5. If the setting passwords are same with each other, the LCD displays
" ", and then return to the parameter menu selecting interface,
which means the password setting is successfully.

2.6. Temperature Calibration

The temperature of the unit should be recalibrated every time if the
handle, heating element or soldering tip is replaced. The unit uses
digital calibration.
Method of recalibrating temperature:
Use the thermometer to calibrate it and it is precise
comparatively.
1.
Set the temperature at a certain value.
2.
When the temperature is stable, measure the tip's temperature with
thermometer and write down the value.
3. Press the "▲" & "▼" buttons simultaneously, press the "*" button
until the LCD displays "CAL" to enter the calibrating temperature
mode.
4. When the 100's digit starts to flash, select the value by pressing "▲"
or "▼" button according to the reading of the thermometer and then
click "*" button to confirm it. Input the 10's digit and 1's digit as the
method, after that, click "*" button. Here, the calibration operation
has been finished. If temperature is successful, the LCD will display "
" and then return to the work state.
5. Repeat the above steps if there's any difference between the
thermometer and soldering station.
NOTE:
(1)Recommend using the tip thermometer to measure the
tip's temperature.
(2)If locked by password, it will not be able to calibrate the
temperature and it must input the right password.
13
