Use this product according to this instruction manual. Please keep this instruction manual for future reference.

GENERAL:

Cooper Notification's Series RSS and RSSP Strobes can provide a non-synchronized strobe appliance when connected directly to a Fire Alarm Control Panel (FACP),
or provide a synchronized strobe appliance when used in conjunction with a Sync Module (SM), Dual Sync Module (DSM) or Cooper Notification's Power Supplies.
The Series RSS and RSSP Strobe Appliances are UL Listed under Standard 1971 (Signaling Devices for the Hearing Impaired) for indoor fire protection service. The
1575W candela wall mounted strobes are listed at 15 candela under UL Standard 1971 and meet 75 candela intensity on axis with low current draw. These Strobes are
listed for wall mount and indoor use only, with the backboxes specified in these instructions (See Mounting Options). RSS models have an integrated Strobe
Mounting Plate (SMP) that can be mounted to a single-gang, double-gang, 4" backbox, 100mm European backbox or SHBB surface backbox. The strobes use a xenon
flashtube with solid state circuitry enclosed in a polycarbonate lens to provide maximum visibility and reliability for effective visible signaling. All inputs are polarized
for compatibility with standard reverse polarity supervision of circuit wiring by the Fire Alarm Control Panel (FACP).
NOTE: All CAUTIONS and WARNINGS are identified by the symbol
WARNING: PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT. FAILURE TO COMPLY WITH ANY OF
THE FOLLOWING INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION, INSTALLATION AND/OR
OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION, WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS
INJURY OR DEATH TO YOU AND/OR OTHERS.

SPECIFICATIONS:

RSS-241575W
RSSP-241575W
RSS-121575W
RSSP-121575W
NOTES:
1. Strobes will produce 1 flash per second over the "Regulated Voltage" range.
2. These strobes meet the required light distribution patterns defined in UL 1971.
All models are listed by UL for indoor use with a temperature range of +32F to +120F (0C to +49C) and maximum humidity of 93%  2% RH. The effect
3.
of shipping and storage temperatures shall not adversely affect the performance of the appliance when it is stored in the original cartons and is not subjected to
misuse or abuse.
Table 3: Current Ratings (AMPS) for 24VDC Models
Maximum RMS Current
Voltage
DC 16.0-33.0VDC
FWR 16.0-33.0VRMS
When calculating the total currents use Table 3A and 3B to determine the highest value of RMS current for an individual strobe, then multiply these values by the total
number of strobes. Be sure to add the currents for any other appliances, including audible signaling appliances powered by the same source, and to include any required
safety factors.
NOTE: The maximum number of strobes on a single notification appliance circuit shall not exceed 50.
CAUTION: These notification appliances are UL Listed as "Regulated". They are intended to be used with FACPs whose notification circuits are UL Listed as
"Regulated." These appliances shall not be used on UL Listed "Special Application" notification circuits unless the appliances are identified to be compatible in the
installation instructions of the FACP or unless the FACP is identified to be compatible in this instruction manual.
WARNING: THESE APPLIANCES WERE TESTED TO THE REGULATED VOLTAGE LIMITS OF 16.0-33.0 VOLTS FOR 24V MODELS USING
FILTERED DC OR UNFILTERED FULL-WAVE-RECTIFIED VOLTAGE. DO NOT APPLY VOLTAGE OUTSIDE OF THIS RANGE.
Copyright 2009 Cooper Wheelock Inc., dba Cooper Notification. All rights reserved.
Thank you for using our products.
INSTALLATION INSTRUCTIONS
SERIES RSS AND RSSP STROBE APPLIANCES
Regulated
Model
Voltage
(VDC/VRMS)
24
24
12
12
All 1575 models are UL Listed at 15cd and meet 75cd on axis.
Table 2: Audible/Speakers for RSSP Strobe/Plate
Product
Multitone Appliances
Motor Bells
Speakers
Chimes
241575W
0.090
0.145
(WALL MOUNT VERSIONS)
. All warnings are printed in bold capital letters.
Table 1: Ratings Per UL
Voltage Range Limit
Per UL 1971
(VDC/VRMS)
16.0-33.0
16.0-33.0
8.0-17.5
8.0-17.5
AMT, MT, MT4
MB-G6/G10
ET-1010/1080, ET70, E70
CH70
Table 3B: Current Ratings (AMPS) for 12VDC Models
DC
FWR
Strobe
Mounting
Candela
Options
(cd)
15 A,B,C,D
15 E,F
15 A,B,C,D
15 E,F
Series
Maximum RMS Current
Voltage
8.0-17.5VDC
8.0-17.5VRMS
121575W
0.255
0.335
P84233 M
