LG 43UJ67V Series Service Manual

Hide thumbs

LED TV

SERVICE MANUAL

CHASSIS : UD74P

MODEL : 43UJ67*V

CAUTION

BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

P/NO : MFL69879806 (1707-REV02)

43UJ655V

43UJ701V

CONFIDENTIAL

43UJ67*V-ZD/ZC

43UJ655V-ZC

43UJ701V-ZC

Table of Contents

Need help?

Do you have a question about the 43UJ67V Series and is the answer not in the manual?

Questions and answers

Summary of Contents for LG 43UJ67V Series

Page 1 CHASSIS : UD74P MODEL : 43UJ67*V 43UJ67*V-ZD/ZC 43UJ655V 43UJ655V-ZC 43UJ701V 43UJ701V-ZC CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. P/NO : MFL69879806 (1707-REV02) Copyright © 2017 LG Electronics Inc. All rights reserved. Only training and service purposes.
Page 2 SPECIFICATION ..................6 SOFTWARE UPDATE ................11 BLOCK DIAGRAM .................. 12 EXPLODED VIEW .................. 25 DISASSEMBLY GUIDE ................26 TROUBLE SHOOTING GUIDE ..........APPENDIX - 2 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 3: Safety Precautions
When the exposed metal has no return path to the chassis the reading must be infinite. An other abnormality exists that must be corrected before the receiver is returned to the customer. - 3 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 5 1. Clip each fuse or resistor lead at top of the circuit board hollow stake. 2. Securely crimp the leads of replacement component around notch at stake top. - 5 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 6: Specification
BIRD3 5.0W , BADR 26.0E , DIRECTV-1R 56.0E , EUROBIRD 9A 9.0E , EUROBIRD3 33.0E , EUTELSAT 36 A/B 36.0E , EUTELSAT W2A 10.0E , EUTELSAT W3A 7.0E , EUTELSAT7WA 7.3W - 6 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 7 DVB-S mode : 1/2, 2/3, 3/4, 5/6, 7/8 DVB-S2 mode : 1/2, 2/3, 3/4, 3/5, 4/5, 5/6, 8/9, 9/10 Input Voltage AC 100 ~ 240V 50/60Hz - 7 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 8: Component Input
67.50 30.00 297.00 UDTV 2160P UHD only 4096*2160 53.95 23.97 296.703 UDTV 2160P UHD only 4096*2160 54.00 24.00 297.00 UDTV 2160P UHD only - 8 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 9 112.50 50.00 594.00 UDTV 2160P(DVB) UHD only 4096*2160 134.86 59.94 593.41 UDTV 2160P UHD only 4096*2160 135.00 60.00 594.00 UDTV 2160P UHD only - 9 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 10 2D to 3D, Side by Side, 1280*720 37.50 74.25 HDTV 720P Top & Bottom 2D to 3D, Side by Side, 1920*1080 28.13 74.25 HDTV 1080I Top & Bottom - 10 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 11: Software Update
(7) Click [Yes] : TV will be DC OFF -> ON (8) After TV turned on, Check the updated SW Version and Tool Option. - 11 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 25: Exploded View
It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent Shock, Fire, or other Hazards. Do not modify the original design without permission of manufacturer. - 25 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 26: Disassembly Guide
DISASSEMBLY GUIDE 1. Disassemble stand M4*20 4EA -.M4*20 4EA Disassemble screw -.rotate and disassemble. - 26 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 27 2. Disassemble screw M3*10 13EA M4*10 2EA M3*5.5 1EA -put up the back cover. 3. Disassemble screw M3*5.5 21EA - 27 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 28 4. Disassemble Bottom Cover, and Wifi PCBA -put up the Bottom cover. push -push side and raise up. 5. Disassemble IR -pushing red point and pull out side. - 28 - Copyright © LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 30 E. Noise Circuit noise, mechanical noise F. Exterior error Exterior defect First of all, Check whether there is SVC Bulletin in GSCS System for these model. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 31 ☞A4 & A2 Always check & record S/W Version and White Replace Main Board Re-enter White Balance value Balance value before replacing the Main Board Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 32 ☞A18 Check and Check voltage of No Video/ Normal replace Power Board ( 13V…) No audio voltage? MAIN B/D Replace Power Board and repair parts Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 33 1. Reconnection 2. Install Booster S/W Upgrade Normal Contact with signal distributor Picture? or broadcaster (Cable or Air) Normal Picture? Replace Main B/D Close Close Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 34 /Cable device and error normal cable Request repair for external device/cable Check external External device HDMI device and Replace Main/T-con B/D /Cable error cable normal Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 35 Replace screen? Screen (Check normal operation of Main /T-con External Input, Component, normal? RGB and HDMI/DVI by connecting Jig, pattern Generator ,Set-top Box etc. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 36: Power Error
