  • Page 1 Order Number : GETEC-C1-18-270 FCC Part 15 Certification 1 / 1 Test Report Number : GETEC-E3-18-017 Page APPENDIX G : USER’S MANUAL EUT Type: Network keypad FCC ID.: OZ5URCTKP9600...
  • Page 2 TKP-9600 Owner’s Manual...

  • Page 3: Table Of Contents

    URC Home Page for downloads, training materials, and frequently asked questions. Installation......................4 Contact Support: Main Menu: Navigation..................6 Total Control is a URC product sold direct or through distribution. For questions or Title Bar........................7 assistance contact your Custom Installer/Programmer. Room’s Menu....................9 Room Linking....................10 My Installer/Programmer: Now Playing....................11...

  • Page 4: Features And Benefits

    Features and Benefits: The TKP-9600 In-Wall Network Keypad is one of URC’s most advanced devices that is optimized for usage with Total Control 2.0. Enjoy these key features: Updated User Experience: This device has the capability of using URC’s Total Control 2.0 software suite. Using this software provides this device with a modern “look and feel”...
  • Page 5 Proximity Sensor: This feature allows the TKP-9600 to spring into action automatically. Utilizing its proximity sensor, the keypad can detect distances from up to three (3) feet away. This setting can be adjusted in the device’s Settings menu. Flexible Orientation: The TKP-9600 offers the ability to display the device in either portrait or landscape mode making it the perfect keypad for almost any room.

  • Page 6: Parts List

    Part List: Included in the TKP-9600: 1x - TKP-9600 Network Keypad 4x - Mounting Screws 1x - Mounting Ring 4x - Spacers TKP-9600 Mounting Ring Mounting Screws Spacers...

  • Page 7: Installation

    Installation: The TKP-9600 is wall mountable and fits into a standard dual gang (J-box or Mud Ring) opening. Prior to installation, make sure power is available at the preferred location. Power can be supplied to the TKP-9600 through an Ethernet (RJ45) cable connected to a PoE (Power over Ethernet) in either of the following ways: ●...
  • Page 8 Wall Mounting: Follow the steps below for installation: 1. Assure the dual-gang opening is fitted with the standard two-gang Dual-Gang Box retro-box (available at almost any electronic supplier). Mounting Ring 2. Mount the wall-plate to the two-gang retro-box. TKP-7600 3. Connect the Ethernet cable to the rear of the supplied TKP-9600. 4.

  • Page 9: Main Menu Navigation

    Main Menu is dictated by the custom integrator. ● Right Swipe: Swipe right to reveal the Scenes Menu. The Scenes Menu contains URC Scenes that are created by the custom integrator. Return to the Main Menu by swiping left from the Scenes Menu.
  • Page 10 Ribbon View (Landscape & Portrait): Main Menu: View Modes Total Control 2.0 features two different view modes for the TKP-9600. Each view mode has its own unique properties that compliment the user experience. The view mode must be programmed from within the Accelerator 2.0 software, speak to a custom home integrator for more details.

  • Page 11: Title Bar

    Title Bar: The Title Bar is always present regardless of what menu and/or room the TKP-9600 is currently using. On the left of the Title Bar, the current room the TKP-9600 is controlling is Now Playing Current Room displayed. Selecting it reveals the Rooms Menu. At the right of the Title Bar is the Now Playing area.

  • Page 12: Room's Menu

    Room’s Menu: Tap on the Room Name located on the left in the Title Bar to display the Room’s Menu. The Room’s Menu contains every room programmed into the system. Specific rooms may be hidden from certain interfaces, speak to the custom home integrator for that option.

  • Page 13: Room Linking

    Room Linking: Remember, Room Linking can only be used by DMS Zones/Areas. The following steps take place from within the Room’s Menu: 1. Select the Room Link button, this displays the Room Linking Menu. 2. Select which rooms in the system to link. Only rooms that are DMS Zones/Areas appear on the Room Linking Menu.

  • Page 14: Now Playing

    Now Playing: On the right hand side of the Title Bar is the Now Playing area. The Now Playing area always dictates what activity is currently playing in the room. In the example at the right, Now Playing reads “SNP-2 Pandora”. This means that in the Home Theater the SNP-2 is using Pandora currently.

