RVE DUBHE E700 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Item No. / 产品编号
Description / 产品名称
Power / 动力
Rotor Head / 主旋翼头型式
Length / 总长度
Width / 总宽度
Height / 总高度
Length / 长度
Main Rotor (Req'd)
Diameter / 旋翼直径
主旋翼
Length / 长度
Tail Rotor (Req'd)
尾旋翼
Diameter / 回转直径
Main Gear / Pinion 主齿轮 / 马达驱动齿轮
Gear Ratio (E:M:T) / 齿轮比
Full Equipped Weight
全备重量
Recommended of servo specifications
建议使用舵机规格
Recommended Power Configuration
动力搭配建议
MK70000
DUBHE E700
天枢星 E700
Electric Motor
电动无刷马达
Flybarless
无副翼控制系统
1360 mm / ( 53.54" )
190 mm / ( 7.48" )
352 mm / ( 13.86" )
700 mm / ( 27.56" )
1555 mm / ( 61.22" )
105 mm / ( 4.13" )
289 mm / ( 11.38" )
112 T Main Gear / 12T Pinion Gear
9.33 : 1 : 4.89
4480 g (12S 4500mAh)
(158 oz)
Standard Servo
标准尺寸舵机
Battery 电池 : 12S (6S x 2) 3200~5300mAh
ESC 电调 : 130A+ (12S)
Motor 马达 : 510~540KV (12S)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DUBHE E700 and is the answer not in the manual?

Questions and answers

Related Manuals for RVE DUBHE E700

Summary of Contents for RVE DUBHE E700

  • Page 1 MK70000 Item No. / 产品编号 DUBHE E700 天枢星 E700 Description / 产品名称 Electric Motor Power / 动力 电动无刷马达 Flybarless Rotor Head / 主旋翼头型式 无副翼控制系统 1360 mm / ( 53.54" ) Length / 总长度 190 mm / ( 7.48" ) Width / 总宽度...

  • Page 2: Exploded View

    目录 Intro & Caution / 简介与警告 AMA Information / 特别注意事项 Flight Safety Checklist / 飞行前安全确认工作项目 Post Flight Inspection / 飞行结束安全检查事项 Caution / 注意事项 Other Item Required / 其它需求设备配件 Tools Required For Assembly / 组装工具需求 A Guide to the Instruction Manual / 说明书使用说明...
  • Page 3 Thank you for purchasing the RVE RC radio control helicopter. This new helicopter is the latest innovation by RVE RC. It has the perfect combination of flying stability and the agility for 3D flying. This helicopter is an excellent choice for flying enthusiasts like you. For convenient assembly and safe operation of the helicopter, please read the instructions carefully.

  • Page 4: Post Flight Inspection

    FLIGHT SAFETY CHECKLIST 飞行前安全确认工作项目 1. Make sure that the transmitter battery is fully charged before flying. 2. Make sure all control surfaces are operated properly before flying. 3. Do a range check of the radio before the first flight. The electronic equipment must operate properly at a range of at least 5 meters (18 ft) even with the transmitter antenna collapsed.

  • Page 5: Other Items Required

    OTHER ITEMS REQUIRED / 其它需求设备配件 RADIO SET / 遥控器系统 Standard Servo (For Swashplate) Receiver Rx Battery 标准尺寸倾斜盘用舵机 Switch Harness 接收机电池 接收机 电源开关组 Transmitter (helicopter type Standard Servo only, 6 or more channels) (For Tail Gyro) 发射机（需具备直升机控制功能 3-AXIS Gyro 标准尺寸尾舵用舵机 的6通道以上遥控器） 3轴陀螺仪...

