AXIS M32-LVE Network Camera Series
AXIS M3205-LVE Network Camera
AXIS M3206-LVE Network Camera
ユーザーマニュアル

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M32-LVE Series and is the answer not in the manual?

Questions and answers

Related Manuals for Axis M32-LVE Series

Summary of Contents for Axis M32-LVE Series

  • Page 1 AXIS M32-LVE Network Camera Series AXIS M3205-LVE Network Camera AXIS M3206-LVE Network Camera ユーザーマニュアル...

  • Page 2: Table Of Contents

    AXIS M32-LVE Network Camera Series ⽬次 About this this manual manual ......................... . .

  • Page 3: About This Manual This

    AXIS M32-LVE Network Camera Series About this manual About this manual This user manual describes several products. This means you may find instructions that arenʼt applicable to your product.

  • Page 4: Installation

    AXIS M32-LVE Network Camera Series Installation Installation このビデオを⾒るには、このドキュメントのWeb バージョンにアクセスしてください。 www.axis.com/products/online-manual/42925#t10170563 Installation video for the product.

  • Page 5: Get Get Started

    Verify that no one has tampered with the firmware To make sure that the device has its original Axis firmware, or to take full control of the device after a security attack: 1. Reset to factory default settings. See .

  • Page 6: Webpage Overview

    Secure passwords 重要 Axis devices send the initially set password in clear text over the network. To protect your device after the first login, set up a secure and encrypted HTTPS connection and then change the password. The device password is the primary protection for your data and services. Axis devices do not impose a password policy as they may be used in various types of installations.

  • Page 7: Configure Your Device Your

    AXIS M32-LVE Network Camera Series Configure your device Configure your device Adjust the image This section includes instructions about configuring your device. If you want to learn more about how certain features work, go to . Level the camera To adjust the view in relation to a reference area or an object, use the level grid in combination with a mechanical adjustment of the camera.
  • Page 8 AXIS M32-LVE Network Camera Series Configure your device Reduce noise in low-light conditions To reduce noise in low-light conditions, you can adjust one or more of the following settings: • Adjust the trade-off between noise and motion blur. Go to Video Video Video >...
  • Page 9 Use corridor format to better utilize the full field of view in a long and narrow area, for example a staircase, hallway, road, or tunnel. 1. Depending on your device, turn the camera or the 3-axis lens in the camera 90° or 270°. 注...
  • Page 10 AXIS M32-LVE Network Camera Series Configure your device ABC 123 Video > > > Image Image and click 1. Go to Video Video Image 2. Click for Pixel Pixel counter Pixel counter counter . 3. In the cameraʼs live view, adjust the size and position of the rectangle around the area of interest, for example where you expect license plates to appear.

  • Page 11: Adjust The Camera View (Ptz)

    AXIS M32-LVE Network Camera Series Configure your device 2. Make sure you have set up the application according to your needs. Add the overlay text: Video > > > Overlays Overlays . 1. Go to Video Video Overlays 2. Under Overlays...
  • Page 12 AXIS M32-LVE Network Camera Series Configure your device View and record video This section includes instructions about configuring your device. To learn more about how streaming and storage works, go to . Reduce bandwidth and storage 重要 Reducing the bandwidth can result in loss of details in the image.

  • Page 13: Set Up Rules For Events

    AXIS M32-LVE Network Camera Series Configure your device 5. Type the username and password. 6. Select the SMB version or leave it on Auto Auto. Auto 7. Select Add Add share share even share even even if if if connection...
  • Page 14 Provide visual indication of an ongoing event You have the option to connect the AXIS I/O Indication LED to your network camera. This LED can be configured to turn on whenever certain events occur in the camera. For example, to let people know that video recording is in progress.
  • Page 15 For instructions on how to connect the AXIS I/O Indication LED, see the installation guide provided with the product. The following example shows how to configure a rule that turns on the AXIS I/O Indication LED to indicate that camera is recording.
  • Page 16 AXIS M32-LVE Network Camera Series Configure your device 4. Type a name for the recipient. 5. Select Email Email Email . 6. Type an email address to send the email to. 7. The camera doesnʼt have itʼs own email server, so it will need to log into another email server to be able to send mails.
  • Page 17 AXIS M32-LVE Network Camera Series Configure your device 12. Type a name for the rule. Video , select T T T ampering ampering . 13. In the list of conditions, under Video Video ampering Notifications , select Send Send notification...

