Assembling And Preparing
The power cord provided may differ depending upon the region. • It is recommended that use the supplied components. • If you use generic cables not certified by LG, the screen may not display or there may be image noises. Supported Drivers and Software •... -
Page 5: Product And Button Description
Product and Button Description How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with your finger. Basic Functions Press the joystick button once with Power on your finger to turn on the monitor. -
Page 6: Moving And Lifting The Monitor
Moving and Lifting the Monitor When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. • Place the monitor in the original box or packing material before attempting to move it. -
Page 7: Installing On A Table
Installing on a Table • If you use the monitor panel without the stand base, its joystick button may cause the monitor to become unstable and fall, resulting in damage to the Lift the monitor and place it on the table in an upright position. Place the monitor or human injury. -
Page 8: Adjusting The Stand Height
Adjusting the Stand Height Adjusting the Angle Place the monitor mounted on the stand base in an upright position. Place the monitor mounted on the stand base in an upright position. Handle the monitor with both hands for safety. Adjust the angle of the screen. The angle of the screen can be adjusted forward or backward from -5°... - Page 9 NOTE WARNING • The left or right side of the monitor head can be slightly rotated up or down (up • To avoid injury to the fingers when adjusting the screen, do not hold the lower to 3°). Adjust the horizontal level of the monitor head. part of the monitor’s frame as illustrated below.
-
Page 10: Tidying Up Cables
Tidying up Cables Using the Kensington Lock Arrange the cables using the cable holder as shown in the illustration. The connector for the Kensington security system is located at the bottom of the monitor. For more information on installation and usage, refer to the Kensington lock owner’s manual or visit the website at http://www.kensington.com. -
Page 11: Installing The Wall Mount Plate
Installing the Wall Mount Plate Installing on the Wall This monitor meets the specifications for the wall mount plate or other compatible Install the monitor at least 100 mm away from the wall and leave about 100 mm devices. of space at each side of the monitor to ensure sufficient ventilation. Detailed installation instructions can be obtained from your local retail store. - Page 12 The length of the screw may differ for each wall mounting bracket. Be sure to A non-VESA standard screw may damage the product and cause the monitor use the proper length. to fall. LG Electronics is not liable for any accidents relating to the use of non- standard screws. •...
- Page 13 • Use the wall mounting bracket and screws that conform to VESA standards. Damage caused by the use or misuse of inappropriate components will not be covered by the product warranty. • When measured from the back of the monitor, the length of each installed screw must be 8 mm or less.
-
Page 14: Using The Monitor
USING THE MONITOR Connecting to a PC • This monitor supports the *Plug and Play feature. • Illustrations in this manual may differ from the actual product * Plug and Play: A feature that allows you to add a device to your computer Press the joystick button, go to Settings →... -
Page 15: Displayport Connection
Connecting Peripherals DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. USB Cable connection NOTE The USB port on the product functions as a USB hub. To use USB 3.0, connect the A-B type USB 3.0 cable of the product to the PC. •... -
Page 16: Connecting Headphones
Connecting Headphones Connect peripherals to the monitor via the headphones port. NOTE • Peripheral devices are sold separately. • If you use angled earphones, it may cause a problem with connecting another external device to the monitor. Therefore, it is recommended to use straight earphones. -
Page 17: User Settings
USER SETTINGS Button Menu Status Description Main menu disabled Enables the main menu. Exits the main menu. Activating the Main Menu (Holding down the button to turn off the monitor. You can Main menu enabled turn off the monitor this way at any time, including when the Press the joystick button on the bottom of the OSD is on.) monitor. -
Page 18: Main Menu Features
Main Menu Features Main Menu Description Input Sets input mode. Power Off Power Off Turns off the monitor. Settings Configures the screen settings. Input Exit Settings Game Mode Sets the game mode for gaming. Exit Exits the main menu. Game Mode... -
Page 19: User Settings
User Settings Menu Settings To view the settings menu, press the joystick button at the bottom of the monitor and then enter the Settings. Configure the options by moving the joystick up/down/left/right. To return to the upper settings or set other settings items, move the joystick to or press ( ). - Page 20 Game Mode on SDR(Non-HDR)signal. Settings > Game Mode Description Gamer 1 In this mode, users can customize elements including game-related options. Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup Gamer 2 options.
- Page 21 Game Mode on HDR signal. Settings > Game Mode Description Gamer 1 In this mode, users can customize elements including game-related options. Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup Gamer 2 options.
