  • Page 1 WASHER-DRYER INSTRUCTION MANUAL...

  • Page 2: Table Of Contents

    Contents 1. PRECAUTIONS FOR SAFETY AND USE ................2 3. DESCRIPTION OF CONTROLS ..................... 12 4. USING THE APPLIANCE FOR WASHING ................13 5. USING THE APPLIANCE FOR DRYING ................19 6. CLEANING AND MAINTENANCE ..................22 7. TROUBLESHOOTING ......................25 This appliance is tagged in accordance with European Directive 2012/19/EU on Waste Electrical and Elec- tronic Equipment - WEEE.

  • Page 3: Precautions For Safety And Use

    READ THE INSTRUCTIONS Attention! You are advised to read all the instructions in this manual carefully; it will inform you about the right conditions for the proper, safe use of your washer-dryer It is very important to keep this instruction manual with the appliance for future reference. In the event of sale or transfer, ensure that the manual always accompanies the appliance, to provide the necessary information about its use.
  • Page 4 washing by the producer on the relevant label. All other uses are to be considered improper. The manufacturer declines all liability for uses other than those stated above.  The nameplate with the technical data, serial number and mark is in a visible posi- tion in the part in view after the door has been opened.
  • Page 5  During washing at high temperatures, the glass in the door will become very hot.  Check that all water has been drained from the appliance before opening the door.  If there is water inside, pump it out before opening the door. If in doubt, read the instruction manual.
  • Page 6 Lengthy periods out of use.  If the appliance is not to be used for a lengthy period it should be disconnected from the electricity and water supplies and the door should be left ajar to prevent un- pleasant smells from building up inside. Important! This appliance is easy to use.
  • Page 7 Important: The fuse cover must be refitted when changing a fuse and if the fuse cover is lost the plug must not be used until a correct replacement is fitted. Correct replacement are identified by the colour insert or the colour embossed in words on the base of the plug.
  • Page 8 2. INSTALLATION INSTRUCTIONS Important! The appliance must be installed by a qualified engineer in compliance with the relevant regulations. The washer-dryer is heavy. Take care when lifting it. 2.1 UNPACKING The unit on flexible mounts is fixed in place for transport using the screws (A) on the rear of the washer-dryer, with the relative plastic spacers (B).
  • Page 9 2.2 POSITIONING AND LEVELLING Place the appliance in the chosen position. Level the appliance carefully in all direc- tions with the aid of a spirit level, adjusting the height of the feet if necessary. Once done, fix the feet in place with the locknuts provided.
  • Page 10 The water intake and drain hoses can be fitted pointing to the left or right for effective installation. Warning! This operation must be carried out with care to prevent the washer-dryer  from vibrating, moving or generating excessive noise during use. ...
  • Page 11 2.3 CONNECTING TO THE WATER SUPPLY Check that the water supply pressure is in the following range: 0,05-0,9MPa. With higher pressures, use a pressure reducer. Connect the cold water supply hose (blue screw collar) to the cold water tap with ¾ gas threaded connector, taking care to tighten firmly to prevent leaks.
  • Page 12 2.5 ELECTRICAL CONNECTION Before connecting the plug to the power socket ensure that: 1. The electrical system voltage is the same as that stated on the nameplate on the front of the appliance, in the zone visible when the door is open. The rated power supply and the fuses required are specified on the nameplate.

  • Page 13: Description Of Controls

    3. DESCRIPTION OF CONTROLS 3.1 CONTROL PANEL All the appliance's control and monitoring devices are placed together on the front panel. Display: shows the settings (spin speed, cycle status, flexi time, maximum recommended weight, drying levels, child lock, clean programme). The settings can be modified using the buttons under- neath.

