Connecting the Power & IO Cables and USB Cable Connecting the Antenna Cable The supplied cable, CBLASY0146 provides connection to both the power input Screw the TNC-F to SMA-M coaxial adaptor onto the antenna jack and the 9 way RS232 serial port. The module is powered from a 9 to 32V DC located on the bottom end of the module. supply using a 4-pin square Molex connector from the Power & IO cable and attaching to the DC Power cable. Attach the Red and Black wires to a compliant power supply. The RED wire is the positive. The Yellow wire is not used. It is recommended to fit a 1A or 2A fuse at the power output-end of the wire. This will protect the wiring against fire should a short circuit exist in the vehicle. The front LED has a dual function: Green – Power OK and network visible. Orange – Power OK but network unavailable. Ensure that the cable being used is long enough to reach from the 9602 SBD MODEM to the Antenna location. Plug the antenna cable Serial communication can be either by the USB Mini-B connector or the 9 pin into the adapter. D Connector (RS232) attached to the Power & IO cable. The USB port function has priority over the RS232 serial. If the USB cable is connected to a PC it will Ensure that you fasten the antenna cable securely to the TNC jack by operate and the RS232 serial will be disabled. screwing the cable firmly all the way in with your fingers. Both ports provide similar functionality and the setup parameters are the Please refer to the Antenna Installation Guide for important information same for both. on installation and placement of your antenna. Note: Refer to the Antenna Installation Guide supplied with your 9602 SBD MODEM for information on installing the antenna and assuring Quality of Service.
