obsta OFP-CAB-8E-RW-240-HIA Installation And Operation Manual

Obstaflash hi led lighting system
Hide thumbs

Advertisement

Quick Links

Download this manual
OBSTAFLASH HI LED
LIGHTING SYSTEM
INSTALLATION AND OPERATION GUIDE
OBSTA- 2 rue Troyon 92316 Sèvres Cedex FRANCE
Phone : +33 1 41 23 50 10
Fax : +33 1 41 23 50 11
www.obsta.com
January 2021
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the OFP-CAB-8E-RW-240-HIA and is the answer not in the manual?

Questions and answers

Related Manuals for obsta OFP-CAB-8E-RW-240-HIA

Summary of Contents for obsta OFP-CAB-8E-RW-240-HIA

  • Page 1 OBSTAFLASH HI LED LIGHTING SYSTEM INSTALLATION AND OPERATION GUIDE OBSTA- 2 rue Troyon 92316 Sèvres Cedex FRANCE Phone : +33 1 41 23 50 10 Fax : +33 1 41 23 50 11 www.obsta.com January 2021...
  • Page 2 DESCRIPTION COLOR POWER SUPPLY OFP-CAB-8E-RW-240-HIA 120-230 V – 50/60Hz 113782RW-8E White OFP-120-RW-2L-HIA-L4 White 113781L4 OFC-CTR 113625L 120-230 V – 50/60Hz ICAO PHOTOCELL 500/50 LUX 113135 48 Vdc This list is not exhaustive and some options can be added for synchronization and remote alarm control (GPS for wireless synchronization, optical cable for synchronization and/or GPRS interface for remote monitoring) and combination of medium and high intensity system.

  • Page 3: Warranty

    OBSTA shall in no case exceed the price allocable to the item or service or part thereof which gives rise to the claim.

  • Page 4: General Information

    This manual provides information about the installation, operation, and maintenance of the OBSTAFLASH HI Led High Intensity Obstruction Lighting Systems manufactured by OBSTA. The lighting systems described in this manual are ICAO High intensity type A, for use as high intensity aviation obstruction warning systems.
  • Page 5 OFP-CAB-8E-RW-240-HIA P/N:113782RW-8E Fault Transmitter Card NO CO M NC O UT Ni ght +48 G ND R E LA Y P W R + OFF : S lave GN D Power control C TR L Up Remote Middle Test mode...
  • Page 6 Figure 1-2 Outline and mouting dimensions Power supply P/N:113782RW-8E...
  • Page 7 Figure 1-3 Outline and mouting dimensions HI flashhead P/N:113781L4...
  • Page 8 Intermediary junction box P/N: 1238DI Ph2 Ph3 N Ph1 Ph2 Ph3 N INPUT OUTPUT INPUT TRI 380V OUTPUT TRI 380V LEVEL UP CONTROLLER CONTROLLER LEVEL UP 113797AOL 113797AOL 113780-RW-3 113780-RW-3 113780-RW-3 N°1 or 4 N°2 or 5 N°3 or 6 Figure 1-4.
  • Page 9 All dim ensions are in m m 4 Trous de fixation Ø9 4 x Ø9 mouting holes 1 SERRURE ETANCHE 1 WATER-RESISTANT LOCK FRONT VIEW Passage de cable Ø 11 à 21 Ø 11 to 21 cable connectors BOTTOM VIEW Matériel : Inox 316L ep.
  • Page 10 Figure 1-6 Outline and mouting dimensions Photocell Day/Twilight/Night P/N:113135...
  • Page 11 OFH-CTR P/N : 113625L Carte de commande / Command board Fault Tr ansm itter Car d N O C O M N C O U T N ight D ay +48 G N D RELAY 6 Crep Manu Test Night II RELAY 5 Nuit Manu Test Twlight 0 Test Day I...
  • Page 12 Figure 1-8 Outline and mouting dimensions Controller P/N:113625L...

  • Page 13: Specifications

    1.3 SPECIFICATIONS 1.3.1 LIGHT OUTPUT Intensity Day………………………........200 000 ±25% effective candelas, single flash Twilight..............20 000 ±25% effective candelas, single flash Night................2 000 ±25% effective candelas, single flash Beam Pattern................120º horizontally; 3º min. vertically Flash Rate: ..........................40 fpm Master/slave configuration: ............up to 32 lights can be synchronized With controller: ................

