User Manual for your Applico
GPP75L
75 cm Stainless Steel Powerpack Rangehood
NOTE: This user manual contains important information including safety &
installation points which will enable you to get the most out of your appliance.
Please keep it in a safe place so that it is readily available for future reference.
Advertisement
Table of Contents
Related Manuals for Applico GPP75L
Summary of Contents for Applico GPP75L
- Page 1 User Manual for your Applico GPP75L 75 cm Stainless Steel Powerpack Rangehood NOTE: This user manual contains important information including safety & installation points which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is readily available for future reference.
-
Page 2: Table Of Contents
Contents Environmental note Important safety information Specifications of your rangehood Using your rangehood Before first use To use your rangehood Cleaning your rangehood The grease filter Maintenance Removing and cleaning the grease filter Changing a light bulb Fitting the carbon filter Installation Electrical connection Before beginning installation... -
Page 3: Environmental Note
Environmental note Note: Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. -
Page 4: Important Safety Information
Important safety information Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Retailer where you purchased your unit from. - Page 5 o When installed between adjoining wall cabinets, the cabinets must not overhang the hob. o The edges of the rangehood are sharp – be mindful of this as you handle your appliance, especially during installation and cleaning. DO NOT CLEAN IN BEHIND THE GREASE FILTERS! o If the room where the rangehood is to be used contains a fuel burning appliance such as a central heating boiler then its flue must be of the sealed or balanced flue...
- Page 6 o Warning - Always ensure that the rangehood has been switched off before carrying out any work, including replacing light bulbs. o Do not connect the ducting system of this appliance to any existing ventilation system which is being used for any other purpose. o Do not install above a cooker with a high level grill.
-
Page 7: Specifications Of Your Rangehood
Specifications of your rangehood Product dimensions Height: 254mm Width: 750mm Depth: 296mm Your rangehood is fitted with: o Modern LED lighting (2 lamps) o Push buttons o A 3 speed fan o Brushed stainless steel finish o S/S panel Aluminium filter o 60dB min. noise level o 70dB max. noise level o 150mm diameter ducting outlet Extraction capacity: 700m³/hr... -
Page 8: Using Your Rangehood
online and for service. You can find the data plate behind the motor after removing the grease filter. For information on how to remove the grease filter, see page 8. Using your rangehood Before first use IMPORTANT: This process must be followed before the rangehood is used for the first time. -
Page 9: Cleaning Your Rangehood
IMPORTANT: Ideally you should switch on your rangehood ten minutes before you start to cook, or at the very least when you begin cooking. You should also run your rangehood for ten minutes after you have finished cooking. Cleaning your rangehood IMPORTANT: Before cleaning, always ensure that you have switched your rangehood off at the omni-polar switch, set at the wall from the cable. -
Page 10: Maintenance
Maintenance Removing and cleaning the grease filter o First remove the grease filter by sliding the securing nibs at the sides of the grille on the underside of the cooker hood. o Soak the grease filter in hot water and washing up liquid for about an hour. o Rinse it off thoroughly with hot water. -
Page 11: Fitting The Carbon Filter
o Press gently on the underside of the bulb that needs to be replaced and twist anticlockwise to release. o Replace in reverse order using only genuine spare part SYKL25. o IMPORTANT: Defective bulbs should be replaced immediately. o If the light still does not work, make sure that the internal plug is fitted properly before you call for technical assistance. -
Page 12: Electrical Connection
4) Reposition the metal grease filters. Installation IMPORTANT: Before installation read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the rating plate are exactly the same as the voltage and frequency in your home. The rating plate can be found behind the grease filters. -
Page 13: Before Beginning Installation
We recommend that the appliance is connected by a qualified electrician, who is registered with the EWRB and who will comply with ALL regulations. The wires in the mains lead are coloured in accordance with the following UK code: Blue = Neutral, Brown = Live, Green/Yellow = Ground If you can only find two wires in the cable (blue and brown), neither must be connected to the Earth terminal! As the colours of the wires in the appliance’s mains lead may not correspond with... -
Page 14: Installing Your Rangehood
thick, protective covering should be placed over the worktop, hob top or cooker. This will help to protect these surfaces from damage and debris. o Select a flat surface for assembling the rangehood. Cover that surface with a protective covering and place all rangehood parts and fittings on it. o Do not tile, grout or silicone this appliance to the wall or cabinetry. -
Page 15: Connecting To External Ducting
6) Connect the ducting pipe to the outlet. Connecting to external ducting (top) o Connect the coupling to the top of the rangehood, using two of the smaller screws provided. o (If side ducting, this is either through the wall or the Soffit) o Connect a 150 mm ducting hose to a discharge outlet that is suitable for cooking vapours. -
Page 16: Completing The Installation
Completing the installation If you are setting the appliance to recirculation mode, then you should now fit the two carbon filters. See the section “Fitting the carbon filter” on page 9. The electrical connection must correspond to the electrical requirement noted on the rating plate, which is placed inside the rangehood. -
Page 17: Troubleshooting
Unfortunately if you live in a flat, or if the rangehood is too far from an outside wall, this may not be possible. The only alternative is to recirculate the air. Do I need a charcoal filter? All rangehoods have a grease filter but if you are using your rangehood in recirculation mode, then a charcoal filter must be fitted in addition to the grease filter. - Page 18 My rangehood is noisy and/or vibrating. o Check whether the installation has been completed as per the instruction booklet. o It is normal to get a certain amount of noise and vibration, due to the extraction capacity of the rangehood. IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact an Authorised Service Agent.
- Page 21 Imported by Applico Ltd. Private Bag 92900 Onehunga, Auckland 1061, New Zealand Website www.baumatic.co.nz...