  • Page 6: Symbols Used Throughout The Manual

    A GUIDE TO THE INSTRUCTION MANUAL / 说明书使用说明 A: Indicates the assembly step number and the parts bags that are to be assembled. Example 说明范例 B: Displays actual size drawings, and part quantities used. C: This instruction manual uses several symbols. Pay careful Step 1-1 Tail Belt Tenssion Pulley assembly / 尾皮带压带轮組裝...
  • Page 7 Tail Belt Tenssion Pulley assembly / Step 1-1 尾皮带压带轮组裝 ESC Mount Assembly / 电调固定座组装 Parts Description Flange Bearing d3xD7xW3 法兰轴承 d3xD7xW3 零件名称 Belt Pully Mount 皮带导向轮安装座 Collar 3x5x2.3 Parts Description 垫圈3x5x2.3 零件名称 ESC Mounting Plate Stainless Steel Pin 3x16 电调安装板 皮带导向轮轴销...
  • Page 8 Frame Inside Support Mount & Gyro, Receiver Mount assembly Step 1-3 内侧板前支撑板、陀螺仪、接收机固定座組裝 Parts Description 零件名称 Frame Inside Support Plate 内侧板前支撑板 Fream Spacer 内侧板支撑柱L32 Gyro Mount Plate 陀螺仪安装板 Tail Boom Clip Mount 尾管管夹 Receiver Mount Plate 接收机安装板 Flat Head Socket Screw, M3x8 沉头内六角螺丝...
  • Page 9 Tail Drive Gear & Main Gear Set assembly Step 1-4 尾传动齿轮及主齿轮组裝 Parts Description Parts Description 零件名称 零件名称 Tail Drive Gear Cover Main Gear, 112T/10° 尾皮带主齿轮挡边 主齿轮 112T/10° Tail Drive Gear, 88T One Way Clutch Housing 尾皮带主齿轮 88T 单向轴承座 Socket Screw, M2.5x6 One Way Clutch Washer 杯头内六角螺丝...
  • Page 10 Main Gear Set & Motor Mount assembly Step 1-6 主齿轮、电机固定座组裝 Parts Description Parts Description 零件名称 零件名称 One Way Bearing Shaft Motor Pinion Gear 12T/10° 单向轴承内套 12T电机齿（10°） Main Gear Set Shim 14x20x0.1 主齿轮组间隙调整垫片（0.1mm） Ball Bearing 10x19x5 主轴轴承10x19x5 Main Gear Set Shim 14x20x0.2 Pinion Gear Nut 主齿轮组间隙调整垫片（0.2mm）...
  • Page 11 Upper Frame assembly Step 2-1 内侧板组裝 Parts Description Parts Description 零件名称 零件名称 Upper Frame Lift Socket Screw M3x8 上侧板左 杯头内六角螺丝 M3x8 Upper Frame Right 上侧板右 Frame servo mount A 舵机固定片A Belt tension pulley mount 皮带张紧器安装片 Canopy Retaining Post L26 700头罩固定柱L26 Button Head Socket Screw M2.5x5 半圆头内六角螺丝...
  • Page 12 Upper Frame Bearing Block assembly Step 2-2 内侧板组裝 Parts Description 零件名称 Main Shaft Bearing 主轴轴承 10x19x5 Main Shaft Bearing Block 主轴轴承座 Frame Reinforcing Plate 侧板加强件 Servo Mount 舵机安装座 Button Head Socket Screw M3x6 半圆头内六角螺丝 M3x6 Socket Screw M3x12 杯头内六角螺丝 M3x12 Socket Screw M3x40 杯头内六角螺丝...
  • Page 13 Lower Frame assembly Step 2-3 外侧板组裝 Parts Description 零件名称 Lower Frame 外侧板 Battery Tray Rail 电池滑轨 Battery Tray Clip 电池卡扣 Canopy Retaining Post L15 头罩固定柱 L15 Button Head Socket Screw M2.5x5 半圆头内六角螺丝 M2.5x5 Button Head Socket Screw M2.5x6 半圆头内六角螺丝 M2.5x6 Button Head Socket Screw M3x8 半圆头内六角螺丝...
  • Page 14 Lower Frame & Upper Frame Unit assembly Step 2-5 机架总裝 Parts Description 零件名称 In Side Frame Spacer L32 内侧板支撑柱L32 Out Side Frame Spacer L20 外侧板支撑柱L20 Landing Skid Mounting Block 整体脚架安装座 Socket Screw M2.5x6 杯头内六角螺丝 M2.5x6 Socket Screw M3x10 杯头内六角螺丝 M3x10 Socket Screw M3x30 杯头内六角螺丝...
  • Page 15 Install Main Transmission Step 2-6 主传动系统组裝 Parts Description Parts Description 零件名称 零件名称 700尾传动皮带 Main Shaft E700 Tail Drive Belt 700主轴 Main Shaft Stopper 主轴定位环 Tail Boom 700尾管 Socket Screw M3x22 杯头内六角螺丝 M3x22 Set Screw M2.5x10 杯头内六角螺丝M2.5x10 Nylon Nut M3 自锁螺母 M3 2-6 2-7主传动系统组装...