  • Page 18: Learn Learn More

    AXIS M32-LVE Network Camera Series Learn more Learn more View area A view area is a cropped part of the full view. You can stream and store view areas instead of the full view to minimize bandwidth and storage needs. If you enable PTZ for a view area, you can pan, tilt and zoom within it. By using view areas you can remove parts of the full view, for example, the sky.

  • Page 19: Streaming And Storage

    10/AVC 注 H.264 is a licensed technology. The Axis product includes one H.264 viewing client license. To install additional unlicensed copies of the client is prohibited. To purchase additional licenses, contact your Axis reseller. H.264 can, without compromising image quality, reduce the size of a digital video file by more than 80% compared to the Motion JPEG format and by as much as 50% compared to older MPEG formats.
  • Page 20 AXIS M32-LVE Network Camera Series Learn more Maximum Maximum bitrate Maximum bitrate (MBR) bitrate (MBR) (MBR) Maximum bitrate lets you set a target bitrate to handle bitrate limitations in your system. You might see a decline in image quality or frame rate as the instantaneous bitrate is kept below the specified target bitrate.
  • Page 21 AXIS M32-LVE Network Camera Series Learn more kbit/s Target bitrate Actual average bitrate You can also turn on maximum bitrate and specify a target bitrate within the average bitrate option. kbit/s Target bitrate Actual average bitrate...

  • Page 22: Roubleshooting

    Using firmware from the active track is recommended if you want to access the newest features, or if you use Axis end-to-end system offerings. The LTS tracks are recommended if you use third-party integrations, which are not continuously validated against the latest active track.

  • Page 23: Upgrade The Firmware

    Firmware upgrade Upgrade When the upgrade has finished, the product restarts automatically. You can use AXIS Device Manager to upgrade multiple devices at the same time. Find out more at axis.com/products/axis-device-manager Technical issues, clues, and solutions axis.com/support If you canʼt find what youʼre looking for here, try the troubleshooting section at...
  • Page 24 Possible IP address The static IP address in the Axis device is used before the DHCP server sets a dynamic conflict with another address. This means that if the same default static IP address is also used by another device on the same device, there may be problems accessing the device.

  • Page 25: Performance Considerations

    • An event that uses images on the camera, for example an event that sends an e-mail with an image every hour • An installed and running application, such as AXIS Video Motion Detection, will always consume a video stream, whether it is used or not. A stopped application does not consume a video stream.

  • Page 26: Need More Help

    Heavy network utilization due to poor infrastructure affects the bandwidth. • Viewing on poorly performing client computers lowers perceived performance and affects frame rate. • Running multiple AXIS Camera Application Platform (ACAP) applications simultaneously may affect the frame rate and the general performance. Need more help? Useful links •...

  • Page 27: The Device Interface Device

    AXIS M32-LVE Network Camera Series The device interface The device interface You reach the device interface by entering the IP address of the device in a web browser. 注 Support for the features and settings described in this section varies between devices.