  • Page 15: Core Buttons

    Core Buttons: These buttons are almost always on display. Each one of these buttons has a specific function: 1. Volume: Used to control an active audio device. 2. Shortcut Popup: Use this to display the Shortcut Popup Menu. This menu contains up to six (6) current room activities. 3.

  • Page 16: Shortcut Popup Menu

    Shortcut Popup Menu: The Shortcut Popup Menu can holds the end-user’s favorite or most frequently used devices/activities and places them in one easy to access location. Adding Shortcuts: Follow these steps to add a Shortcut: 1. Locate an available button and hold it down until the status bar on the top of the display fills.
  • Page 17 Just tap on a Shortcut button to launch that device/activity. Remember, this menu can only hold up to six (6) items and each item must already be a device/activity programmed into that current room. Removing Shortcuts: Follow these steps to remove a Shortcut: 1.

  • Page 18: Status Bar

    Status Bar: Located above the Core Buttons, this section of the interface is almost always on display. The Status Bar is designed to inform the end-user of various different customizable options: 1. Metadata Information: Located to the far left, options selected from the programming software cycle through here.
  • Page 19 2. Page Indicator: The icons here represent the current page number the interface is on. However, the icon located to the left is the Scenes Menu icon. All icons to the right of that represent page numbers. 3. Time: This is always present on the right hand side of the interface.

  • Page 20: Intercom

    Intercom: The TKP-9600 has the capability of communicating across the home network to any Intercom-Enabled client (interface). There are three (3) different types of intercom calls that can be made: 1. Audio-Video: This type of call uses the camera and microphone of the calling and receiving client to provide auditory and visual feedback.
  • Page 21 4. Audio Broadcast Call: This type of call is audio communication between two or more clients. An ideal way to communicated across multiple Intercom-Enabled interfaces in almost any home.

  • Page 22: Navigating The Intercom Menu

    Navigating the Intercom Menu: As mentioned on page 8 of this document, accessing the Intercom button is performed by swiping down on the Title Bar. After selecting the Intercom button from the Title Bar Menu, the Intercom Menu displays. This menu presents the end-user with useful information: 1.

  • Page 23: Making Calls: Audio-Video

    Making Calls: Audio-Video Remember that the Intercom feature must be enabled from with in the Settings Menu. The following steps take place from the Intercom Menu, to access this menu refer to page 1. Select an available client from the Intercom Menu. After selecting a client, the three (3) call options are displayed.
  • Page 24 Once the call is accepted, the TKP-9600 provides auditory and visual two-way feedback on the screen. Use the Volume Slider at the right of the video feedback to raise or slower the volume. Slide the indicator to the top for maximum volume or slide it down to the bottom to mute the audio.

  • Page 25: Making Calls: Audio Calls

    Making Calls: Audio Calls Remember that the Intercom feature must be enabled from with in the Settings Menu. The following steps take place from the Intercom Menu, to access this menu refer to page 1. Select an available client from the Intercom Menu. After selecting a client, the three (3) call options are displayed.
  • Page 26 Once the call is accepted, the TKP-9600 provides two-way communication between clients via audio only. Use the Volume Slider at the right of the call icon area to raise or slower the volume. Slide the indicator to the top for maximum volume or slide it down to the bottom to mute the audio.

  • Page 27: Making Calls: Baby Monitor

    Making Calls: Baby Monitor Remember that the Intercom feature must be enabled from with in the Settings Menu. The following steps take place from the Intercom Menu, to access this menu refer to page 1. Select an available client from the Intercom Menu. After selecting a client, the three (3) call options are displayed.
  • Page 28 When using a Baby Monitor Call, the receiving client is not notified. It provides one-way communication from the receiving client to the calling client. Use the Volume Slider at the right of the video feedback to raise or slower the volume.

  • Page 29: Making Calls: Audio Broadcast

    Making Calls: Audio Broadcast Remember that the Intercom feature must be enabled from with in the Settings Menu. The following steps take place from the Intercom Menu, to access this menu refer to page 1. Select Broadcast Call. A list populates of all available Intercom-Enabled devices.
  • Page 30 Once the call is established, all selected devices communicate via audio. Use the Volume Slider at the right of the call icon area to raise or slower the volume. Slide the indicator to the top for maximum volume or slide it down to the bottom to mute the audio.