  • Page 16: Swashplate Assembly

    Step 3-1 Swashplate & FBL Washout Block assembly 倾斜盘、相位摇臂组组裝 Parts Description Parts Description 零件名称 零件名称 Swashplate Washout Arm 倾斜盘 相位摇臂 Swashplate Post Washout Arm Pin 倾斜盘滑轨球头 相位摇臂轴销 Linkage Ball 3x3x5.5mm FBL Washout Linkage A Arm 3x3x5.5MM球头 牛角摇臂 Flange Bearing 3x7x3 法兰轴承...

  • Page 17: Rotor Head Assembly

    Rotor Grip & Rotor Head assembly Step 3-3 桨夹组、旋翼头组装 Parts Description Parts Description 零件名称 零件名称 Rotor Grip Thrust Collar 12x16x0.5 主旋翼夹 桨夹推力轴承垫片12x16x0.5 Rotor Grip Lever Ball Bearing 8x16x5 桨夹摇臂 桨夹轴承8x16x5 Rotor Head Hub 700 Thrust Bearing 旋翼头中联 700桨夹推力轴承 Rotor Head Damper Button Head Socket Screw M3x25 旋翼头减震套...
  • Page 18 Rotor Head Linkage assembly Step 3-5 旋翼头连杆组裝 Parts Description 零件名称 Anti-Rotation Bracket 倾斜盘滑轨 Enhanced Universal Ball Link 加强型球头扣 Linkage Rod L34 正反牙拉杆 L34 Linkage Rod L38 正反牙拉杆 L38 Socket Screw M2.5x6 杯头内六角螺丝 M2.5x6 Socket Screw M3x20 杯头内六角螺丝 M3x20 Nylon Nut M3 M3防松螺帽...
  • Page 19 Tail Gear Box assembly Step 4-1 尾波箱组裝 Parts Description Parts Description 零件名称 零件名称 Tail Unit Housing Button Head Socket Screw M3x6 尾波箱安装座 半圆头内六角螺丝 M3x6 Set Screw M3x3 Tail Housing Plate 尾波箱轴承座 内六角顶丝 M3x3 Flanged Bearing 5x13x4 Tail Housing Spacer 尾波箱轴承 5x13x4 尾波箱支撑柱...
  • Page 20 Tail Pitch Control System assembly Step 4-2 尾滑块、尾推控制组组裝 Parts Description Parts Description 零件名称 零件名称 Tail Pitch Control Link Tail Pitch Control Arm Collar 尾螃蟹爪球头扣 尾推轴承垫片 Tail Pitch Control Fork Tail Pitch Control Arm Lever 尾螃蟹爪 尾推摇臂 Tail Pitch Control Slider Bushing Tail Pitch Control Linkage Ball 尾滑套...
  • Page 21 Tail Rotor Grip assembly Step 4-4 尾桨夹组裝 Parts Description Parts Description 零件名称 零件名称 Tail Rotor Hub Socket Screw M3x8 尾桨中联 杯头内六角螺丝 M3x8 Tail Rotor Grip Socket Screw M3x18 尾桨夹 杯头内六角螺丝 M3x18 Set Screw M4x4 Tail Thrust Bearing 尾桨夹推力轴承 内六角顶丝M4x4 Thrust Washer 8x10x0.3 尾桨夹推力轴承垫片8x10x0.3 Ball Bearing 5x10x4 尾桨夹轴承5x10x4...
  • Page 22 Landing Skid & Tail Fin assembly Step 5-1 5-1B 脚架、垂直尾翼组裝 Parts Description Parts Description 零件名称 零件名称 Landing Skid Battery Tray 脚架H40 电池安装板 Skid Pipe Horizontal Fin 脚架滑撬 水平尾翼 Skid pipe end cap Vertical Fin 滑撬堵头 垂直尾翼 Set Screw M3x3 顶丝M3x3 Socket Screw M3x12 杯头内六角螺丝M3x12 Button Head Socket Screw M3x6...
  • Page 23 Tail Boom Support assembly Step 5-2 尾撑组组裝 Parts Description 零件名称 Carbon Tail Boom Support 碳纤尾撑杆L590 Tail Boom Support End 尾撑头 Socket Screw M3x10 杯头内六角螺丝 M3x10 Socket Screw M3x35 杯头内六角螺丝 M3x35 Socket Screw M2x11 杯头内六角螺丝 M2x11 Nylon Nut M3 M3自锁螺母 Nylon Nut M2 M2自锁螺母...
  • Page 24 Tail Pitch Control Likage assembly Step 5-3 尾舵拉杆组组裝 Parts Description 零件名称 Tail Pitch Linkage Connector 尾拉杆接头 Tail Pitch Carbon Linkage Rod 尾拉杆L715 Rod Guide 尾拉杆导向环 Rod Linkage Screw M2.3x20 丝杆M2.3x20 Ball Link 球头扣 Button Hexagon Tapping Screw M2.6x10 半圆头内六角自攻螺丝M2.6X10 5-3 尾舵拉杆组 Tail Pitch Control Likage assembly 尾拉杆在5-5零件包内。...