  • Page 28: Video

    AXIS M32-LVE Network Camera Series The device interface Video Click to play the live video stream. Click to freeze the live video stream. Click to take a snapshot of the live video stream. The file is saved in the ʻDownloadsʼ folder on your computer.
  • Page 29 AXIS M32-LVE Network Camera Series The device interface • Pixel Pixel counter Pixel counter : Click counter to show the pixel counter. Drag and resize the box to contain your area of Width and Height Height fields. interest. You can also define the pixel size of the box in the Width...
  • Page 30 AXIS M32-LVE Network Camera Series The device interface Brightness : Use the slider to adjust the light intensity. This can make objects easier to see. Brightness is applied Brightness Brightness after image capture, and doesnʼt affect the information in the image. To get more details from a dark area, itʼs usually better to increase gain or exposure time.
  • Page 31 AXIS M32-LVE Network Camera Series The device interface When the camera detects the color temperature of the incoming light, it can adjust the image to make the colors look more natural. If this is not sufficient, you can select a suitable light source from the list.
  • Page 32 AXIS M32-LVE Network Camera Series The device interface Synchronize illumination illumination : Turn on to automatically synchronize the illumination with the surrounding light. The Synchronize Synchronize illumination synchronization between day and night only works if the IR-cut filter is set to Auto...
  • Page 33 AXIS M32-LVE Network Camera Series The device interface Spot: Uses an area with a fixed size and position in the live view to calculate the exposure. • Spot Spot • Custom Custom : Uses an area in the live view to calculate the exposure. You can adjust the size and position Custom of the area.
  • Page 34 Zipstream H.264 or H.265 stream in real time. Axis Zipstream applies a high bitrate in scenes where there are multiple regions of interest, for example in scenes with moving objects. When the scene is more static, Zipstream applies a lower bitrate, and thereby reduces the required storage.
  • Page 35 AXIS M32-LVE Network Camera Series The device interface • Average Average : Select to automatically adjust the bitrate over a longer time period and provide the best Average possible image quality based on the available storage. Click to calculate the target bitrate based on available storage, retention time, and bitrate limit.

  • Page 36: Recordings

    AXIS M32-LVE Network Camera Series The device interface View areas : Click to create a view area. Click the view area to access settings. Name: Enter a name for the view area. The maximum length is 64 characters. Name Name...

