- Page 1 Operators & Installation Guide...
- Page 2 WARNING ! WARNING ! PLEASE READ OPERATORS MANUAL BEFORE USE. PLEASE Only operate the Quest Q1 when you have the pool pump Only have the system installed by a qualified electrician KEEP FOR FUTURE REFERENCE AS THIS DOCUMENTATION switched on and you have water flowing through the...
-
Page 3: Table Of Contents
Table of Content Operating Instructions ................ 2 System Operation 1.1.1 Controls 1.1.2 Pool Balance 1.1.3 Adjusting Copper / Silver Levels Basic Theory ..................8 Ionisation Electronic Oxidisation (ORP generator) EM Descaler Initial System Start-Up ................ 9 Maintenance..................10 Basic Maintenance 4.1.1 Fuse 4.1.2 Adjustment of Copper/Silver Electrodes 4.1.3... -
Page 4: System Operation
Quest Q1 water sanitiser. this system. During periods of intense use or when there has been... - Page 5 Quest Q1 Components Off / Manual / Auto switch ECU Main Control System Q1 Control Unit ON/OFF Switch EM Descaler Indicator LED Digital Display Ioniser Current Control Fuse Oxidiser Current Control Timer Clock Ioniser Polarity Indicator Air Duct Keep clear of Pump Outlet obstructions To EM...
- Page 6 Ioniser and Oxidiser Chambers Oxidiser and Ioniser The Oxidiser and Ioniser chambers can be installed in two different formats. Horizontal and in a H shape , both chambers are connected by the descaler coupling. This design is designed for the pool engineer to choose the most suitable set up for your filtration system.
-
Page 7: Controls
The Q1 is designed to allow the user to benefit from reduced running of the swimming pool pump by coordinating the operation of the pump with the timer on the Q1. If it is desired that the pool pump should be operating 24/7 then its power supply should... - Page 8 01 to 16 A value in the range of 1-16 indicates the current (in Amps) being applied to the Oxidiser plates. The Q1 control unit limits to a maximum of 15 Amps. When the Oxidiser Current Control is at maximum the display should show 14-16. If the display at maximum is below 14-16 amps this is either due to low TDS levels or a high internal temperature.
-
Page 9: Pool Balance
1.1.2 Pool Balance Balance Symptoms Ideal Range Measurement Adjustment Parameter pH difficult to 80-150 ppm Use supplied test kit Raise by using Sodium Bicarbonate. maintain Approx 450 grams per 10,000 litres (e.g. 2.25kg for 50,000 litres) to raise from pH bounce 60ppm to 100ppm. -
Page 10: Basic Theory
ORP. 2.0 Basic Theory 2.3 EM Descaler There is no such thing as a maintenance-free pool. However, the Q1 EM Descaler used in the Q-1 system further system requires only a few minutes each week to keep your pool in helps to improve the water quality by top condition whilst saving money. -
Page 11: Initial System Start-Up
3. Initial System Start-Up WARNING ! Turn both control knobs (Ioniser and Oxidiser) on the Q-1 control box fully counter-clockwise to the “MIN” settings. This system must be installed and serviced by a qualified pool Turn on the power switch on the control unit. or water sanitiser technician. -
Page 12: Maintenance
0.2 – 0.4 ppm recommended level. operation. 4.0 Maintenance WARNING ! Only operate the Quest Q1 when you have the pool pump switched on and you have water flowing through the ioniser ,oxidiser and 4.1 Basic Maintenance de-scaler chamber. - Page 13 4.1.3 Replacement of electrodes and oxidiser plates The copper and silver electrodes and oxidiser cell are consumables and will require periodic replacement. The life time of both components will depend on many factors including pool use, maintenance, dirt and other debris in the pool. Typically, both the electrodes and oxidiser will last for around two to three years before replacement.
-
Page 14: Specifications, Warranty And Contacts
For the best results in obtaining a crystal clear and healthy pool please read the following: Your Quest Q1 comes with a 24 month manufacturers warranty DO NOT USE A STABILIZER from the date of installation . Your warranty is invalid if you DO NOT USE A BROMINE COMPOUND don’t follow the following procedures and policies detailed in the... -
Page 15: Pre Installation
1 x Q1 Control Unit WARNING ! 2 x Electrolysis cells containing Only operate the Quest Q1 when you have the pool pump switched 1 x coated Titanium plate assembly on and you have water flowing through the ioniser ,oxidiser and 1 x 2 Cu/Ag electrodes de-scaler chamber. -
Page 16: Converting Existing Pools
5.2 Converting Existing Pools When fitting the Q1 system to existing pools consideration should be given to the treatment that has been previously been applied to the pool. Previous Treatment(s) Comments Recommendations OK to install Q1 with the existing water. The chlorine will dissipate Chlorine or Bromine naturally in a few days and does not react with the Q1 processes. -
Page 17: Filters
5.3 Filters The processes used by Q1 mean that excellent filtration can be achieved using standard cartridge or sand filters with coarse sand. Sand filters are the most convenient. Filter considerations are as follows Type Media Recommendation Cartridge Standard Filter OK with Q1 OK with Q1. -
Page 18: Installation
Installation Guide... -
Page 19: Installation
Keep clear of Automatic obstructions Pump Filter Heater Oxidiser Descaler Ioniser Pool dosers WARNING ! Only operate the Quest Q1 when you have the pool pump switched on and you have water flowing through the ioniser ,oxidiser and de-scaler chamber. -
Page 20: Control Box
6.1 Control Box The control box is IP23 rated and approved to EU and other International standards. It is designed for outside or inside installation. Ensure adequate ventilation is provided and that it is in a position where it is unlikely to be flooded, sprayed with water or come into contact with chemicals. -
Page 21: Ioniser /Oxidiser/De-Scaler
6.2 Ioniser/Oxidiser/De-scaler Unit (Wet-end Cell) The cell is ideally installed on the outlet from the Filter (or heater where installed) and before any Automatic Chemical Feeders (see above). Install so that the inflow is over the Oxidiser plates and the outflow is from the Ioniser Electrode end. Ensure that the cell is fitted to allow access to the plates and rods for maintenance. -
Page 22: Troubleshooting
6.3 Troubleshooting Problem Possible Cause What to do to fix it Turn off power to control box, replace fuse and allow clean Blown fuse Undiluted chemicals added to pool or skimmer basket water to circulate through the system before switching on. Low conductivity Refer to operating instructions Excessive make-up water added due to leak in pool or Repair leak equipment... - Page 23 Contact Information Manufacturing Plants: Ecotec Systems Ltd, Bruntingthorpe Industrial Estate, Lutterworth, Leicestershire, LE175QZ, England Email:sales@questsemi.com Tel:+44(0)1162479794 Global Sales Office: Queensland Semiconductor Technologies Pty Ltd QUEST Unit 5 , 1 Maid Street, Southport, Queensland, 4215 Australia Email:sales@questsemi.com Tel:+61 7 55324800...
- Page 24 YOUR AUTHORISED QUEST RESELLER IS www.questpools.com.au...
