Cecilware ELG-1F Operation Manual

SPARE PARTS LIST FOR SANDWICH GRILLS
9
5
4
6
2
6
7
1
ITEM # PART #
1 01500 Thermostat – All TSG – ELG
2 01501 Thermostat Knob – All TSG – ELG
3 01502 Right Lifting Spring – TSG-2 (Only)
3 0515 Right Lifting Spring – TSG-1 (Only)
4 01503 Left Lifting Spring – TSG-2 (Only)
4 01514 Left Lifting Spring – TSG-1 (Only)
5 01504 Upper Element – 120V – TSG-1 (Only)
5 01506 Upper Element – 230V – TSG-2 (Only)
6 01505 Lower Element – 120V – TSG-1 – ELG-1
6 01512 Lower Element – 230V – TSG-2 – ELG-2
7 01507 Pilot Light – All 230V – TSG-2 – ELG-2
7 01516 Pilot Lights – 120V – TSG – ELG
8 01508 Feet – All TSG's
9 01509 Top Plate Handle – TSG-1 (Only) (Long)
9 01511 Top Plate Handle – TSG-2 (Only) (Short)
Not Shown 01510 Terminal Block – All TSG's
Not Shown 01513 Grill Brush
3
8
DESCRIPTION
OPERATION MANUAL
TSG-1G
(All Grooved Surfaces)*
TSG-1F
(All Flat Surfaces)*
ELG-1G
(All Grooved Surface) †
ELG-1F
(All Flat Surface) †
* Available with timer – Add Suffix "T" (not shown)
† Not shown
TSG-2G
(All Grooved Surfaces)*
TSG-2F
(All Flat Surfaces)*
ELG-2G
(All Grooved Surface) †
ELG-2F
(All Flat Surface) †
ELG-2F/G
(Flat/Grooved Surface) †
* Available with timer – Add Suffix "T" (not shown)
† Not shown
CECILWARE CORPORATION
43-05 20th Avenue • Long Island City, NY 11105
THE
SANDWICH
"PANINI"
GRILL
TSG-1G
TSG-2G
Tel: 800-935-2211 • Fax: 718-932-7860
1/7/02