  • Page 37: Apps

    Find more more apps apps apps: Click to go to an overview page of Axis apps. The context menu contains: • App App log log: Click to view a log of the app events. The log is helpful when you contact support.
  • Page 38 AXIS M32-LVE Network Camera Series The device interface IPv4 IPv4 IPv4 • Automatic Automatic IP IP IP (DHCP) Automatic (DHCP) (DHCP) and and DNS DNS (DHCP) (DHCP) (DHCP) : The recommended setting for most networks. The current settings are updated automatically.
  • Page 39 AXIS M32-LVE Network Camera Series The device interface Bonjour ® Bonjour Bonjour : Turn on to allow automatic discovery on the network. Bonjour Bonjour name Bonjour name name: Enter a friendly name to be visible on the network. The default name is the device name and MAC address.
  • Page 40 Authentication failed 注 All Axis Video MIB traps are enabled when you turn on SNMP v1 and v2c traps. For more information, see AXIS OS Portal > SNMP • v3 v3 v3: SNMP v3 is a more secure version, which provides encryption and secure passwords. To use SNMP v3, we recommend you to activate HTTPS, as the password is then sent through HTTPS.
  • Page 41 When configured without a CA certificate, server certificate validation is disabled and the device tries to authenticate itself regardless of what network it is connected to. When using a certificate, in Axis' implementation, the device and the authentication server authenticate themselves with digital certificates using EAP-TLS (Extensible Authentication Protocol - Transport Layer Security).
  • Page 42 To install test firmware or other custom firmware from Axis on the device, you need a custom-signed firmware certificate. The certificate verifies that the firmware is approved by both the device owner and Axis. The firmware can only run on a specific device which is identified by its unique serial number and chip ID. Custom-signed firmware certificates can only be created by Axis, since Axis holds the key to sign them.
  • Page 43 AXIS M32-LVE Network Camera Series The device interface A rule defines the conditions that must be met for the product to perform an action. The list shows all the currently configured rules in the product. 注 You can create up to 256 action rules.
  • Page 44 AXIS M32-LVE Network Camera Series The device interface Use passive passive FTP passive FTP: Under normal circumstances the product simply requests the target FTP server to open the data connection. The device actively initiates both the FTP control and data connections to the target server.
  • Page 45 IoT integration and is used in a wide variety of industries to connect remote devices with a small code footprint and minimal network bandwidth. The MQTT client in Axis device firmware can simplify integration of data and events produced in the device to systems which are not video management systems (VMS).
  • Page 46 AXIS M32-LVE Network Camera Series The device interface Connect : Turn on or off the MQTT client. Connect Connect Status Status : Shows the current status of the MQTT client. Status Broker Broker Broker Host: Enter the hostname or IP address of the MQTT server.
  • Page 47 Storage). We recommend you to configure the host to use a fixed IP address (not DHCP since a dynamic IP address can change) or that you use DNS. Windows SMB/CIFS names are not supported. Network share share : Enter the name of the shared location on the host server. Several Axis devices can use • Network Network share the same network share, since each device gets its own folder.
  • Page 48 AXIS M32-LVE Network Camera Series The device interface Add share share even even if if if connection connection test test fails fails : Select to add the network share even if an error is discovered • Add share even connection...
  • Page 49 AXIS M32-LVE Network Camera Series The device interface Hard drive drive Hard Hard drive • Free Free: The amount of free disk space. Free • Status Status : If the disk is mounted or not. Status • File File system File system : The file system that is used by the disk.
  • Page 50 AXIS M32-LVE Network Camera Series The device interface Each NAT traversal protocol can be used separately or in different combinations depending on the network environment. • ICE ICE: The ICE (Interactive Connectivity Establishment) protocol increases the chances of finding the most efficient path to successful communication between peer devices.
  • Page 51 AXIS M32-LVE Network Camera Series The device interface • Registered Registered : Use for calls to SIP devices outside the local network, through a SIP server. Registered • Domain Domain : If available, enter the public domain name. It will be shown as part of the SIP address when Domain calling other accounts.
  • Page 52 Delete the user. You canʼt delete the root user. user By creating an ONVIF user, you automatically enable ONVIF communication. Use the username and password for all axis.com ONVIF communication with the device. For more information see the Axis Developer Community at ONVIF media media profiles profiles...
  • Page 53 AXIS M32-LVE Network Camera Series The device interface Detectors Camera Camera tampering Camera tampering tampering The camera tampering detector generates an alarm when the scene changes, for example because the lens is covered, sprayed or severely put out of focus, and the time in T T T rigger...
  • Page 54 Severity : Select which messages to send when triggered. Severity CA certificate certificate certificate set set: See the current settings or add a certificate. Plain config Plain config is for advanced users with experience of Axis device configuration. Most parameters can be set and edited from this page.

  • Page 55: Maintenance

    注 All Axis device firmware is digitally signed to ensure that you only install verified firmware on your device. This further increases the overall minimum cybersecurity level of Axis devices. For more information, see the axis.com white paper “Signed firmware, secure boot, and security of private keys”...

  • Page 56: Specifications

    AXIS M32-LVE Network Camera Series Specifications Specifications Product overview Optical shield microSD card slot Network connector (PoE) Status LED indicator IR illumination Control button HDMI connector Focus ring LED indicators Status Status LED Status Indication Indication Indication Unlit Connection and normal operation.

  • Page 57: Sd Card Slot

    • Resetting the product to factory default settings. See . • Connecting to an AXIS Video Hosting System service. To connect, press and hold the button for about 3 seconds until the status LED flashes green. Intrusion alarm switch Use the intrusion alarm switch to get a notification when someone opens the deviceʼs housing. Set up an action rule, for example recording or notification, to perform an action when the switch is activated.
  • Page 58 AXIS M32-LVE Network Camera Series Specifications Function Function Function Notes Notes Notes Specifications Specifications Specifications DC ground 0 V DC DC output Can be used to power auxiliary equipment.Note: This 12 V DCMax load = 25 mA pin can only be used as power out.
  • Page 59 Ver. M10.2 ユーザーマニュアル AXIS M32-LVE Network Camera Series ⽇付: 2022年6⽉ © Axis Communications AB, 2019 - 2022 ⽂書番号 T10141921...
