1 Ton High Lift Air/Hydraulic Professional
2-Stage Transmission Jack
!
Owner's Manual
WARNING:
Read all instructions and safety warnings before
operating this equipment. Failure to follow the
instructions and safety warnings may result in
personal injury or property damage.
1
PROD NO. 030538
MOD NO. 816BA
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Surewerx 816BA
Summary of Contents for Surewerx 816BA
- Page 1 PROD NO. 030538 MOD NO. 816BA 1 Ton High Lift Air/Hydraulic Professional 2-Stage Transmission Jack Owner’s Manual WARNING: Read all instructions and safety warnings before operating this equipment. Failure to follow the instructions and safety warnings may result in personal injury or property damage.
- Page 2 WARNING! The use of shop equipment is subject to certain hazards that cannot be prevented by mechanical means, but only by exercise of intelligence, care, and common sense. It is therefore essential to have personnel involved in the use and operation of equipment who are careful, competent, trained, and qualified in the safe operation of this equipment and its proper use when servicing motor vehicles and their components.
-
Page 3: Maintenance
SETUP operation WARNING! Ensure that you read, understand and apply the safety instructi ons and warnings before use. Failure to heed these instructi ons may result in property damage and/or personal injury. 1. Roll the transmission jack into positi on and pump the foot pedal (35) unti l saddle reaches desired height. NOTE: Follow vehicle manufacturer’s recommended procedures for removing the load as outlined in vehicle service manual or repair guide. - Page 4 PURGING AIR FROM THE HYDRAULIC SYSTEM. Please follow the instructi ons to eliminate the air in the pump core if the product is lift ing slowly or can’t lift up. Loosen Screw R33. Press the Release Pedal R40 when the 2 piston (1st stage and 2nd stage) are in the lowest positi on. Use a 3mm Wrench to loosen M6*8 bleed screw but DO NOT take it off .
-
Page 5: Troubleshooting Guide
TROUBLE SHOOTING GUIDE Trouble Possible Reason Solution 1. Not enough oil 1. Refer to maintenance section and fill to correct fluid level Unit fails to lift 2. Air in the hydraulic system 2. Refer to Purging air 3. Inner leaking 3. - Page 6 PARTS...
-
Page 7: Parts List
PARTS LIST Parts No. Description Parts No. Description Dust ring Washer O-ring Pump Screw U-limited Steel Ball Lock washer Oil cup Screw Caster Release pedal Second piston rod Retainer ring Washer Dust ring Foot pedal O-ring Retainer ring Round nut Connect rod O-ring First piston rod... - Page 8 Parts Description Parts Description Bolt AdjustedHandle Block Bolt Plate Cover Washer Bolt Saddle Base Chain Hook PlateCarrier Hook Base Washer Pin2 Washer Bear Retainer Ring Washer Pin1 Chain Retainer Ring Bolt Cotter Pin...
- Page 9 Parts Description Parts Description Screw Screw Steel Ball Steel Ball Steel Ball Base O-Ring Spring Pin Cover Screw Dust Cover Spring Dust Plunger Washer Big Pump Core Screw O-Ring Spring Washer Spring Spring O-Ring Small Pump Core Push Rod Washer Copper Washer O-Ring Screw...