Measure voltage of each output of Power B/D Normal? Normal Replace Main B/D voltage? Normal Close Check ST-BY 3.5V voltage? ☞A18 Replace Power B/D Replace Power Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 37 Normal Replace Main B/D Check Power B/D voltage? voltage ※ Caution Check and fix exterior Replace Power B/D of Power B/D Part Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 38 Reboot by SW down load function UNKNOWN No meaning (same as initial value) COMP_END OLED threshold voltage degradation(Compensation) completes. PNWASHDONE Power off by panel noise wash function complited. (OLED) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 39 13V of Power Screen normal voltage Speaker off Board Cancel OFF Replace Power Board and repair parts Check Replace MAIN Board Disconnection Speaker disconnection Replace Speaker Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 40 (In case of Connect and check Normal External Input other external audio? signal error) device Check and fix external device Check and fix external device Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 41: Function Error
Replace Main B/D (Power B/D don’t have problem) If R/C operate, Normal Close Explain the customer operating? cause is interference from light in room. Replace R/C Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 42 Replace MR15 Close Down load the Firmware • If you conduct the loop at 3times, change the MR15 * INSTART MENU14.RF Remocon Test3. Firmware download Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 43 INSTART menu Voltage? 1pin Main B/D ☞A24 Close Check & Repair Wifi cable connection ☞A4 Wi-Fi Mac value Close is “NG”? Change the Wifi assy Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 44 4.Camera operating error ☞A4 ☞A25 Check the Camera Ver. Reconnect the Normal Replace is “NULL”? INSTART menu operation? Camera module Main B/D Close Change the Camera module Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 45 Recognition error - S/W Version HDMI/ Check and fix DVI, Optical Replace Main B/D Fix in external device/cable Recognition error accordance with technical information Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 46 “Part related to nose” in the Owner’s (For models without any fix information, Manual. provide the description) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 47 Revised date 17/17 Zoom part with Module Replace module exterior damage damage Cabinet Replace cabinet damage Remote Replace remote control control damage Stand Replace stand dent Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 48 Exchange Module (1) ~ (3) A-8/11 Inverter/ Module A-9/11 ~ Exchange T-Con (1) ~ (2) A-10/11 Exchange Power Board (PSU) A-11/11 Continue to the next page Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 49 Check items after Main B/D replacement E. Etc Adjustment Test pattern - ADJ Key How to use JIG (Power B/D Diganostic Smart Jig Multi Gender) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 50 Check LCD back light with naked eye date <ALL MODELS> After turning on the power and disassembling the case, check with the naked eye, whether you can see light from locations. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 51 2. Enter into White Balance of item 13. 3. After recording the R, G, B (GAIN, Cut) value of Color Temp (Cool/Medium/Warm), re-enter the value after replacing the MAIN BOARD. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 52 TUNER input signal strength checking method Content date <ALL MODELS>  Advanced Channels Channel Tuning Manual Tuning When the signal is strong, use the attenuator (-10dB, - 15dB, -20dB etc.) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 53 Content Version checking method date <ALL MODELS> 1. Checking method for remote control for adjustment Version Press the IN-START with the remote control for adjustment Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 54 2. After measuring each voltage from power supply, finally replace the MAIN BOARD. 