- Page 1 ASSEMBLY FABRIC 180CM 2 DRAWER BED INSTRUCTIONS Approximate Assembly Time People Required to Assemble Tools Required...
- Page 3 Please check all hardware matches the list below. Should you notice any are missing please contact your retailer. Already inserted into Head & Foot Ends M8x30mm +Spring Washer M5x70mm +Flat Washer M8x45mm +Flat Washer M4x20mm M5x50mm 40x75 M5x50mm M4x20mm M4x30mm We strongly advise that you do not use Power Tools, such as drills or electric screwdrivers during the assembly as this may cause irreparable damage and will invalidate your...
- Page 4 (2x) 07 (48x) Please ensure you carefully check all the pieces, should you have any concerns please contact the retailer before assembly commences. Please have your order number, details of the issue, the product code, and the batch number from the cartons as this will help us to resolve your issue much faster.
- Page 6 01 02 Please note that the Bolt (A) x 16 are prefixed into parts 1 & 2...
- Page 7 01 02 ARROWS ON LABELS POINT TO EACH OTHER...
- Page 8 PUSH PUSH PUSH Drawer Assembly Important: Make sure when you fit the nuts that the hole is in the correct alignment. Part M x 3...
- Page 9 Positions For Castors FOLLOW LINE ON BACK OF DRAWER FACE PANEL...
-
Page 10: General Care And Maintenance
GENERAL CARE & MAINTENANCE We advise that when cleaning the product that a damp cloth is used. Avoid the use of all household cleaners and abrasive. Never push or drag the furniture. Never attempt to move the furniture when fully loaded. We advise that periodically all fixing are re-tightened.