  • Page 25: Servo Installation

    Servo Installation Step 5-4 舵机安装 Parts Description 零件名称 Servo Nut 舵机固定座 Linkage Ball 2x5x2.5 2x5x2.5球头 Hexagon Tapping Screw M2.6x8 内六角自攻螺丝 M2.6x8 Socket Screw M2.5x8 杯头内六角螺丝 M2.5x8 Nylon Nut M2 自锁螺母 M2 Servo Mounting Spacer 舵机压片 5-4 舵机安装 Servo Installation Swashplate Servo Horn Rudder Servo Horn 另购...

  • Page 26: Canopy Installation

    / Canopy Installation Step 5-6 头罩安装 Parts Description 零件名称 Painted Canopy 彩绘头罩 Main Blade Holder 桨托 Hook And Loop Tape 电池魔术贴 Hook & Loop Strap L 设备绑带L Hook & Loop Fastening Tape L320 电池绑带 L320 R -Clasp R型扣 5-6 头罩安装 Canopy Installation R型扣...
  • Page 27 Radio System Setup / 遥控器系统设定 WARNING! / 警告! For safety, please ensure the motor has been deactivated and will not drive the main rotor head before performing following setting processes. You may just unplug 2 of the wires between the motor and the ESC or removing the motor pinion away from the main gear to avoid the rotor head rotating.
  • Page 28 Exploded View / 爆炸图检索 Rotor Head / 旋翼头组 10137 10132 68003 68002 10131 68090 68012 70021 75012 70019 70024 75082 10134 10022 68010 10015 70042 68013 70018 68029 10019 68016 10139 75016 70017 75014 75017 70023 70001 75082 -27-...
  • Page 29 SPARE PARTS / 配件表 Exploded View / 编 号 N O 名 称 数 量 Q uantity Description 68002 横 轴 SPIN DLE SHAF 68003 旋 翼 头 中 联 RO TO R HEAD HU B 68010 桨 夹 推 力 轴 承 垫 片 THRU ST CO LLAR 12x 16x 0.5 68012 桨...
  • Page 30 Exploded View / 爆炸图检索 OPTIONAL PARTS / 改装配件 70002 68026 70004 70003 10013 68027 68029 10151 68027 68029 70008 10013 68028 10109 10151 70036 10119 68085 ★ 10021 70037 68031 68023 10021 75029 68073 70039 10152 -29-...