3. If you can`t see the UHD live TV, please connect signal at left side of jack. (Korea model only) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 55 Revised Content Connection diagram (1) date <ALL MODELS> As the part connecting to the external input, check the screen condition by signal Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 56 Revised Content Check Link Cable(FFC) reconnection condition date <ALL MODELS> Check the contact condition of the Link Cable, especially dust or mis insertion. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 57 Screen darkness to disconnection of the FFC cable pin. G color transient due to poor FFC cable CABLE G Color Excessive connection A - 1/11 Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 58 LVDS cable connection problem CABLE Color spread LVDS cable connection problem Due to foreign substance withi nLVDS CABLE Screen stop cable PIN A - 2/11 Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 59 Main IC problem Main Dark picture Dark left-side screen Top/bottom screen part Main Broken picture Picture problem due to tuner Inner side quality problem A - 3/11 Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 60 Screen spread Screen corner appears blurry Main Color Spread Color spread on the screen Main Blurry Screen Blurry picture on the screen A - 4/11 Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 61 Screen picture spread problem Screen problem No problem at the initial stage. Right-side Main During Heat run, right-side picture picture problem problem A - 5/11 Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 62 BLU internal foreign matter inflow MODULE Internal matter 6 block image broken MODULE Image broken MODULE Image broken Screen sync signal broken A - 6/11 Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 63 BLU Vertical spreading on cube screen in no MODULE Vertical smear signal MODULE Over color Screen contour part brightly Over color A - 7/11 Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 64 Center of the screen 1 block dark MODULE Screen darkness MODULE Vertical bar Center Vertical Bar Darkness at the MODULE bottom of the MODULE internal BLU breakage screen A - 8/11 Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 66 The entire screen is dark and bit noise T-CON Image Broken occurs The entire screen is dark and bit noise T-CON Image Broken occurs A - 10/11 Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 68 Standard Repair Process Detail Technical Manual Error Established B. Power error _No power symptom date Revised Content Check front Power Indicator date <ALL MODELS> Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 69 136.73 60UJ63 55UJ65 99.4 106.6 113.8 55UJ63 130.4 141.2 49UJ65 85.05 91.8 49UJ63 111.6 118.8 43UJ65 65.94 71.4 43UJ63 65.94 71.4 Check the DC 13V Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 70 POWER OFF MODE checking method date <ALL MODELS> Entry method 1. Press the IN-START button of the remote control for adjustment 2. Check the entry into adjustment item 3 Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 71: Checking Method
1. Press the Setting button on the remote control 2. Select the Sound function of the Menu 3. Select the Sound Out 4. Select TV Speaker Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 72 3.Connect the tester RX1 to the speaker terminal and if you hear the Chik Chik sound when you touch the GND and output terminal, the speaker is normal. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 73 2.Check the standby 3.5V on the terminal 22 pin (③) KEY1 3.AS checking the Pre-Amp(IR LED light) , the power is in ON condition, an Analog Tester needle should move slowly, otherwise, it’s defective. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 74 Checking order to check motion remote/wifi Checking order 3.5V KEY2 1.Check BT/Wifi cable condition between BT/Wifi assy & Main board. 2.Check the 3.5V on the terminal 1 KEY1 Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 75 Standard Repair Process Detail Technical Manual Error Established D. Function error symptom date Revised Content How to use the Service remote control date 1. How to access the remote control Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 76 Digital EYE function ON/OFF For some Model, access to the Test Pattern TILT Used for screen tilting change (Access to the old PDP control mode) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 77 Connects to external input 1,2,3 COMP1,2 (Added Connects to Component 1,2 function) HDMI1,2,3,4 Connects to HDMI 1,2,3,4 (Add function) DVI (Add function) Connects to DVI Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 78 - Record the R, G, B (GAIN, Cut) value of the color temperature before main board replacement. After replacing the main board, key in the recorded value. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 79 You can view 11 types of patterns using the CH+ or - key Checking item : 1. Defective pixel 2. Residual image 3. MODULE error (ADD-BAR,SCAN BAR..) 4.Video error (Classification of MODULE or Main-B/D!) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 80 Smart JIG Power Diagnosis Muitl Gender Guide (P/N : RAD32507801) (P/N : RAD33187801) A 28 (1/19) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 81: Main Board
13Y/14Y 28Pin (OLED) 24Pin 28Pin 16Y/17Y (UH/UJ) 18Pin 28Pin 28Pin 12Pin 12Pin 28Pin Includes 49UJ63 16Y/17Y 16Y/17Y A 28 (2/19) (SJ/UJ) (UH) (UH) (UH/SJ) (LH/LJ) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 82 OLED ‘16 UH95/UH96 UH85/UH93 UH77/UH87 UH75/UH76 UH65/UH68 LH68, LH66, LH60,LH54 ‘17 OLED SJ95/UJ98 SJ85/UJ94 SJ80, UJ77 UJ75/UJ78 ’17 UJ65/UJ68 UJ63/UJ67 LJ61/LJ68 LJ55/LJ58 A 28 (3/19) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 83 “A: 2013 LCD POWER” 2014 ▶ Connect the Muiti Gender to the connector (black) as shown in picture 2 of the Smart JIG. A 28 (4/19) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 84 - 20V Power Board : Change the switch to 24V of Smart Jig Voltage - 13.2V/18V Power Board : Change the switch to 24V of Smart Jig Voltage Power B/D Smart Jig Voltage Switch 13.2V/18V A 28 (5/19) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 85 ▶ Disconnect the Main Board 24Pin Power Cable connector. ▶ Connect the 24Pin Power Cable connector to the Muitl Gender JIG 24Pin connector A 28 (6/19) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 86 ▶ When the OK LED(24V,12V) turns on, Power Board is normal. ▶ When the NG LED turns on, the Power Board can be judged as defective. A 28 (7/19) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 87 ▶ When the OK LED(24V,12V) turns on, Power Board is normal. ▶ When the NG LED turns on, the Power Board can be judged as defective. A 28 (8/19) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 88 ▶ When the OK LED(24V,12V) turns on, Power Board is normal. ▶ Connect the 24Pin Power Cable connector to the Muitl Gender JIG 24Pin connector A 28 (9/19) Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 89 Muitl Gender JIG 24Pin connector ▶ When the NG LED turns on, the Power Board A 28 (10/19) can be judged as defective. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 90 Muitl Gender JIG 24Pin connector ▶ When the NG LED turns on, the Power Board A 28 (11/19) can be judged as defective. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 91 ▶ When the NG LED turns on, the Power Board ▶ Fix the LCD MODEL switch to 20V.(Smart JIG) A 28 (12/19) can be judged as defective. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 92 ▶ When the NG LED turns on, the Power Board ▶ Fix the LCD MODEL switch to 20V.(Smart JIG) A 28 (13/19) can be judged as defective. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 93 Muitl Gender JIG 24Pin connector ▶ When the NG LED turns on, the Power Board A 28 (14/19) can be judged as defective. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 94 Muitl Gender JIG 28Pin connector ▶ When the NG LED turns on, the Power Board A 28 (15/19) can be judged as defective. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 95 Muitl Gender JIG 28Pin connector ▶ When the NG LED turns on, the Power Board A 28 (16/19) can be judged as defective. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 96 Muitl Gender JIG 12Pin connector ▶ When the NG LED turns on, the Power Board A 28 (17/19) can be judged as defective. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 97 Muitl Gender JIG 24Pin connector ▶ When the NG LED turns on, the Power Board A 28 (18/19) can be judged as defective. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
Page 98 Muitl Gender JIG 28Pin connector ▶ When the NG LED turns on, the Power Board A 28 (19/19) can be judged as defective. Copyright © 2017 LG Electronics. Inc. All rights reserved. Only for training and service purposes.
