- Page 1 C24-CAMANL Video Server/Encoder User’s Guide firealarmresources.com firealarmresources.com...
-
Page 2: Table Of Contents
Table of Contents CHAPTER 1 INTRODUCTION....................1 Overview ..........................1 Physical Details - Video Server..................2 Package Contents ......................3 CHAPTER 2 BASIC SETUP ....................4 System Requirements......................4 APPENDIX A SPECIFICATIONS..................6 Video Server........................6 Regulatory Approvals ....................... 6 P/N: 957YDC01MY Copyright ©... -
Page 3: Chapter 1 Introduction
Chapter 1 Introduction This Chapter provides details of the Video Server's features, components and capabilities. Overview The Video Server digitizes analog video signals and transmits digital images directly to your gateway. Features • Dual Stream Live Video to Multiple Users. The MPEG4 and JPEG encoders built into the video server generate a ready-to-view video stream. -
Page 4: Physical Details - Video Server
Physical Details - Video Server Front - Video Server This button is recessed; you need a pin or paper clip to press it. It can Reset Button be activated at any time the video server is in the "ready" mode. Reset to manufacturer default value and reboot. -
Page 5: Package Contents
Package Contents 1. Video Server 2. Power Adapter 3. Video Output Terminator 4. Quick Installation Guide firealarmresources.com firealarmresources.com... -
Page 6: Chapter 2 Basic Setup
Using a different one may cause hardware damage. Step 1. Log into User Portal (with authorized credentials) Step 2. Go to System Tab Step 3. Click on the “Manage Devices” button Step 4. Click on “Cameras” Step 5. Select C24-CAMANL Wired IP Analog Camera Adapter firealarmresources.com firealarmresources.com... - Page 7 Connect the analog camera to the Video In connector of the C24-CAMANL. Next, connect the C24-CAMANL to the Device LAN port of your gateway with an Ethernet cable. Finally, plug the power supplies for the camera and C24-CAMANL into an electrical outlet.
-
Page 8: Appendix A Specifications
Appendix A Specifications Video Server Model Video Server Dimensions 90mm (W) * 30mm (H) * 140mm (D) Operating Temperature 0° C to 40° C Storage Temperature -10° C to 60° C Network Protocols: TCP/IP, DHCP, SMTP, NTP, HTTP, HTTPS, UPnP, FTP, RTP, RTSP Network Interface: 1 Ethernet 10/100BaseT (RJ45) LAN connection... - Page 9 FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause...
