- Page 1 Assembly instructions Pivot arm awnings US701 - US702 - US715 art.nr. 41183...
- Page 2 16 A. Introduction The Harol - pivot arm awnings US701/US702 are cassette awnings. This means that, in a closed posi- tion, fabric and roller tube are protected against weather conditions by the top board and the cover cap. The closed case is a closed, all-protecting cassette.
- Page 3 Assembly instructions pivot arm awnings US701 - US702 - US715 Guarantee and conditions : - Harol has endeavered to design and assemble this sun protection in accordance with the ruling and valid CE-norms. Nevertheless, feel free at any time to countercheck these interpretations with your local national institute of normation.
- Page 4 Assembly instructions pivot arm awnings US701 - US702 - US715 D. Assembly instructions US700 D.1. Open the cardboard wrapping Control the width of the casing and measure the width of the opening and see whether they fully cor- respond in the context of the fitting situation on hand.
- Page 5 Assembly instructions pivot arm awnings US701 - US702 - US715 Situation 1 – US701 Measure the holes to be drilled and do this on the side consoles of the box. Transfer these marks to the wall or the fitting surface. Make sure these holes are perfectly in line and use for this purpose waterhose and plumb line.
- Page 6 Assembly instructions pivot arm awnings US701 - US702 - US715 Situation 2 – US702 Mark the holes to be drilled on the wall or the fitting surface by using one of the wall brackets.The outer wall brackets have to be positioned as close as possible to the side consoles of the box.
- Page 7 Assembly instructions pivot arm awnings US701 - US702 - US715 Situation 3 – US715 Slide the wall consoles, left and right side, including the open bearings, pro- visionally onto the fabric roller. Measure the attachment holes to be drilled on the wall consoles(frontal or sideways). Mark these holes on the wall or the fitting surface.
- Page 8 Assembly instructions pivot arm awnings US701 - US702 - US715 35,5 12,5 22,5 Position elliptic holes in rear arm with VA/SA/WGA/GA L = 300 mm (2 holes) SA + WGA : L = 765 mm (2 holes) GA 165 :...
- Page 9 Assembly instructions pivot arm awnings US701 - US702 - US715 D.5. Fitting of the arms: Control the number of arms delivered. There must always be a left arm and a right arm, fitted to the extremities of the box. The other arms have to be divided proportionally; if dealing with a coupled...
- Page 10 Assembly instructions pivot arm awnings US701 - US702 - US715 Fitting the fabric roller to the rear means a shift of 30mm. Fitting the fabric roller to the front means a shift of 20mm. Drill the attachment holes into the wall , use a masonry drill Ø8mm. Introduce the S8 wall plugs into the holes.
- Page 11 Assembly instructions pivot arm awnings US701 - US702 - US715 D.8. Coupled awnings (US701 / US702): If the width of the awning exceeds 7 meters, the awning is delivered in two separate parts. Part 1 is equipped with the drive and part 2 is the part to be coupled. The coupling takes place on the fitting location..
- Page 12 Assembly instructions pivot arm awnings US701 - US702 - US715 E. Electrical connections + motor Important remark: all electrical connections have to be made by a qualified fitter/electrician (see guar- antee card 2.1.). Electrical fitting- and connection diagrams have to be applied in a correct way. The electrical accessories used have to be conform the norms and/or demands in vigor.
- Page 13 Assembly instructions pivot arm awnings US701 - US702 - US715 Connection and installation of the motor Discreetly lead the motor cable to the switch. Connect the motor cable and the net wires to the single- pole switch (see above). If necessary change the brown and the black wire according to the direction of the arrows of the switch.
- Page 14 Assembly instructions pivot arm awnings US701 - US702 - US715 E.2. Setting of the end switches of the motor E.2.1. Roll-down direction - setting of the end position down Allow the motor to run down. Make sure it stops in time, before reaching the final down position.
- Page 15 Assembly instructions pivot arm awnings US701 - US702 - US715 E.3. Why use an RI2 relay box ? If several motors are operated using the same switch, you must always use a relay box. If relay boxes are not used, the integral limit switches will soon burn out due to the high inductive and capacitive voltages which are mutually generated.
- Page 16 - See fitting instruction for wind/sun automats. G. Labels If necessary, do apply warning labels. Harol reserves the right to make changes at any time to the construction without having to inform the client beforehand, and therefore without having to adapt existing installations. V1-02-06...