  • Page 31: Do Not Disturb Mode

    Do Not Disturb Mode: Enabling the Do Not Disturb feature sets the current TKP-9600 unavailable. This means that the keypad cannot receive any calls from other interfaces. To enable this feature, use the slider located at the right of the text Do Not Disturb.

  • Page 32: Scenes Menu

    Scenes Menu: The Scenes Menu is dictated by the system programmer. Access this menu by swiping to the right from the Main Menu. The Scenes Menu can contain up to a hundred (100) Scenes (buttons) per room. Keep in mind that the Scene Menu is unique to each room. Tap any button on the Scenes Menu to select a particular activity.

  • Page 33: Settings Menu

    Most settings do NOT require interaction with the end-user. Changing some settings could cause issues with the Total Control 2.0 system, only do so when instructed by URC Technical Support. These are the available options: ● Sleep Settings: Manage when the LCD screen turns OFF.
  • Page 34 Sleep Settings: Below are the selectable choices available in this menu: 1. LCD Screen is Always On: When selected, the TKP-9600’s display never turns off. 2. LCD Screen will Turn Off: When selected the Turn Off After section is selectable. Choose from a 20 second, 30 second, or one (1) minute time out.
  • Page 35 General: Using the left and right arrow keys, enter the values of each category: 1. Date: The following can have its value changed: ● Month ● Day ● Year 2. Time: The following can have its value changed: ● Hour ●...
  • Page 36 Sound: Brightness: Press the minus (-) button to lower the TKP-9600’s audio output or press the plus (+) Press the minus (-) button to lower the TKP-9600’s display brightness or press the button to increase the volume. plus (+) button to increase the brightness. Additionally, dragging the slider to the right increase the audio output while Additionally, dragging the slider to the right increase the display brightness while dragging it to the left decreases it.
  • Page 37 Proximity Sensor: Press the minus (-) button to lower the sensitivity on the TKP-9600’s Proximity Sensor or press the plus (+) button to increase the sensitivity. Additionally, dragging the slider to the right increases the sensitivity while dragging it to the left decreases it. The maximum distance of the proximity sensor is about three (3) feet.
  • Page 38 System Information: Although none of the information can be modified. These System Pages display important information about the TKP-9600. These pages are only needed by a custom install professional or by URC Technical Support.
  • Page 39 Network: This option displays important information about the current network. Caution, these settings should ONLY be changed by a professional. Entering values without specific instruction could easily result in the TKP-9600 failing to function correctly. Here is the information that can be displayed here: 1.
  • Page 40 Intercom: The Audio-Video Intercom Settings menu is the location where the Intercom features must be enabled. By default this feature is disabled, it must be enabled in order for the TKP-9600 to communicate with other Intercom- Enabled devices. ● Enable Intercom: Enables the audio intercom function. Once enabled, the Intercom icon is displayed when dragging down the Title Bar as see on page...
  • Page 41 Factory Default: This should only be attempted by a custom install professional that is familiar with Total Control 2.0 or under instruction from URC Technical Support. Selecting this option resets the TKP-9600 to its factory state and does not function until the device is reprogrammed by a custom install professional.

  • Page 42: Specifications

    Communications Commissions (“FCC”) regarding electromagnetic interference caused by electronic/computing devices and to the extent that the URC equipment and/or the URC software fails to so comply, URC shall, at its own expense, take all reasonable measures to promptly cause such to comply.
  • Page 43 URC equipment. This limited warranty specifically excludes the URC equipment sold by In the event of any warranty claim, URC will, at its sole option, repair the URC unauthorized resellers.
  • Page 44 POSSIBILITY OF SUCH DAMAGES. Federal Communication Commission IN NO EVENT SHALL URC BE LIABLE FOR LOSS OF OR DAMAGE TO DATA, Interference Statement COMPUTER SYSTEMS OR COMPUTER PROGRAMS. URC’S LIABILITY, IF ANY, FOR This equipment has been tested and found to comply with the limits for a Class B DIRECT DAMAGES OF ANY FORM SHALL BE LIMITED TO ACTUAL DAMAGES, digital device, pursuant to part 15 of the FCC Rules.
  • Page 45 Warning! Regulatory Information to the user Changes or modifications not expressly approved by the manufacturer could void ● CE conformity Notice the user's authority to operate the equipment. Products with “CE” marking comply EMC Directive 2014/30/EU issued by the Note : The manufacturer is not responsible for any Radio or TV interference caused commission of the European Community.
