INSTRUCTIONS FOR USE
EN
APPLIANCE DIAGRAM (Fig. 1)
A. Handle.
B. Safety closure (if provided).
C. Seal.
D. Separator (if provided).
E. Defrost water drain plug.
F. Control panel.
G. Side motor ventilation grille.
CONTROL PANEL DIAGRAM (Fig. 2)
1. Red light: when blinking, it indicates an alarm condition
(see the section "TROUBLESHOOTING GUIDE").
2. Blue light: when on, it indicates that the STOP FROST
function is activated (see the section "STOP FROST
FUNCTION")
3. Green lights: they indicate that the product is working,
the set temperature and possible activation of the quick
freeze function ("Shopping").
4. Setting button: for updating the set temperature,
activation/deactivation of the quick freeze function
("Shopping") and activation/deactivation of the "STOP
FROST" function.
BEFORE USING THE APPLIANCE
Your new appliance is designed to be used in the
household and similar applications such as:
- kitchen areas in shops, offices and other working
environments
- farm houses
- by clients in hotels, motels, residences, bed &
breakfasts.
The product must only be used to store frozen food, to
freeze fresh food and to make ice.
Regulations require the appliance to be earthed. The
manufacturer declines all liability for injury to persons
or animals and for damage to property resulting
from failure to observe the above procedures and
reminders.
1. After unpacking, make sure that the appliance is
undamaged and that the door closes perfectly, with the
gasket remaining intact. Any damage must be reported
to your retailer within 24 hours after delivery of the
appliance.
2. Wait at least two hours before switching the appliance on
in order to ensure the refrigerant circuit is fully efficient.
3. Installation and electrical connection must be carried out
by a qualified technician, according to the manufacturer's
instructions and local safety regulations.
4. Clean the inside of the appliance before using it.
• Before connecting the appliance to the mains supply,
ensure that the voltage corresponds to that given on the
rating plate located on the rear of the appliance.
• Electrical connections must be made in accordance
with local regulations.
INSTALLATION
• Unpack the product.
• Remove the 4 spacers inserted between the lid and
the product. (Fig. 3)
• Make sure the defrost water drain plug (if provided) is
correctly positioned (E).
• For optimum operation and to avoid damage when the
lid is opened, maintain a distance of at least 7 cm from
the front wall and 7 cm at the sides. (Fig. 4)
• Insert the accessories (if provided).
STARTING THE PRODUCT
• Connect the product to the power supply.
• The green light ("Normal") comes on.
• The red light (1) blinks, since the temperature inside the
product is not yet low enough for loading food. This light
normally goes off within six hours after startup.
• Place food inside only when the red light has gone off.
Note: If the STOP FROST function is deactivated, the lid
cannot be immediately reopened after closing it, because
the seal is tight. It is necessary to wait a few minutes before
reopening the lid.
TEMPERATURE ADJUSTMENT
Use the button (4) to select the required temperature. To
adjust the product temperature, proceed as follows:
• Press the button (4). With each press of the button, the
set temperature will be changed cyclically between the
values "Eco", "Normal", "Intensive" and "Shopping".
• Select "Intensive" for a colder storage temperature.
• In case of a partial load, it is advisable to select "Eco" to
optimise energy consumption.
The green lights (3) indicate the selected setting as follows:
Note: In case of a power failure, the settings (except for
the "STOP FROST" function) remain stored. The time
required for the temperature inside the freezer to reach
approximately the set value may vary depending on the
climatic conditions and the setting selected.
STOP FROST FUNCTION
The STOP FROST function significantly reduces the
amount of frost that can form inside the product, collecting
it in the special easy to remove and clean "ICE BOX" (M)
container. STOP FROST technology also allows easy
reopening of the lid at any time whenever deemed
necessary, even repeatedly, always with the same effort.
The STOP FROST function is already activated when the
product is switched on the first time (blue light on). It can be
deactivated/reactivated by keeping the button (4) pressed
for at least 3 seconds.
Eco: less cold temperature
(left light on).
Normal: middle temperature
(right light on).
Intensive: very cold temperature
(both lights on).
Shopping: Quick Freeze
(both lights on blinking).
See the section "Freezing fresh
food".