  • Page 14: Using The Appliance For Washing

    4. USING THE APPLIANCE FOR WASHING 4.1 PREPARING THE ITEMS FOR WASHING Subdivide the items for washing by fabric type and colour fastness. Wash white and coloured items separately. New coloured items should be washed separately the first time. Normally, items carry labels with washing instructions. The following is a short description of the symbols used on these labels.
  • Page 15 4.4 LOADING THE ITEMS FOR WASHING Open the door and load the laundry, distributing it evenly over the drum, with items opened out and not bundled together; if possible, large and small items should be well mixed. The washing machine covered by this manual can be loaded with up to 7kg of laundry for each wash. If this weight is exceeded, the washing results will be poor and the appliance may malfunction.
  • Page 16 4.6 POWDER DETERGENT DOSES Laundry with normal dirt Choose a programme without prewash. Pour the total amount of detergent shown on the pack into the main wash compartment of the detergent drawer. Very dirty laundry Choose a programme with prewash. Place ¼...
  • Page 17 4.11 SELECTING AND CONFIRMING OPTIONS Options Option selection Confirm option Start Pause The Option Selection button can be used to select the following options in sequence (from the top down): Prewash: adds a stage before the main wash, lasting about 20 minutes at a temperature of 35°C. Suitable for loads of particularly dirty items.
  • Page 18 4.12 TIME REMAINING Delay Timer symbol Start pause symbol Start Pause Delay Timer button The Delay Timer can be pressed repeatedly to select the time after which the washing programme will end. The time left before the end of the cycle calculates the initial duration of the washing/drying cycle, the settings made (temperature, spin speed and options) which may shorten or lengthen the cycle's initial duration, and the delay time the user wishes to add before the cycle starts.
  • Page 19 4.14 INTERRUPTING OR CHANGING THE WASHING PROGRAMME The washing programme in progress can be interrupted at any moment: press the “Start/Pause” button for about 3 seconds: the display shows the word PAUS (for 1 second) alternating with the time remaining until the end of the cycle (for 1 second). The Start/Pause light flashes on and off.

  • Page 20: Using The Appliance For Drying

    4.17 OPENING THE APPLIANCE IN AN EMERGENCY In the event of a power failure, the door is opened using the mechanical release device activated by means of the lever in the bottom of the appliance:  Turn the knob to Off and disconnect the power supply plug from the socket.
  • Page 21 5.2 WASH-AND-DRY PROGRAMME Automatic washing and drying can be carried out in the tough fabrics (cotton and colours) and synthetic/delicate fabrics programmes. If the wool wash programmes are selected, automatic drying after the wash cannot be set. For automatic washing and drying, the load of laundry must not exceed 4 kg of cotton or 2 kg of synthetic fabrics.
  • Page 22 5.5 CLEAN PROGRAMME To keep the appliance operating at peak efficiency over time, it has a CLEAN programme for regular cleaning of the drying circuit to remove any fluff deposits. After a given number of drying cycles, the CLEAN symbol lights up and the text Cln appears on the display to warn that this programme needs to be run.

  • Page 23: Cleaning And Maintenance

    6. CLEANING AND MAINTENANCE Important – Before carrying out any cleaning or maintenance procedure, the plug must be disconnected from the power supply socket. 6.1 CLEANING THE OUTSIDE OF THE APPLIANCE  Regular, thorough cleaning will keep your appliance looking good. ...
  • Page 24 6.3 CLEANING THE DOOR GASKET Check regularly that there are no brooches, buttons, nails or pins in the folds of the door gasket. 6.4 CLEANING THE DRAIN PUMP The drain pump only needs cleaning if it has been blocked by buttons, brooches or similar objects and the water is not being pumped out.
  • Page 25 6.5 CLEANING THE DETERGENT DRAWER The detergent drawer should be kept clean, removing all solid deposits. To simplify this operation, completely remove the detergent drawer (pull the drawer fully out, press in the zone marked PUSH and then remove completely). Remove the siphon "A"...

  • Page 26: Troubleshooting

    7. TROUBLESHOOTING This produce complies with the relevant regulations governing the safety of electrical equipment. For safety reasons, any technical inspections or repairs must be performed by qualified staff, to prevent all hazards for the user. If the appliance does not work, before calling the After-Sales Service, to avoid unnecessary expense, check yourself that the operations listed in this troubleshooting table have been carried out.
  • Page 27 Appliance does not spin Anti-imbalance safety device tripped because laundry not evenly distrib- uted in drum. If laundry is still wet at end of cycle, rearrange it in the drum by hand and repeat spin programme only. Emptying water from drum In the event of a power blackout or appliance failure, the water can be re- moved from the drum using the emergency procedure.
  • Page 28 PROGRAM GUIDE Detergent drawer compartments Options Programs Temp. Max. Spin Max. Max. drying Prewash Wash Conditioner Prewash Intensive Easy Extra rinse Rapid Drying after Wash program description (°C) (rpm) washing load (kg) Iron wash if load (kg) selected Cotton and Delicate coloureds with ...
  • Page 31 • •...
  • Page 33 820mm 560mm 596mm 820mm 58mm ca. 82kg 150mm 16mm...
  • Page 34 3 - A 11 11 3 - B...
  • Page 35 Unterkante Unterkante Lower edge Lower edge Côté inférieur Côté inférieur Lato inferiore Lato inferiore Lado inferior Lado inferior Onderkant Onderkant 16...21mm 16...21mm ижний к ай ижний к ай 592...595mm 592...595mm Ø 35mm Ø 35mm Ø 2mm Ø 2mm...