  • Page 14: Section 2 : Principles Of Operation

    SECTION 2 : PRINCIPLES OF OPERATION Power supply P/N 113742 The main power input is converted in 48VDC through the AC power supply that feeds the 2 command cards and power cards. Power cards P/N 113741B The system includes 9 power cards that regulate the current sent to the 16 white led circuits and 1 red led circuit as per figure 2-2: 8 power cards for white led circuits: each card regulates the current of 2 white led circuits of the same projector during daytime and twilight;...
  • Page 15 when set-up in slave mode (dipswitch n°1 on « off»), the command card waits for a top sync • pulse on terminal 3, D14 also blink at the same frequency If no pulse is received from terminal 3, D14 is off and light flashes on its own at 15 fl per •...
  • Page 16 Figure 2-1. Luminous indicators on the command card...
  • Page 17 Figure 2-2. Wiring of led circuits on the command card...
  • Page 18 SECTION 3.0 – INSTALLATION (wiring diagram 3-1 to 3-5 page 19 to 24) 3.1 Unpacking Carefully unpack each item and remove any internal packing material from the power supply and the obstaflash. Examine each item for obvious physical damage. Report any claims to the carrier immediately. Pertinent data such as installation drawings, schematics, interconnection drawings, and operation manuals are included in the power supply carton.
  • Page 19 OFH-CAB-8P-8E-240-HIA P/N:113782RW-8E Flashhead HI Projecteur N°7 Projecteur N°8 R E L A Y P W R+ Projecteur N°5 Projecteur N°6 OFF : Sl a v e GN D Power control C T RL Projecteur N°3 Projecteur N°4 Projecteur N°1 Projecteur N°2 Up Remote Middle Test mode ON : M a s t e r...
  • Page 20 3.2.2 OBSTAFLASH Power Supply The power supply is connected to its respective obstaflash via the 4 meters cable provided with each led projector. If you required longer length of cable, consult your OBSTA representative. 3.2.3 Ambient Light Sensor P/N113135 The ambient light sensor should be mounted upright, away from artificial light (eg., floodlights), and in a location that will enable its sensor window to have an unobstructed view of the polar sky (eg., pointed north in...
  • Page 21 OFP-CAB-8E-RW-240-HIA OFP-CAB-8E-RW-240-HIA OFP-CAB-8E-RW-240-HIA P/N:113782-RW-8E P/N:113782-RW-8E P/N:113782-RW-8E In te rme d i a ry j u n cti o n b ox N° 1 or 4 N° 2 or 5 N° 3 or 6 P/N: 1 2 3 8 DI Faul t Tr ansm i t t er Car d...
  • Page 22 OF H-CT R P/ N : 113625L In te rme d i a ry j u n cti o n b o x Ca rte d e co mma n d e P/N: 1 2 3 8 DI / Co mma n d b o a rd P h 1P h 2 P h 3 N P h 1P h 2 P h 3 N 12 3...
  • Page 23 OF P -CAB-8E-RW-240-HI A OFP-120-RW-2L-HIA-L4 P/ N:113782-RW-8E 113781L4/113782RW-8E P/N :113781L4 Faul t Tr ansm i t t er Car d Proje c t N°7 Proje c t N°8 113782RW-8E 113782RW-8E Project N °1 Project N°5 1 PC A 1 9 PC A5 Blue B lue R E L A Y...
  • Page 24 Intermediary junction box Intermediary junction box P/N: 1238DI P/N: 1238DI cabinet in top cabinet in down P h 1 P h 2 P h 3 N P h 1 P h 2 P h 3 P h 1P h 2 P h 3 N P h 1P h 2 P h 3 N IN P U T TR I 380V OU TP U T T R I 380V...

