- Page 1 IQ SERIES GROW ROOM HVAC Dry Coolers OPERATION AND MAINTENANCE MANUAL Q u e s t C l i m a t e . c o m...
-
Page 2: Table Of Contents
Table of Content General Information ......................2 Document Scope ............................2 Contact Us ..............................2 Operating Safety (Warnings, Cautions, and Notes) ................... 2 Basic Information ............................4 Equipment Specific Data ..........................6 Operation and Control ..........................7 Layout and Components ......................9 Dry cooler Main Components ........................ -
Page 3: General Information
General Information Document Scope This manual provides operation and maintenance information about the Quest IQ Dry Cooler and its operation. Additional information regarding installation, maintenance, and equipment commissioning and auxiliary devices is provided with the system and can also be obtained from the manufacturer. Contact Us Quest QuestClimate.com... - Page 4 The following warnings, cautions, and notes appear throughout this manual and referenced documentation whenever special care must be taken to avoid potential hazards that could result in equipment malfunction or damage, personal injury, or death. Note CAUTION WARNING Indicates a situation that could Indicates a potentially hazardous Indicates a potentially hazardous result in equipment damage or...
-
Page 5: Basic Information
Basic Information View and Options The views of standard NG series dry coolers’ product line are shown on Pic.C.1. and C.2 below. Dry cooler Options • Capacity. NG series dry coolers range broadly in their capacities, which depends on factors including physical size, fluid flow rate, glycol concentration and ambient conditions. - Page 6 • Pump package (optional). As needed, dry cooler could be equipped with pump package – to establish cooling media flow (or to serve as additional/booster pump). For multi-fans coolers: If pump • package is required, each “two-fan” • section, normally, would get its own package (Pic.
-
Page 7: Equipment Specific Data
Attention! Equipment Clearances! CAUTION! Proper clearances should be maintained for adequate airflow and heat rejection, as well as for maintenance and service of the equipment! Generally, up to 36” sides (all around) and 96” top clearances are required. For more information on clearances as well as equipment dimensions and other details, refer to the submittal documentation. -
Page 8: Operation And Control
Labels and Stickers: attached normally to indicate dry cooler external systems connections (piping, electrical etc.), terminals designation, to display warning etc. Wiring Diagrams: typically, attached to the interior side of the dry cooler main electrical panel, depicting control and power wiring. Operation and Control Dry cooler rejects the heat, absorbed by the cooling media (water etc.) from the external system(s) that dry cooler serves, to the outdoor air. - Page 9 Control There may be some different types of controls used with NG series dry coolers. Fan type: • Modulating (EC-type) fans are capable of varying their speed (from 0 to 100%) based on 0-10VDC signal. Control Type (all control types referenced below are applicable to all fans type described above): •...
-
Page 10: Layout And Components
Layout and Components General layout of the various NG-series dry coolers is shown on Pic.D.1 below. While layout and main components are similar for all applicable dry coolers, there are some deviations (number of fans and coils, composition, etc.). Refer to Views and Options (Basic Information chapter) for additional information: Dry cooler Main Components Pic. -
Page 11: Electrical Box - Power And Control
Fig. 1, 2 and 4 show NG-V type dry coolers (two, six and single-fan models, respectively), while Fig. 3 shows NG-Z type dry cooler. Examples show all/most available options (like pump package etc.); some of shown options may not be present on your dry cooler –... -
Page 12: Pump Package
Pump Package If equipped with such option, dry cooler would have a pump package box. Pic.D.3 below shows general layout of pump packages, used for NG-V model dry coolers. Note, that the package could be mounted onto the dry cooler directly (standard) or provided separately. -
Page 13: Basic Maintenance
Basic Maintenance Although dry cooler is built for minimal service downtime, periodic preventative maintenance is required to ensure maximum reliability, safety, and operating efficiency. WARNING! To ensure equipment longevity and proper and efficient operation, it must be maintained properly. It is recommended to create a facility-specific Routine Maintenance Program. Failure to perform necessary maintenance task(s) properly and regularly could result in personal injury, equipment damage or malfunction and will void the equipment warranty. -
Page 14: Specific Components Maintenance And Special Tasks
Monthly – Quartely Observe equipment general operation (for unusual vibration, noise etc.) Verify control settings (applicable to “self-controlled” equipment) Inspect the airside coils for dirt, cobweb build-up, etc.; clean as needed Semi-Annually – Check electrical connections (both, power and control), tighten as needed Annually Check the frame and fasteners for being structurally sound (loose fasteners, corroded/deteriorating components etc.) -
Page 15: Warranty
Warranty General Policy All Quest service and warranty work is managed exclusively by Dehumidified Air Services (DASV). All warranties apply to the original equipment owner and are not transferable. All warranty inquiries should be made through either Quest Customer Account Management or Dehumidified Air Services. Quest Customer Account Management: Phone: 1-833-327-2447 Email: Service@QuestClimate.com... - Page 16 applicability. Parts shipping and handling costs (to and from the factory) are not covered outside of the Initial 90‐ day Warranty. Replacement Part Warranty If a replacement part provided by Quest under this warranty fails due to a material defect prior to the end of the Two-Year Parts Warranty (or the end of the extended warranty period if applicable), whichever comes first, Quest will provide a new or rebuilt part F.O.B.
- Page 17 the warranties described above. Quest expressly disclaims and excludes any liability for consequential or incidental damage for breach of any express or implied warranty. Where a jurisdiction does not allow limitations or exclusions in a warranty, the foregoing limitations and exclusions shall not apply to the extent of the legislation, however, in such case the balance of the above warranty shall remain in full force and effect.
