Summary of Contents for Harol TR850
- Page 1 Assembly instructions Terrace awning TR850 art.nr. 6837...
-
Page 2: General Warnings
15 A. Introduction The Harol TR850 terrace awning is an outside sun protection to be fitted on your terrace. This sun protection blocks the sun rays and thereby protects your terrace against overheating. These assembly instructions explain step by step the fitting of this system. - Page 3 Assembly instructions terrace awning TR850 D. Fitting instructions Terrace awning The terrace awning is a sunblind which must be fitted perfectly square and vertical. The guide rails must be set up absolutely parallel to one another. It is very important to work with extreme accuracy and to make sure that the base supports are solidly secured.
- Page 4 Assembly instructions terrace awning TR850 the plugs supplied in the wall. Remove the lid of the casing, take hold of the casing by the ends with the sections of guide rail directed downwards, and with the hinge points upwards (fig. 4).
- Page 5 Assembly instructions terrace awning TR850 B. Assembling the support rails Now take the guide rails for the sloping part of the sunblind (fig. 7). Lay these rails in front of the sun- blind, so that the end stop (A) fits...
- Page 6 Assembly instructions terrace awning TR850 runner. The conical side of the wheel should be on the outside (fig. 10). Then insert the guide rails in the cover, along with the runners. To do this, the casing must be tilted slightly on its fixing hinge.
- Page 7 Assembly instructions terrace awning TR850 Then take firm hold of the horizontal rails by the end with the corner piece and bring this section immediately above the vertical bases. Now press the corner piece into the vertical guide rail (Fig. 14). The guide rails will now stand up by themselves.
- Page 8 Assembly instructions terrace awning TR850 The tensioning system: If the width of the terrace awning is between 350 and 500 cm, a simple pulley system can be used. The two springs have a length of 1360 mm and are located directly alongside each other inside fig.
- Page 9 Assembly instructions terrace awning TR850 EXTENSION 680 mm spring, double 1360 mm spring ,single fig. 20: spring diagram For the cable run see fig. 18. Then place the plastic U-section supplied round the spring for protection (fig. 17B). To prevent the spring from falling out during tensioning, short pieces of clip section can be places over the spring as a temporary measure.
- Page 10 Assembly instructions terrace awning TR850 E. Electrical connections + motor IMPORTANT : the electrical connections have to be made by a qualilfied installer/electrician (see guar- antee card 2.1.) The diagrams for electrical fittings and connections have to be applied correctly and all the electrical accessories used must be in accordance with the existing norms and requirements.
- Page 11 Assembly instructions terrace awning TR850 wires as shown in the diagram. The phase wire from the fuse box should be connected to terminal L. If necessary, reverse the brown and black leads from the motor in the switch so that the arrows on the...
- Page 12 Assembly instructions terrace awning TR850 Why use an RI2 relay box ? Terrace awnings consisting of several blinds are always driven by several motors. The motors can be operated each using a separate switch. This allows each blind to be operated separately.
-
Page 13: Finishing & Maintenance
Assembly instructions terrace awning TR850 G. Finishing & Maintenance G.1. Finishing If the sun blind is to be fitted with a storm bar, lower the drop bar by about 15 cm. Remove the closing plate at the upper end of the guide rails. - Page 14 Assembly instructions terrace awning TR850 fig. 28: Gutter G.2. Maintenance - The terrace awning is in the first instance a sun blind. With a suitable slope, i.e. 15 to 20 degrees, the sun blind can also be used to provide shelter from moderate rain. It goes without saying that a sudden large quantity of water on the blind will cause sagging if the water is not drained off.
-
Page 15: Fault Finding
Assembly instructions terrace awning TR850 H. Fault-finding 1. Blind will not unroll or roll up: - Wire making poor contact after extending motor cable. Check connections. - Motor has run hot. Leave 1/2 hour to cool. - Faulty adjustment of limit switches on motor.
