Quanser QNET Quick Start Manual

Quick Start Guide:
STEP 1
Check Components and Details
Make sure your QNET Mechatronic Interfacing experiment includes the following components:
1
2
STEP 2
Additional Components Required
To complete your QNET Mechatronic Interfacing setup, you will also need the following hardware:
1
STEP 3
Install LabVIEW and Add-Ons
Make sure the following versions of LabVIEW™ and required add-ons are installed:
1. LabVIEW™ 2013 or later
2. NI DAQmx 9.8 or later
3. NI ELVISmx 4.5 or later
QNET Mechatronic Interfacing
3
2
3
1. Quanser QNET Mechatronic Interfacing board
2. CAN bus loopback cable
3. SD card
The QNET curriculum resources are
Note:
available for download at www.ni.com/qnets
1. NI ELVIS II or NI ELVIS II
2. +5VDC / 5A, +15VDC / 2A,
-15VDC / 0.8A Power Supply
3. USB Cable
Note: All references to NI ELVIS II in
this guide apply to both NI ELVIS II
and NI ELVIS II
+ workstation
+ devices.