  • Page 31: Spare Parts

    SPARE PARTS / 配件表 编号 NO 名称 Description 数量 Quantity 68023 主轴轴承座 MAIN SHAFT BEARING BLOCK 68026 皮带导向轮安装座 BELT PULLEY MOUNT 68027 皮带导向轮 BELT GUIDE PULLEY 68028 皮带导向轮轴销 STAINLESS STEEL PIN 3x16 68029 皮带导向轮轴套 BELT GUIDE PULLEY COLLAR 3x5x2.3 68031 电机齿轴承座...
  • Page 32 Exploded View / 爆炸图检索 Exploded View / Upper Frame / 上侧板组 10135 68055 10117 10111 68023 70006 10104 68034 68030 10135 68025 10116 75072 10131 70005 70012 70010 10108 68077 10135 10116 68031 68025 10103 68057 75116 10111 70009 -31-...
  • Page 33 SPARE PARTS / 配件表 编号 NO 名称 数量 Quantity DESCRIPTION 68023 主轴轴承座 MAIN SHAFT BEARING BLOCK 68025 内侧板支撑柱 FRAME SPACER L32 68030 电机安装座 MOTOR MOUNTING BLOCK 68031 电机齿轴承座 PINION GEAR BEARING BLOCK 68034 尾管安装管夹 TAIL BOOM CLIP MOUNT 68055 接收机安装板 RECEIVER MOUNT PLATER 68057 内侧板前支撑板...
  • Page 34 Exploded View / 爆炸图检索 Exploded View / Lower Frame / 外侧板组 10106 75078 68032 75116 10130 10130 10120 10131 68033 10103 70013 10109 10131 10112 10109 70015 75222 70034 10118 10104 70033 70035 70040 30006 L260 30010 30007 L320 30011 30016 -33-...
  • Page 35 30006 防滑电池绑带L260 HOOK AND LOOP STRAP L260 30007 防滑电池绑带L320 HOOK AND LOOP STRAP L320 30010 桨托 MAIN BLADE HOLDER 30011 RVE 毛钩一体绑带 VELCRO STRAP (10x220MM) 30016 电池魔术粘 HOOK AND LOOP TAPE 10103 M3x10杯头内六角螺丝 SOCKET HEAD BOLT M3x 10 10104 M3x12杯头内六角螺丝...
  • Page 36 Exploded View / 爆炸图检索 Exploded View / Main Gear / 传动齿轮组 10109 68022 10120 10133 10137 68021 70016 10113 10109 68071 68076 68084 68017 68042 68018 Servo / 舵机控制组 68019 10123 68043 75072 75072 75072 10110 10150 -35-...
  • Page 37 SPARE PARTS / 配件表 编号 NO 名称 DESCRIPTION 数量 Quantity 68017 单向轴承座 ONE WAY CLUTCH HOUSING 68018 单向轴承铜垫片 ONE WAY CLUTCH WASHER 68019 单向轴承内套 ONE WAY BEARING SHAFT 68021 尾皮带主齿轮（88T) TAIL DRIVE GEAR 88T 68022 尾皮带主齿轮挡边 TAIL DRIVE GEAR COVER 68042 单向轴承...
  • Page 38 Exploded View / 爆炸图检索 Tail Drive Unit / 尾波箱组 70043 10111 75231 70025 10111 75059 75225 68046 10118 68038 10112 75054 75114 75052 70041 68041 75120 70022 10123 10129 10110 75086 10017 68043 10120 10008 68045 68044 10102 75115 68083 10118 10121 68082...
  • Page 39 SPARE PARTS / 配件表 Exploded View / 编号 NO. 名称 数量 Quantity DESCRIPTION 68036 尾波箱安装座 TAIL UNIT HOUSING 68038 尾滑套 TAIL PITCH CONTROL SLIDER BUSHING 68041 尾推拨叉组 TAIL PITCH CONTROL ARM 68043 不锈钢球头 2x 5x 2.5 LINKAGE BALL 2x 5x 2.5 68044 尾桨夹...
