- Page 1 Fabric Building Double Truss Peak Style Model# FB204016DP 20’x40’x16’ (8’ arch space) Assembly Instructions...
-
Page 2: Equipment List
Equipment List Speed Wrench 22#.23#.24# Hammer (30lb) Rope (12#) Long Tape (50m) Hammer Drill*1 Lifter*2 Crane*1 Forklift*1 Protective equipment... - Page 3 YOU MUST READ THIS DOCUMENT BEFORE YOU BEGIN TO ASSEMBLE THE SHELTER. Thank you for purchasing our shelter. When properly assembled and maintained, this product will provide years of reliable service. These instructions include helpful hints and important information needed to safely assemble and properly maintain the shelter.
- Page 4 Fabric Building 20'x40'x16' Parts List Part Qty/ Description Code top truss for 2nd to 5th arch top truss for 1st arch (front wall) top truss for 6th arch (back wall) roof truss for 2th to 5th arch roof truss for 1st arch (front wall) roof truss for 6th arch (back wall) shoulder truss for 1st to 6th arch upright truss for 2nd to 5th arch...
- Page 5 tensioning tube for roof cover (4+1 2 sets pieces/set) tube clip for steel wire No.21 bolt M8x50 for truss swaged end connection bolt M10x70 for purlin connection end plug (Φ32) for tensioning tube No.9 belt for ratchet on base plate knitting rope for roof cover (2 1 pack bundles)
- Page 6 connetion plate for square tube post 2 sets No.22, 23, 24, 25 (2pcs/set) post on the lower side of the back door post on the upper side of the back door base plate for back door cross beam for front door vertical tube for door beam No.30 side rail for front wall (two sides) upper rail for back wall...
- Page 7 bolt M6x45 for door bracing tube No.38, 39 bolt M12x130 for square tube post No.22, 23, 24, 25 bolt M10x70 for square tube post No.22, 23, 24, 25 knitting rope for front and back cover 2 packs (6 bundles) cable tie for fixing front and back cover expansion bolt steel wire for front door...
-
Page 8: Installation Process
INSTALLATION PROCESS A—BASE PLATES INSTALLATION Please refer to the below diagram to mark the position of base plates The measurement is from center to center of base plates. Referring to the diagram and confirm the place of base plates. ENSURE THAT THE FOUNDATION IS SQUARE. Note: The expansion bolt (No.18, 49) applies for fixing base plate on concrete ground. - Page 9 B—FRAME INSTALLATION First Arch and Front Wall 1. Find Trusses (No.1A, 2A, 3, 4A) for first arch and connect them by bolt M8x50 (No.11). 2. Find relative parts of posts and rails for front wall and assemble them according to the below diagram.
- Page 10 Second Arch to Fifth Arch Installation 3. Find Trusses (No.1, 2, 3 and 4) for second to fifth arch and connect them by bolt M8x50 (No.11).
- Page 11 Sixth Arch and Back Wall Installation 4. Find Trusses (No.1B, 2B, 3 and 4A) for sixth arch and connect them by bolt M8x50 (No.11). 5. Find relative parts of posts and rails for back wall and assemble them according to the below diagram.
- Page 12 Purlin and Steel Wire Installation 6. Lift the assembled arches onto base plates (No.7 and 8) and connect them by bolt M8x50 (No.11). 7. When finish installing the first and second arches, install purlin (No.5) and connect them by bolt M10x70 (No.12).
- Page 13 C-INSTALLING COVER Front Cover and Winch Door Installation 1. Install the winch door refer to the diagram bellow. Install front cover (No.53) to the first arch and posts and rails on front wall by rope (No.47) and cable tie (No.48). WINCH DOOR INSTALLATION...
- Page 14 1. Install the front door frame and door winch bracket 2. Fix the winch to the bracket. Make sure the winch handle faces the outside. Refer to Figure 1.
- Page 15 3. Take out the door curtain cloth and lay it on the ground. Pay attention to the direction. The side with pipe pockets faces inward. 4. Connect the door bracing tube (2pcs/set) with M6x40 bolt. 5. Thread the door bracing tube into the pocket from top to bottom. Pay attention to the bottom bracing tube.
- Page 16 6. Put the steel wire rope through the pulley on the door frame as shown in Figure 3, so that the steel wire rope is located on the inner side of the door frame and on the same plane as the pulley, and then the steel wire rope sags naturally.
- Page 17 9. Adjust the length of the steel wire rope to be equal on both sides.Fix the wire rope fold to the hole in the winch. Refer to Figure 4.
- Page 18 10. Turn the winch clockwise to lift the door curtain cloth and bracing tubes to a position about 40-50cm away from the cross beam. Lace the eyelets on the cloth to cross beam with a rope. Refer to Figure 5.
- Page 19 11. Now the winch door installation is completed.Turn the winch clockwise to raise and counterclockwise to lower the door. The steel wire rope shall be evenly wound on the winch so that the door can rise and fall smoothly.
-
Page 20: Front Cover Installation
Front Cover Installation... -
Page 21: Back Cover Installation
Back Cover Installation 3. Install back cover (No.53) to the sixth arch and posts and rails on back wall by rope (No.47) and cable tie (No.48). - Page 22 Roof Cover Installation NOTE: DO NOT install the cover onto the frame of your building in high wind conditions. A slight breeze is the most advantageous for cover installation. To take advantage of the breeze, pull the cover up over the arches with the breeze blowing in the cover like a sail filled with air.
- Page 23 Now your assembly is completed.