- Page 22 Settings > Game Adjust Description Sets Overclock to a higher refresh rate than specified by the panel specification. Disables the Overclock improvement feature. NOTE • After the monitor reboots, change the maximum refresh rate setting in the GPU control panel. Game Adjust Overclock •...
- Page 23 Provides seamless and natural images by synchronizing the vertical frequency of the input signal with that of the output signal. CAUTION • In HDMI input, the menu name is displayed as certified AMD FreeSync Tier name instead of Adaptive-Sync. (FreeSync / FreeSync Premium / FreeSync Premium Pro) •...
- Page 24 Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Fast. For a fast-moving picture, it is recommended that you use Faster. Setting to Faster may cause image sticking. Response Time Faster Sets the response time to Faster.
- Page 25 Settings > Picture Adjust Description Brightness Adjusts the brightness of the screen. Contrast Adjusts the contrast of the screen. Sharpness Adjusts the sharpness of the screen. Mode 1, Mode The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the 2, Mode 3 lighter the image becomes.
- Page 26 Sets the offset level (for HDMI only). y Offset: as a reference for a video signal, this is the darkest color the monitor can display. Black Level High Keeps the current contrast ratio of the screen. Lowers the black levels and raises the white levels from the current contrast ratio of the screen. Picture Adjust Adjusts the brightness automatically according to the screen.
- Page 27 Settings > Input Description Input Selects the input mode. Adjusts the aspect ratio of the screen. Full Wide Displays the video in widescreen, regardless of the video signal input. Original Displays video according to the aspect ratio of the video signal input. Just Scan The aspect ratio is not adjusted from the original.
- Page 28 Settings > General Description Language Sets the menu screen to the desired language. High Saves energy using the high-efficiency SMART ENERGY SAVING feature. SMART ENERGY Saves energy using the low-efficiency SMART ENERGY SAVING feature. SAVING Disables the SMART ENERGY SAVING feature. Turns the power LED on the bottom of the monitor on or off.
- Page 29 Provides global dimming effects depending on game or video content. Faster Preferably for PC gaming experiences. Fast Preferably for console gaming experiences. Normal Preferably for playing video content and internet or word-processing. Disables the Variable Backlight feature. Variable Backlight NOTE •...
-
Page 30: Troubleshooting
Have you installed the display driver? • Be sure to install the display driver from our web site: http://www.lg.com. • Make sure to check if the graphics card supports Plug and Play function. Some features are disabled. - Page 31 The screen retains an image. Does image sticking occur even when the • Displaying a still image for a prolonged time may cause damage to the screen, resulting in the retention of the image. monitor is turned off? • To extend the lifetime of the monitor, use a screensaver. Screen display is unstable and shaky.
- Page 32 The display color is abnormal. Does the display appear discolored • Set the color to 24 bit (true color) or higher. In Windows, go to Control Panel > Display > Settings > Color Quality. (The (16 colors)? settings may differ depending on the operating system (OS) you use.) Does the display color appear unstable or •...
-
Page 33: Product Specification
PRODUCT SPECIFICATION LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Color Depth HDMI 10-bit color is supported. DP (DisplayPort) 10-bit color is supported. Pixel Pitch 0.2325 mm x 0.2325 mm Resolution Max Resolution DP:3440 x 1440 @ 144Hz DP:3440 x 1440 @ 160Hz (Overclock: On) HDMI:3440 x 1440 @ 85Hz Recommended Resolution... - Page 34 Dimensions Monitor Size (Width x Height x Depth) With Stand 819.2 x 574.1 x 312.2 (mm) Without Stand 819.2 x 361.6 x 104.4 (mm) Weight (Without Packaging) With Stand 7.6 kg Without Stand 5.5 kg Specifications are subject to change without notice. * The Operating Mode of Power Consumption is measured with LGE test standard.
-
Page 35: Factory Support Mode
Factory Support Mode (Preset Mode, HDMI/ DisplayPort PC) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 60.0 1152 x 864 54.347 60.05 1280 x 720 1280 x 1024 63.981 60.02... -
Page 36: Hdmi Timing (Video)
2560 x 1440 88.79 HDMI Only * DisplayPort only, Adaptive-Sync: On, Overclock: On HDMI Timing (Video) Factory support mode Vertical Frequency Remarks (Preset Mode) (Hz) 480p 720p 1080p 2160p HDMI Compatibility Mode: Off... - Page 37 Record them below in case you ever need service. download.LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and Model handling) upon email request to opensource@lge.com.