  • Page 25: Controller (Option)

    3.2.5 Controller (option) In the controller, there is one Receiver Block (plugged into a Fault Receiver Board) for every eight lights. This card is used to view faulty lamps. 3.2.6 Power supply flashhead (option) In each power supply of the flash fire heads, there is an emitter board which must be assigned a unique light number (up to 32) corresponding to the light number in the controller.
  • Page 26 N° Micro interrupteur S2 Micro interrupteur S2 N° lightin lighting 3-5 : Coding...
  • Page 27 3.3 Final Check with controller Before applying power to the equipment, check all wire connection according to figure 3-1 and 3-2 and ensure that any user-installed wiring does not interfere. 3.3.1 Test button (S1 in the middle position) The S1 test button allows 3 positions: “Up”: remote position, the light is in normal operation “Middle”: the light are forced in “day”...
  • Page 28 OFH-CAB-8E-RW-240-HIA P/N:113782RW-8E Carte de défaut Fault transmitter N O C O M N C Nig h t Da y + 4 8 GND RELAY PWR+ OFF : S lave CTRL Power control ON : Master P/N :113744HIL P/N :113744HIR COMMAND BOARD DAY COMMAND BOARD NIGHT / TWILIGHT +48V +48V...
  • Page 29 Controleur Feu led H I 113625L Carte de commande / Command board C ar te de défaut NO CO M NC O UT Ni g ht +48 G ND Co m RELAY 6 Cr ep M anu RELAY 5 Nui t M anu RELAY 4 AUTO / M ANU J/ C RELAY 3 AUTO / M ANU...
  • Page 30 Intermediary junction box P/N: 1238DI OUTPUT TRI 380V OUTPUT CONTROLLER INPUT INPUT TRI 380V LEVEL UP LEVEL UP 113625L 113797AOL 113797AOL 113682RW 113682RW 113682RW T B5 T B6 T B7 O-CBL-00080-OFH Figure 3-8. Wiring diagram of the Power supply 1238DI...
  • Page 31 SECTION 4.0 - MAINTENANCE 4.1 Obstaflash beacon No special or preventive maintenance is required for the obstaflashs, but only that which can be performed on an as-needed basis. 4.2 Obstaflash power supply No special maintenance is to be done on the power cabinet except when it is necessary, however it is recommended to tight screws once a year 4.3 Photocell The only maintenance required for this unit is the periodic cleaning of the Photocells.
  • Page 32 Annex The controller powered through 110-240Vac is located at the bottom of the tower. It is connected to the photocell and the 5G1,5 control cable going to the junction boxes of the high intensity lights 1. It contain a test button to force day/twilight/night mode and remote mode (controlled by photocell through relays) It allows also to 2.
  • Page 33 OFH-CTR P/N : 113625L C arte de commande / C ommand board F a u lt tra ns m itte r PHOT OCELL 500/50 LUX P/N 113135 NO CO M NC O UT Ni g ht Da y +48 G ND R ELA Y 6 C rep M anu T e s t Nig h t II R ELA Y 5 N ui t M anu...
  • Page 34 OFH-CTR P/N : 113625L Carte de commande / Command board Fault transmitter C OM O U T N ight D ay GN D RELAY 6 Crep Manu Test Night II RELAY 5 Nuit Manu Test Twlight 0 Test Day I RELAY 4 AUTO/MANU RELAY 3 AUTO/MANU RELAY 2 Crépu Auto...
  • Page 35 Transmitter/receiver card part number 113749B inside each high intensity power supply and the controller P/N 113625L at the bottom 1. Configuration of the card : The same card is inside each lamp and inside the controller. So it can be configured as: - transmitter (pin 2 of dip-switch S1 at ON) when installed inside each lamp - receiver (pin 2 of dip-switch S1 at OFF) when installed inside the controller.
  • Page 36 3. Assignment of a unique number in each transmitter card inside each lamp In each transmitter card, the user must assign a unique number for each lamp as dened by the switch S2 according to the table below.  This number will correspond to the leds B1 to B32 “on” in case of default received in the receiver card located inside the controller at the bottom of the pylon The receiver card count every 5 minutes the number of defaults.
  • Page 37 Possible troublesomes on high intensity part number 113780 To be used in the manual: figure 3-4 page 23 for the localization of each items inside the power supply of each flash-head  figure 3-6 page 28 for the internal wiring of the power supply of each flash-head ...

This manual is also suitable for:
