- Page 1 SAVE THESE INSTRUCTIONS SONOMA PLASTIC UMBRELLA BASE STYLE #: 71SRRUM05 ASSEMBLE ON A FLAT, PROTECTED SURFACE. FIGURE DESCRIPTION PART LIST QUANTITY 1 PC BASE 1 PC KNOB CONNECTOR 1 PC COLLAR 1 PC HOLE COVER Page 1/4...
- Page 2 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SRRUM05 STEP 1 A. PLACE BASE (A) ON A FLAT, PROTECTED SURFACE. B. UNSCREW THE HOLE COVER (D). C. FILL WATER OR SAND INTO THE BASE HOLE. STEP 2 A. REPLACE HOLE COVER (D). TIGHTEN COMPLETELY.
- Page 3 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SRRUM05 STEP 4 A. TURN THE COLLAR (C) TO THE RIGHT TO SECURE. B. UMBRELLA BASE ASSEMBLY IS COMPLETE. STEP 5 A. INSERT UMBRELLA POLE INTO COLLAR (C) THROUGH THE KNOB CONNECTOR (B). TIGHTEN KNOB CONNECTOR (B) TO SECURE UMBRELLA.
- Page 4 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 71SRRUM05 STEP 7 A. UNSCREW HOLE COVER (D) AND DRAIN THE WATER OR SAND FROM THE BASE. CARE AND CLEANING IN ORDER TO PROLONG THE LIFE OF YOUR UMBRELLA BASE, PLEASE STORE IN DRY SHELTERED PLACE WHEN NOT IN USE OR DURING INCLEMENT WEATHER.
